| # | Part | Description |
Req | Notes | Availability |
|---|
10 |
373-1705
|
Contact pressure wheel |
1 |
|
|
20 |
373-1706
|
Deflector roll |
1 |
|
|
30 |
373-1707
|
Retainer |
1 |
|
|
40a |
373-1760
|
Disc brush (red) |
1 |
|
|
40b |
373-1761
|
Disc brush (black) |
1 |
|
|
40c |
373-1762
|
Disc brush (nature) |
1 |
|
|
40d |
373-1763
|
Disc brush (white) |
1 |
|
|
50 |
373-1708
|
Bracket |
1 |
|
|
60 |
373-1709
|
Pipe clamp |
2 |
|
|
70a |
273-3646
|
Covering cap |
1 |
(machines with solenoid valve) |
|
70b |
273-3646
|
Covering cap |
1 |
(machines without solenoid valve) |
|
80 |
373-1711
|
Threaded plate |
1 |
|
|
90 |
373-1712
|
Hose clip |
1 |
|
|
100 |
373-1713
|
Extension spring |
1 |
|
|
110 |
273-3647
|
Splash proof profile |
1 |
|
|
120 |
183-0075
|
Screw 5-16 x 10.9mm |
2 |
|
|
130 |
173-6202
|
Screw M5 x 20mm |
9 |
|
|
140 |
373-1714
|
Deflector roll |
1 |
|
|
150 |
373-1666
|
Screw M8 x 35mm |
9 |
|
|
160 |
999-1261
|
Washer M6 flat stainless steel |
8 |
|
|
170 |
373-1716
|
Screw M6 x 20mm |
8 |
|
|
180 |
273-8159
|
Screw M8 x 16 hex head |
1 |
|
|
190 |
373-1717
|
Washer |
2 |
|
|
200 |
173-9870
|
Washer #8 |
1 |
|
|
210 |
373-1718
|
Seal |
1 |
|
|
220 |
373-1719
|
Rubber stopper |
1 |
|
|
300 |
373-1720
|
Pad driver |
1 |
|
|
