| # | Part | Description |
Req | Notes | Availability |
|---|
601a |
164-1664
|
Control panel decal |
1 |
|
|
601b |
164-1650
|
Electrical panel decal |
1 |
|
|
602 |
164-0287
|
Rubber switch boot |
4 |
|
|
603 |
164-1629
|
Nut 5/8 hex (large nut) (OBSOLETE) |
8 |
|
|
604 |
999-0260
|
Washer 1/2 internal starlock |
4 |
|
|
605 |
999-0024
|
Washer 5/16 flat stainless steel |
4 |
|
|
606 |
164-2024
|
Emergency stop |
1 |
|
|
607 |
164-2025
|
Emergency stop block (red button) |
1 |
(for use with Curtis Control Board 164-0070) |
|
608 |
999-0016
|
Washer 1/4 flat plain finish |
11 |
|
|
609 |
999-0017
|
Washer 1/4 external star lock |
17 |
|
|
610 |
999-0567
|
Screw 1/4-20 x 5/8 pan head phillips stainless steel |
15 |
|
|
611 |
999-0223
|
Screw 10-24 x 1 1/4 round head slotted zinc plated |
2 |
|
|
612 |
999-0311
|
Washer #10 external star lock zinc plated |
2 |
|
|
613 |
164-1651
|
Control panel weldment |
1 |
|
|
614 |
164-1354
|
Machine controller (OBSOLETE) |
1 |
|
|
615 |
999-0006
|
Washer 3/16 flat zinc plated |
2 |
|
|
616 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
2 |
|
|
617b |
164-9051
|
Cloud burst decal (OBSOLETE) |
1 |
|
|
618 |
164-1517
|
Solution tank |
1 |
|
|
619 |
164-1653
|
Panel |
1 |
|
|
623 |
164-1654
|
Champ color label kit (OBSOLETE) |
1 |
|
|
626 |
164-1655
|
Circuit breaker panel |
1 |
|
|
627 |
164-1656
|
Back-up alarm |
1 |
|
|
628 |
991-1615
|
90amp circuit breaker |
1 |
|
|
629 |
991-1608
|
2amp circuit breaker |
2 |
|
|
630 |
164-1657
|
Plug |
1 |
|
|
631 |
164-1658
|
Ground wire |
1 |
|
|
632 |
164-1659
|
Bolt M6 x 12.7mm hex head |
2 |
|
|
634 |
164-2000
|
Forward/reverse switch (6 prong) |
2 |
|
|
635 |
164-0023
|
Toggle switch |
2 |
|
|
636 |
164-1660
|
Key switch and key |
1 |
|
|
637 |
164-1661
|
Key (pkg of 2) (OBSOLETE) |
1 |
|
|
638 |
164-1662
|
Push button switch |
1 |
|
|
639 |
164-1663
|
LCD module |
1 |
|
|
