| # | Part | Description |
Req | Notes | Availability |
|---|
10a |
373-1645
|
Solution tank |
1 |
(machines without solenoid valve) |
|
10b |
373-1646
|
Solution tank |
1 |
(machines with solenoid valve) |
|
20 |
373-1647
|
Recovery tank |
1 |
|
|
30 |
373-1648
|
Cap |
1 |
|
|
40 |
373-1649
|
Elbow |
2 |
|
|
50 |
373-1650
|
Level indicator hose |
1 |
|
|
55 |
373-1651
|
Level indicator sphere |
1 |
|
|
60 |
373-1652
|
Wire protection sleeve |
2 |
|
|
70 |
273-0815
|
Float regulator |
1 |
|
|
80 |
373-1653
|
Seal |
1 |
|
|
90 |
373-1654
|
Cover |
1 |
|
|
100 |
273-3593
|
Solution cap |
1 |
|
|
110 |
273-3594
|
Gasket |
1 |
|
|
130 |
373-1655
|
Cap |
1 |
|
|
140 |
273-8805
|
Drain hose |
1 |
|
|
150 |
373-1657
|
Rope |
1 |
|
|
170 |
373-1659
|
Cable support |
1 |
|
|
180 |
373-1660
|
Divider |
1 |
|
|
190 |
273-8804
|
Suction hose |
1 |
|
|
210 |
373-1662
|
Decal |
1 |
|
|
220 |
373-1663
|
Gasket |
1 |
|
|
230 |
997-2006
|
Hose clamp |
1 |
|
|
260 |
373-1667
|
Seal |
1 |
|
|
290 |
373-1671
|
Sealing tape |
1 |
|
|
310 |
373-1673
|
Retaining plate |
1 |
|
|
320 |
173-3002
|
Hose clip |
1 |
|
|
