| # | Part | Description |
Req | Notes | Availability |
|---|
201 |
164-7295
|
Front decal |
1 |
|
|
202a |
164-2102
|
Identifier decal |
1 |
|
|
202b |
164-2103
|
Identifier decal |
1 |
|
|
203 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
1 |
|
|
204 |
164-1963
|
Float disc |
1 |
|
|
205 |
164-6226
|
Float disc gasket |
1 |
|
|
206 |
999-0998
|
Washer #10 flat stainless steel |
1 |
|
|
207 |
164-3162
|
Electrical caution label |
1 |
|
|
208 |
164-2036
|
Motor and float support lid |
1 |
|
|
209 |
164-3162
|
Electrical caution label |
1 |
|
|
210 |
164-5201
|
Float stand gasket |
1 |
|
|
211 |
164-5199
|
Lid gasket |
1 |
|
|
212 |
164-2040
|
Lid gasket support (black) |
1 |
|
|
213 |
164-2037
|
Float stand |
1 |
|
|
214 |
999-0013
|
Screw 10 x 5/8 pan head phillips sheet metal |
6 |
|
|
215b |
164-5200
|
Float and stem assembly |
1 |
|
|
216a |
164-1977
|
Cloth dynel bag |
1 |
|
|
216b |
164-1977
|
Cloth dynel bag |
1 |
|
|
217 |
164-1946
|
Float stem |
1 |
|
|
218 |
164-1921
|
Bag ring |
1 |
|
|
219 |
164-1974
|
Bag gasket |
1 |
|
|
220 |
164-5200
|
Float and stem assembly |
1 |
Includes 215b and 217 |
|
221a |
164-9010
|
Dynel filter bag assembly |
1 |
Includes 216b, 218 and 219 |
|
221b |
164-9010
|
Dynel filter bag assembly |
1 |
Includes 216a, 218 and 219 |
|
