Solution Tank Assembly

#PartDescription ReqNotesAvailability
601 164-1630 Seat 1
602 164-0222 Plug 1
603 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel 4
604 164-9118 P clamp 1
605 999-0152 Nut 1/4-20 nylon insert lock zinc plated 4
606 164-1423 Battery warning decal 1
607 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 2
608 999-0034 Washer 3/8 split lock plain finish 2
609 999-0024 Washer 5/16 flat stainless steel 2
610 164-1633 Clip 1
611 164-1634 Prop rod 1
612 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 2
613 999-0034 Washer 3/8 split lock plain finish 2
614 999-0024 Washer 5/16 flat stainless steel 2
615 164-9016 Filter screen assembly 1
616a 164-9039 Solution tank mounting bracket 1 (before 02.2014)
616b 164-9039 Solution tank mounting bracket 2 (after 02.2014)
617 999-0998 Washer #10 flat stainless steel 1
618 164-9040 Pop rivet (pkg of 5) 1
619 164-7035 Solution gauge 1
620 999-0030 Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated 1
621 999-0024 Washer 5/16 flat stainless steel 2
622 999-0211 Nut 5/16-18 hex nylon insert lock zinc plated 1
623 164-1636 Mounting bracket 1
624 999-0024 Washer 5/16 flat stainless steel 2
625 999-0034 Washer 3/8 split lock plain finish 2
626 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 2
627 164-1639 Battery box 1
628 164-0187 90 degree elbow barb 1
629 164-5073 Cord clamp 1
630a 991-1401 Clear vinyl tubing (sold by the inch) 24 in (before 02.2014)
630b 991-1401 Clear vinyl tubing (sold by the inch) 18 in (after 02.2014)
631 164-0398 Control valve (white clamp) 1
632 999-0024 Washer 5/16 flat stainless steel 2
633 999-0034 Washer 3/8 split lock plain finish 2
634 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 2
635a 164-1435 Solution filter kit 1 (includes 635b and 635c) (before 02.2014)
635b 164-9126 Inline canister strainer 1 (before 02.2014)
635c 164-9128 Strainer element 1 (before 02.2014)
635d 991-6024 Inline canister strainer 1 (before 02.2014)
636 164-1516 Hosebarb with filter fitting 1
637 997-2004 Hose clamp 1
638 164-1514 Hose 1
639 N/A Not available 1 (Cargo net) (before 02.2014)
640 999-0013 Screw 10 x 5/8 pan head phillips sheet metal 4 (before 02.2014)
641 999-0998 Washer #10 flat stainless steel 4 (before 02.2014)
642 164-1642 Side cover 1
643 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel 4
644 999-0160 Washer 1/4 x 1 1/4 fender zinc plated 4
645 164-1517 Solution tank 1
646 164-1643 Solution tank mounting bracket 1
647 999-0024 Washer 5/16 flat stainless steel 1
648 999-0034 Washer 3/8 split lock plain finish 1
649 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 1
650a 999-0024 Washer 5/16 flat stainless steel 1 (before 02.2014)
650b 999-0033 Washer 7/16 SAE flat 1 (after 02.2014)
651 999-0034 Washer 3/8 split lock plain finish 1
652a 999-0116 Bolt 1/2-13 x 1 1/2 hex head grade 5 1 (before 02.2014)
652b 999-0119 Bolt 3/8-16 x 3/4 hex head grade 5 zinc plated 1 (after 02.2014)
653 164-1644 External e-ring 2 (for prop rod)
654 999-0132 Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated 4
655 999-0028 Washer 5/16 split lock plain finish 4
656 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel 4
657a 164-1645 Battery cover 1 (before 02.2014)
657b 164-8055 Battery cover/seat plate 1 (after 02.2014)
658 999-0123 Washer 1/4 SAE flat zinc plated 3
659 999-0017 Washer 1/4 external star lock 3
660 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel 3
661 164-1646 Pop rivet 1
662 164-1631 Seat switch 1
663 164-9181 Washer 1/4 turn nylon 2 (after 02.2014)
664 164-8297 Receptical clip 2 (after 02.2014)
665 999-0015 Nut 1/4-20 k-lock zinc plated 2 (after 02.2014)
666 164-1757 Wiring assembly (battery to machine control) 1 (after 02.2014)
667 164-9180 Corner plate 1 (after 02.2014)
668 164-8296 Quarter turn wings 2 (after 02.2014)
669 164-1636 Mounting bracket 1 (after 02.2014)
