| # | Part | Description |
Req | Notes | Availability |
|---|
402 |
999-0019
|
Bolt 1/4-20 x 5/8 hex head grade 5 zinc plated |
2 |
|
|
403 |
N/A
|
Not available |
1 |
|
|
404 |
999-0190
|
Nut 1/4-20 hex plain finish |
2 |
|
|
405 |
999-0726
|
Screw 10-32 x 5/8 pan head phillips zinc plated |
1 |
|
|
406 |
164-3139
|
Nut 10-32 hex (OBSOLETE) |
2 |
|
|
407 |
164-3680
|
1 1/2 inch valve hanger- 12 dbl, 6 stair |
2 |
|
|
408 |
164-3679
|
Vinyl grip- 12 in, 12 bdl, 6 stair |
1 |
|
|
409 |
164-3334
|
Male quick connect |
1 |
|
|
410 |
164-3659
|
1/4 mpt close nipple |
1 |
|
|
411 |
164-0947
|
45 degree elbow |
1 |
|
|
412 |
164-3141
|
Screw 10-32 x 1 1/4 pan head phillips (OBSOLETE) |
1 |
|
|
413 |
164-3654
|
Valve assembly- 2, 3 jt, 12dbl, 6st |
1 |
|
|
414 |
164-3701
|
High pressure hose- 12 inch double (OBSOLETE) |
1 |
|
|
416 |
164-3702
|
Washer flat stainless steel |
1 |
|
|
417 |
999-0317
|
Screw 8-32 x 1/4 pan head slotted zinc plated |
12 |
|
|
418 |
164-3699
|
Squeegee blades (pkg of 2) |
1 |
|
|
419 |
164-3144
|
Screw 10-32 x 1/2 pan head phillips |
2 |
|
|
420 |
164-3698
|
Wand head |
1 |
|
|
421 |
164-3697
|
Brush- 12 (OBSOLETE) |
1 |
|
|
422 |
164-3700
|
Detent ring |
1 |
|
|
423 |
164-3696
|
Truarc snap ring |
1 |
|
|
424 |
164-3695
|
1 1/4 od x 1 1/16 id inchO inch ring |
1 |
|
|
425 |
164-3145
|
Vee jet |
1 |
|
|
426 |
164-3694
|
Base wand, 12 inch double |
1 |
|
|
N/S |
164-3648
|
O ring- small- upper stem |
1 |
|
|
N/S |
164-3647
|
O ring- large- under cap |
1 |
|
|
N/S |
164-3678
|
Valve handle- 12 dbl, 6 stair, 4upho (OBSOLETE) |
1 |
|
|
