| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
164-7461
|
50 ft extension cord with twist lock plug |
1 |
|
|
4 |
164-8305
|
On/off rocker switch |
3 |
|
|
5 |
999-0458
|
Screw 8 x 1/2 pan head phillips T-A sheet metal zinc |
14 |
|
|
6 |
164-8549
|
Switch plate cover |
1 |
|
|
7 |
164-8550
|
Green indicator light |
1 |
|
|
8 |
164-8551
|
Switch/handle decal |
1 |
|
|
9 |
164-8552
|
Patent decal |
1 |
|
|
10 |
164-8553
|
Stallion 12SC decal (OBSOLETE) |
1 |
(OBSOLETE) |
|
11 |
164-8554
|
Handle |
1 |
|
|
13 |
164-8555
|
Serial number cover |
1 |
|
|
14 |
164-8556
|
Vinyl handle grip |
2 |
|
|
15 |
164-8557
|
Momentary toggle switch |
1 |
|
|
16 |
164-8558
|
Toggle boot |
1 |
|
|
17 |
164-8559
|
Handle gasket |
1 |
|
|
18 |
164-8560
|
Handle cover |
1 |
|
|
19 |
164-8561
|
Cord wrap assembly |
1 |
|
|
20 |
164-8562
|
Female 3-C molex |
4 |
|
|
21 |
164-8563
|
Handle-frame wire harness |
1 |
|
|
22 |
164-8564
|
Power cord to switches wire harness |
1 |
|
|
23 |
164-8304
|
Strain relief |
1 |
|
|
25 |
164-8565
|
Circuit breaker reset decal |
1 |
|
|
26 |
164-8566
|
Circuit breaker |
1 |
|
|
27 |
164-8567
|
Circuit breaker flex boot |
1 |
|
|
28 |
164-8568
|
1 inch square closure plug |
1 |
|
|
29 |
164-7462
|
12/3 pigtail cord |
1 |
|
|
30 |
164-8569
|
Equipment info decal |
1 |
|
|
31 |
164-8570
|
Spray switch |
1 |
|
|
