COLT 800P Tank Assembly With Tip Bases

#PartDescriptionPriceReqNotesAvailability
001 999-1241 Screw 3/8-16 x 2 1/2 round head phillips stainless steel $5.50 2 ships same day
002 164-2063 Pivot bracket (black) $56.23 2 usually ships 1-5 days
003 164-1794 Muffler spacer $4.49 2 usually ships 19-25 days
004 164-1919 Machined Hinge Bracket $211.41 1 usually ships 1-5 days
005 999-0193 Screw 10-24 x 5/8 pan head slotted thread cutting zinc $0.99 2 ships same day
006 999-1104 Screw 10-24 x 3/4 pan head phillips thread rolling zinc $0.99 2 ships same day
007 164-5203 Intake baffle (OBSOLETE) $25.72 1 usually ships 19-25 days
008a 164-1924 12 1/2 gallon tank stainless steel $852.51 1 (1250) usually ships 1-5 days
008b 164-1806 Intake assembly with gasket $182.44 1 (includes 009, 010a, 010b, 034, 035, 036, 037 and 038) usually ships 19-25 days
009 164-5204 Intake gasket $4.43 1 ships same day
010a 164-5202 Intake assembly $181.03 1 (includes 010b, 034, 035, 036, 037 and 038) usually ships 19-25 days
010b 164-1805 Polished intake $122.38 1 usually ships 1-5 days
011 164-2600 1 1/2 inch hose coupling $26.24 1 ships same day
012 164-3903 Front decal (OBSOLETE) $9.19 1 usually ships 1-5 days
013 164-1929 Band clamp $60.84 1 usually ships 1-5 days
014 999-1103 Bolt 1/4-20 x 3/4 hex head with nylon patch $4.94 4 ships same day
015 164-1930 Band clamp plate $6.80 2 usually ships 1-5 days
016 164-2065 Polypropelene tip base $462.90 1 usually ships 1-5 days
017 999-0113 Screw 1/4-20 x 1/2 truss head slotted $0.99 4 ships same day
018 999-0017 Washer 1/4 external star lock $0.99 4 ships same day
019 164-2062 Tip base axle $38.84 1 usually ships 1-5 days
020 164-5168 Flat nylon washer $2.82 2 ships same day
021 164-4592 10 inch plastic wheel (white) $67.13 2 ships same day
022 164-5168 Flat nylon washer $2.82 2 ships same day
023 999-0024 Washer 5/16 flat stainless steel $1.34 2 ships same day
024 999-0123 Washer 1/4 SAE flat zinc plated $0.99 2 ships same day
025 999-0060 Washer 1/4 split lock plain finish $0.99 2 ships same day
026 999-0019 Bolt 1/4-20 x 5/8 hex head grade 5 zinc plated $0.99 2 ships same day
027 N/A Not available Call for price 2 (Hubcap) usually ships 3-26 days
028 164-0037 Caster wheel $25.97 2 ships same day
029 999-0159 Screw 10-24 x 7/8 round head slotted zinc plated $0.99 2 ships same day
030 999-1104 Screw 10-24 x 3/4 pan head phillips thread rolling zinc $0.99 2 ships same day
032 164-1997 Container handle (for polypropolene tank) $51.23 1 usually ships 1-5 days
033 999-0421 Screw 10-24 x 1/2 flat head phillips zinc plated $0.99 3 ships same day
034 164-2106 Bag instruction decal $9.31 1 usually ships 1-5 days
035 999-0462 Screw 8-32 x 1/2 pan head slotted zinc plated $0.99 1 ships same day
036 999-0150 Washer #8 medium split lock $0.99 1 ships same day
037 164-1809 Plunger pin $30.72 1 usually ships 19-25 days
038 164-1808 Plunger spring $3.20 1 usually ships 19-25 days
