| # | Part | Description |
Req | Notes | Availability |
|---|
701 |
164-3684
|
1/4 inch mpt brass flood jet |
1 |
|
|
702 |
164-3682
|
Base handle- 4 inch upholstery (OBSOLETE) |
1 |
|
|
703 |
164-3683
|
Valve clamp with hardware |
1 |
|
|
704 |
164-3139
|
Nut 10-32 hex (OBSOLETE) |
2 |
|
|
705 |
164-3141
|
Screw 10-32 x 1 1/4 pan head phillips (OBSOLETE) |
2 |
|
|
706 |
164-3685
|
Valve assembly- 4 inch upholstery |
1 |
|
|
707 |
164-3686
|
High pressure hose- 4 inch upholstery |
1 |
|
|
708 |
164-3334
|
Male quick connect |
1 |
|
|
N/S |
164-3679
|
Vinyl grip- 12 in, 12 bdl, 6 stair |
1 |
|
|
N/S |
164-3678
|
Valve handle- 12 dbl, 6 stair, 4upho (OBSOLETE) |
1 |
|
|
N/S |
164-3680
|
1 1/2 inch valve hanger- 12 dbl, 6 stair |
1 |
|
|
