| # | Part | Description |
Req | Notes | Availability |
|---|
009 |
999-0053
|
Washer #10 split lock plain finish |
23 |
|
|
011 |
999-0055
|
Screw 8-32 x 3/4 round head slotted zinc plated |
6 |
|
|
012 |
999-0056
|
Screw 10-32 x 3/8 round head slotted zinc plated |
4 |
|
|
013 |
999-0057
|
Screw 10-32 x 5/8 round head slotted zinc plated |
2 |
|
|
014 |
999-0058
|
Nut 10-32 wing zinc plated |
2 |
|
|
024 |
999-0061
|
Screw 1/4-20 x 5/16 cup point socket set alloy plain finish |
3 |
|
|
030 |
999-0064
|
Screw 10-24 x 7/16 round head slotted zinc plated |
5 |
|
|
037 |
164-6091
|
Hose coupling gasket (for PowerWand hose) |
1 |
|
|
039 |
164-6024
|
Field core and coil assembly |
1 |
|
|
040 |
164-2111
|
M-1 Decal kit (OBSOLETE) |
1 |
|
|
052 |
999-0024
|
Washer 5/16 flat stainless steel |
1 |
|
|
053 |
999-0255
|
Screw 10-24 x 3 1/2 flat head slotted zinc plated |
2 |
|
|
054 |
164-6034
|
Brass eyelet |
2 |
|
|
055 |
164-6035
|
Baffle spacer |
2 |
|
|
056 |
164-6036
|
Tubing |
2 |
|
|
057 |
164-6037
|
Bearing housing |
2 |
|
|
058 |
999-0071
|
Screw 10-24 x 1/2 flat head slotted zinc plated |
8 |
|
|
060 |
164-0040
|
Armature with bearings |
1 |
|
|
061 |
164-6040
|
Bearing |
2 |
|
|
062 |
164-6041
|
Spring washer |
1 |
|
|
063 |
164-6042
|
Flat washer (pkg of 2) |
1 |
|
|
064 |
164-6043
|
Baffle plate |
1 |
|
|
065 |
164-6044
|
Vent fan |
1 |
|
|
066 |
164-0035
|
Suction fan |
1 |
|
|
067 |
164-6045
|
Dust cap |
1 |
|
|
068 |
164-6046
|
End plate |
1 |
|
|
069 |
164-6047
|
Dust spacer tube |
1 |
|
|
070 |
164-6048
|
Safety trap assembly |
1 |
|
|
071 |
999-0234
|
Nut 3/8-16 acorn nickel plated |
1 |
|
|
072 |
999-0201
|
Washer 3/8 internal star lock |
1 |
|
|
073a |
164-3162
|
Electrical caution label |
1 |
|
|
073b |
164-3162
|
Electrical caution label |
1 |
|
|
074 |
164-0037
|
Caster wheel |
2 |
|
|
075 |
164-6053
|
Vinyl bumper |
1 |
|
|
076 |
164-6054
|
Swivel coupling assembly |
1 |
|
|
