PACER 214UE Brush Head Assembly - Bottom

#PartDescriptionPriceReqNotesAvailability
000a 164-7272 Brush head assembly $778.14 1 (includes 1-34) (includes top and bottom assembly) usually ships 1-5 days
000b 164-7282 Brush head assembly 240V, black $823.68 1 (includes 1-34) (includes top and bottom assembly) usually ships 1-5 days
001 164-6161 Spring extension $3.72 1 usually ships 1-5 days
002 164-6162 Height adjustment axle $38.03 1 usually ships 1-5 days
003 164-6163 Height adjustment wheel $14.62 1 usually ships 1-5 days
004 164-6164 Axle & pedal assembly $165.77 1 usually ships 1-5 days
005 164-6165 Axle retainer clip $3.72 2 usually ships 1-5 days
006 164-6744 Screw 3 1/2 x 12 $2.51 1 usually ships 1-5 days
007a 164-2005 Bottom brush housing $210.21 1 usually ships 18-33 days
007b 164-7285 Bottom brush housing 240V only $126.36 1 usually ships 1-5 days
008 999-0530 Screw M4-.7 x 8mm pan head slotted zinc $0.99 2 ships same day
009a 164-6167 Cover brush accessory $21.62 1 usually ships 1-5 days
009b 164-6167 Cover brush accessory $21.62 1 usually ships 1-5 days
010 164-6168 End plate with bearing $34.32 1 usually ships 18-33 days
011 164-6169 Brush roller assembly $154.23 1 (includes 019a-019b) usually ships 18-33 days
012 164-6170 End plate pulley $52.64 1 usually ships 18-33 days
013 164-6171 Brush pulley $39.61 1 usually ships 18-33 days
015 164-6186 Bumper $46.93 1 usually ships 1-5 days
016 164-7284 Screw M4 x 16 oval head $2.31 4 usually ships 1-5 days
017 164-6172 Brush shoe $82.18 1 usually ships 18-33 days
018 N/A Not available Call for price 1 (sleeve bushing) usually ships 3-26 days
019a 164-6101 14 inch brush strip (black) $36.74 1 usually ships 18-33 days
019b 164-6174 Brush strip\red hard $41.61 1 usually ships 1-5 days
020 164-6678 Screw M5 x 16 oval head $5.76 1 usually ships 18-33 days
021 999-0532 Screw M5-.8 x 30mm pan head slotted zinc $0.99 3 ships same day
022 164-6176 Foot pedal spring $3.85 1 usually ships 18-33 days
023 164-6177 Foot pedal $26.10 1 usually ships 1-5 days
024 164-2002 Wheel only $15.00 2 usually ships 18-33 days
025 164-2003 Wheel retainer $7.26 2 ships same day
026 164-6178 Wheel axle washer $7.38 2 usually ships 1-5 days
027 164-6179 Brass lock screw $51.80 1 usually ships 1-5 days
029 164-6180 Washer plastic $1.67 1 usually ships 1-5 days
030 999-0533 Washer M4 split lock plain finish $0.99 1 ships same day
031 164-6182 Axle support link $17.69 1 usually ships 1-5 days
032 164-6183 Axle clip $2.51 1 usually ships 1-5 days
033 164-6184 Axle support block $8.03 1 usually ships 1-5 days
034 164-6185 Washer $1.67 1 usually ships 1-5 days
