| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
162-5149
|
Summit II 24V 40amp battery charger SB175 large gray plug |
|
|
|
002 |
159-0121
|
Handle frame (reinforced) |
|
|
|
003 |
159-0122
|
Handle spring |
|
|
|
004 |
159-0123
|
Roll pin |
|
|
|
005 |
159-0124
|
Cam |
|
|
|
006 |
159-0087
|
Roll pin |
|
|
|
007 |
159-0013
|
Roll pin |
|
|
|
008 |
159-0125
|
Control lever |
|
|
|
009 |
159-0120
|
Handle assembly (reinforced) |
|
|
|
010 |
159-0127
|
Master link |
|
|
|
011 |
159-0128
|
Chain connector |
|
|
|
012 |
999-0248
|
Bolt M8-1.25 x 30mm hex head full thread plain finish |
|
|
|
013 |
999-0028
|
Washer 5/16 split lock plain finish |
|
|
|
014 |
159-0131
|
Roll pin |
|
|
|
015 |
159-0132
|
Rubber cushion |
|
|
|
