| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
154-9240
|
Cord 14/2 x 50 feet |
1 |
|
|
2 |
154-9241
|
Float seal |
1 |
|
|
3 |
154-9242
|
Screw M8 x 30mm |
1 |
|
|
5 |
154-9244
|
Cable grip |
1 |
|
|
8 |
154-9247
|
Vacuum motor gasket |
1 |
|
|
11 |
154-9250
|
M6 rubber washer |
1 |
|
|
12 |
154-9251
|
M8 washer |
1 |
|
|
13 |
154-9252
|
Self tapping screw M2.9 x 19 |
2 |
|
|
14 |
154-9253
|
Self tapping screw M3.5 x 13 |
1 |
|
|
17 |
154-9256
|
M8 thumb screw |
1 |
|
|
20 |
154-9259
|
Motor gasket |
1 |
|
|
21 |
154-9260
|
Screw cover |
1 |
|
|
23 |
154-9262
|
Filter button rod |
1 |
|
|
24 |
154-9263
|
Filter button |
1 |
|
|
25 |
154-9264
|
Handle |
1 |
|
|
26 |
154-9265
|
Head base |
1 |
|
|
27 |
154-9266
|
Filter ring |
1 |
|
|
28 |
154-9267
|
Head cover |
1 |
|
|
29 |
154-9268
|
Filter bottom |
1 |
|
|
30a |
154-3715
|
Filter cartridge |
1 |
|
|
30b |
154-9269
|
Hepa cartridge filter |
1 |
|
|
32 |
154-9271
|
Head cover gasket |
1 |
|
|
33 |
154-9272
|
Head base gasket |
6 |
|
|
35 |
154-9274
|
D30 compression spring |
1 |
|
|
