| # | Part | Description |
Req | Notes | Availability |
|---|
3 |
164-8684
|
Holder |
1 |
|
|
4 |
164-8728
|
Washer |
4 |
|
|
5 |
164-8729
|
Screw |
4 |
|
|
6 |
164-8685
|
Damper spacer |
4 |
|
|
7 |
164-8686
|
Noise dampening foam |
1 |
|
|
8 |
164-6829
|
Gasket |
1 |
|
|
9 |
164-7480
|
Motor |
1 |
|
|
10 |
164-7480
|
Motor |
1 |
|
|
11 |
164-8687
|
Mousse |
1 |
|
|
12 |
164-8730
|
Support |
1 |
|
|
13 |
164-8311
|
Solution tank |
1 |
|
|
14 |
164-8652
|
Washer |
4 |
|
|
15 |
164-8651
|
Washer |
2 |
|
|
16 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
2 |
|
|
17 |
164-8688
|
Elbow connector |
1 |
|
|
18 |
164-8689
|
Plate |
2 |
|
|
19 |
164-8690
|
Screw |
1 |
|
|
20 |
164-7455
|
Drain plug kit |
1 |
|
|
21 |
164-7455
|
Drain plug kit |
1 |
|
|
22 |
164-8691
|
Filter |
1 |
|
|
23 |
164-8692
|
Water charging hose |
1 |
|
|
24 |
164-8693
|
Screw |
1 |
|
|
25 |
164-8680
|
Washer |
2 |
|
|
26 |
164-7455
|
Drain plug kit |
1 |
|
|
27 |
164-8694
|
Hose block |
1 |
|
|
28 |
164-8656
|
Screw |
2 |
|
|
29 |
164-8633
|
Nut |
1 |
|
|
