| # | Part | Description | Price | Req | Notes | Availability |
|---|
000 |
N/A
|
Not available |
Call for price
|
1 |
Not available - Wire harness |
usually ships 3-26 days |
011 |
164-1189
|
Wire assembly (connector to battery) |
$73.21
|
1 |
|
usually ships 19-25 days |
012 |
N/A
|
Not available |
Call for price
|
1 |
Not available - Wire assembly, charge plug to standoff / solenoid or key switch |
usually ships 3-26 days |
097a |
998-0010
|
Battery jumper cable - ring type (red) |
$6.06
|
3 |
(For use with top, bolt type post batteries) |
ships same day |
097c |
164-0290
|
Toggle switch |
$14.63
|
1 |
|
ships same day |
097d |
164-0001
|
Master switch |
$28.20
|
1 |
|
usually ships 19-25 days |
097e |
172-2039
|
5K potentiometer |
$63.07
|
1 |
|
ships same day |
097f |
164-0310
|
Insulated stand off |
$13.66
|
1 |
|
usually ships 19-25 days |
097g |
164-0889
|
Battery meter |
$157.51
|
1 |
|
usually ships 19-25 days |
097h |
164-0834
|
24V brush gear motor assembly |
$1,698.80
|
1 |
|
usually ships 1-5 days |
097i |
164-2495
|
Solenoid valve |
$176.87
|
1 |
|
ships same day |
097j |
164-0892
|
24V solenoid contactor |
$96.03
|
1 |
|
ships same day |
097k |
164-1451
|
Hour meter |
$133.54
|
1 |
|
usually ships 19-25 days |
097l |
164-2469
|
Control WR20B panel |
$300.08
|
1 |
|
usually ships 1-5 days |
097m |
991-1609
|
25amp circuit breaker |
$66.55
|
1 |
|
usually ships 19-25 days |
097n |
991-1610
|
15amp circuit breaker |
$69.23
|
1 |
|
usually ships 19-25 days |
097o |
991-1618
|
30amp circuit breaker |
$82.69
|
1 |
|
usually ships 19-25 days |
097p |
164-4644
|
Female terminal |
$3.72
|
2 |
|
usually ships 19-25 days |
097q |
164-0553
|
Male push on coupler |
$3.20
|
2 |
|
ships same day |
097r |
991-2103
|
50amp charger plug SB50 with pins (red) |
$7.19
|
1 |
|
ships same day |
097s |
991-1210
|
24V 3 stage vacuum motor tangential |
$119.97
|
1 |
|
ships same day |
097t |
164-0895
|
24V Curtis speed control for Wrangler 26 |
$563.44
|
1 |
|
usually ships 19-25 days |
097u |
164-0847
|
24 inch transaxle assembly (old style)(OBSOLETE) |
$1,000.89
|
1 |
For use on machines built before 5.4.00, for machines built after use 164-7287 |
usually ships 19-25 days |
097v |
164-8120
|
Transaxle with wheels kit |
$2,202.28
|
1 |
for use on machines built after 5.4.00, for machines built before use 164-0847 |
usually ships 19-25 days |
097w |
164-2548
|
2016 Solenoid jumper wire (OBSOLETE) |
$8.58
|
1 |
|
usually ships 1-5 days |
097x |
991-6025
|
Wire 4 x14.5, 3/8 ring x 3/8 ring |
$16.98
|
1 |
(NON-OEM) |
usually ships 18-24 days |
