| # | Part | Description | Price | Req | Notes | Availability |
|---|
401 |
999-0691
|
Bolt 1/2-13 x 2 1/4 hex head grade 5 |
$1.50
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
402 |
164-0234
|
Bushing |
$11.22
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
403 |
164-0235
|
Squeegee pivot bracket |
$127.00
|
1 |
|
usually ships 8-23 days |
404 |
999-0632
|
Washer 1/4 split lock stainless steel |
$0.99
|
4 |
|
ships same day |
405 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
$3.85
|
4 |
|
ships same day |
406 |
999-0187
|
Washer 1/2 flat plain finish |
$0.99
|
1 |
|
ships same day |
407 |
999-0262
|
Nut 1/2-13 nylon insert jam lock zinc plated |
$0.99
|
1 |
|
ships same day |
408 |
164-0237
|
Squeegee pivot spacer |
$7.65
|
1 |
(new pivot rod and narrow squeegee mount) |
usually ships 8-23 days |
409 |
164-0238
|
Ball joint |
$50.71
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
410 |
164-0239
|
Squeegee lift bracket |
$146.69
|
1 |
|
usually ships 8-23 days |
411 |
164-0240
|
Squeegee adjustment spring |
$11.88
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
412 |
999-0513
|
Nut 3/8-16 nylon insert lock type NE stainless steel |
$3.96
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
413 |
999-0659
|
Washer 3/8 medium split lock stainless steel |
$0.39
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
414 |
999-0658
|
Screw 3/8-16 x 2 round head slotted stainless steel |
$3.08
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
415 |
999-0547
|
Bolt 5/16-18 x 1/2 hex head stainless steel |
$0.99
|
2 |
|
ships same day |
416 |
999-0548
|
Washer 5/16 external star lock stainless steel |
$0.99
|
2 |
|
ships same day |
417 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
418 |
991-2009
|
3 inch bumper wheel |
$7.50
|
2 |
|
usually ships 7-17 days |
419a |
164-0243
|
Squeegee weldment (narrow mount) |
$379.28
|
1 |
(Wrangler 27) |
usually ships 8-23 days |
419b |
164-0247
|
Squeegee assembly (narrow mount) |
$947.12
|
1 |
(Wrangler 27) (includes 415-428) |
ships same day |
419c |
164-0244
|
Squeegee housing (wide mount) (OBSOLETE) |
$326.10
|
1 |
(Wrangler 27) |
usually ships 1-5 days |
419d |
164-0248
|
Squeegee assembly (wide mount) (OBSOLETE) |
$724.85
|
1 |
(Wrangler 27) (includes 415-428) |
usually ships 1-5 days |
419e |
164-0245
|
Squeegee weldment (narrow mount) |
$414.26
|
1 |
(Wrangler 33) |
usually ships 8-23 days |
419f |
164-1098
|
Squeegee assembly (narrow mount) heavy duty |
$895.57
|
1 |
(Wrangler 33) (includes 415-428) |
usually ships 8-23 days |
419g |
164-0246
|
Squeegee housing (wide mount) (OBSOLETE) |
$290.46
|
1 |
(Wrangler 33) |
usually ships 1-5 days |
419h |
N/A
|
Not available |
Call for price
|
1 |
(Old pivot rod and wide squeegee mount) (Wrangler 33) |
usually ships 3-26 days |
420a |
164-0041
|
Squeegee blade 32 inch linatex kit (red) (front and rear) |
$216.95
|
1 |
(Wrangler 27) |
ships same day |
420b |
164-0042
|
Squeegee blade 38 inch linatex kit (red) (front and rear) |
$268.39
|
1 |
(Wrangler 33) |
ships same day |
421a |
164-0250
|
Inner channel for Wrangler 26 and 2625 |
$73.24
|
1 |
|
usually ships 8-23 days |
421b |
164-0251
|
Inner channel for Wrangler 27 and 33 |
$68.60
|
1 |
|
usually ships 8-23 days |
422 |
999-0641
|
Screw 5/16-18 x 3/4 socket head stainless steel |
$1.19
|
4 |
|
ships same day |
423 |
999-0131
|
Screw 5/16-18 x 1 1/2 socket head stainless steel |
$2.86
|
2 |
|
ships same day |
424 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
2 |
|
ships same day |
425 |
991-2005
|
Small roller wheel (gray) |
$13.86
|
2 |
|
usually ships 7-17 days |
426 |
999-0108
|
Bolt 5/16-18 x 1 3/4 hex head grade 5 zinc plated |
$0.99
|
2 |
|
ships same day |
427 |
164-1565
|
Knob |
$21.84
|
2 |
|
usually ships 8-23 days |
428 |
164-0254
|
Squeegee bracket (narrow mount) |
$93.94
|
1 |
(new pivot rod and narrow squeegee mount) |
usually ships 8-23 days |
429 |
999-0550
|
Bolt 3/8-16 x 2 hex head stainless steel |
$2.95
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
430 |
999-0660
|
Nut 3/8-16 wing stainless steel |
$2.93
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
431 |
164-0256
|
Squeegee pivot rod |
$69.03
|
1 |
(new pivot rod and narrow squeegee mount) |
usually ships 8-23 days |
432 |
999-0661
|
Bolt 1/2-20 x 1 18-8 hex head stainless steel |
$3.96
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
433 |
999-0560
|
Washer 1/2 lock stainless steel |
$0.99
|
1 |
(new pivot rod and narrow squeegee mount) |
ships same day |
434 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
435 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
2 |
|
ships same day |
437a |
164-0089
|
Squeegee vacuum hose with cuffs |
$47.80
|
1 |
|
ships same day |
437b |
991-8568
|
Squeegee vacuum hose |
$43.73
|
1 |
|
ships same day |
437c |
991-1904
|
Squeegee vacuum hose with straight cuffs |
$38.96
|
1 |
(NON-OEM) |
ships same day |
438 |
164-0859
|
Squeegee shaft |
$33.84
|
1 |
(old pivot rod and wide squeegee mount) (use 999-0661 and 999-0560 to bolt it on) |
ships same day |
439 |
164-1565
|
Knob |
$21.84
|
1 |
(old pivot rod and wide squeegee mount) |
usually ships 8-23 days |
440 |
164-0260
|
Squeegee bracket (wide mount) |
$126.72
|
1 |
(old pivot rod and wide squeegee mount) |
usually ships 8-23 days |
441 |
164-0257
|
Squeegee pivot rod assembly (OBSOLETE) |
$203.78
|
1 |
(new pivot rod and narrow squeegee mount) (includes 401-414 and 428-436) |
usually ships 1-5 days |
