| # | Part | Description |
Req | Notes | Availability |
|---|
201 |
N/A
|
Not available |
1 |
(Cap) |
|
202 |
999-0193
|
Screw 10-24 x 5/8 pan head slotted thread cutting zinc |
4 |
|
|
203 |
N/A
|
Not available |
1 |
(Plate) |
|
204 |
N/A
|
Not available |
3 |
(Female terminal) |
|
205 |
164-8043
|
Vacuum motor |
2 |
|
|
206 |
164-8044
|
Motor gasket |
1 |
|
|
207a |
N/A
|
Not available |
1 |
(Housing) |
|
207b |
N/A
|
Not available |
1 |
(Decal) |
|
207c |
164-1231
|
Pop rivet |
4 |
|
|
207d |
N/A
|
Not available |
2 |
(Latch with keeper) |
|
208 |
N/A
|
Not available |
3 |
(Nut) |
|
209 |
164-0048
|
Filter |
1 |
|
|
210a |
N/A
|
Not available |
1 |
(Canister) |
|
210b |
164-1231
|
Pop rivet |
4 |
|
|
210c |
N/A
|
Not available |
2 |
(Latch with keeper) |
|
211 |
164-4601
|
Screw 1/4 - 3/16 with 10 - 24 thread shoulder |
1 |
|
|
212 |
164-6796
|
Nut 1/4-20 hex thin with nylok insert |
1 |
|
|
213 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
1 |
|
|
214 |
N/A
|
Not available |
1 |
(Plug) |
|
215 |
N/A
|
Not available |
1 |
(Lanyard) |
|
216 |
999-0878
|
Screw 1/4-20 x 1 1/2 truss head slotted stainless steel |
1 |
|
|
217 |
N/A
|
Not available |
1 |
(Decal) |
|
218 |
164-8023
|
Filter cup |
1 |
|
|
