| # | Part | Description |
Req | Notes | Availability |
|---|
601 |
999-0566
|
Washer 1/2 flat nylon |
2 |
|
|
602a |
154-2431
|
Vacuum hose |
1 |
(standard model) |
|
602b |
154-2432
|
Vacuum hose (OBSOLETE) |
1 |
(low profile model) |
|
603a |
154-2433
|
Suction hose (OBSOLETE) |
1 |
(standard model) |
|
603b |
154-2434
|
Suction hose (OBSOLETE) |
1 |
(low profile model) |
|
604a |
154-2102
|
Drain hose (clear) |
1 |
(standard model) |
|
604b |
154-2435
|
Drain hose (OBSOLETE) |
1 |
(low profile model) |
|
605 |
154-1279
|
Clamp |
4 |
|
|
606 |
154-2436
|
Arm (OBSOLETE) |
1 |
|
|
607 |
154-2437
|
Clevis pin |
1 |
|
|
608a |
154-1207
|
Cotter pin |
1 |
(standard model) |
|
608b |
170-3541
|
Cotter pin |
1 |
(low profile model) |
|
609 |
154-2438
|
Hose plug (OBSOLETE) |
1 |
|
|
610a |
154-2439
|
Tank assembly (OBSOLETE) |
1 |
(standard model) |
|
610b |
154-2440
|
Tank assembly (OBSOLETE) |
1 |
(low profile model) |
|
611a |
154-2441
|
Frame assembly (OBSOLETE) |
1 |
(standard model) |
|
611b |
154-2442
|
Frame assembly (OBSOLETE) |
1 |
(low profile model) |
|
612 |
154-2443
|
Squeegee lift assembly (OBSOLETE) |
1 |
|
|
613 |
154-2444
|
26 inch squeegee assembly |
1 |
|
|
614 |
154-2445
|
Hose with swivel cuff (OBSOLETE) |
1 |
|
|
615 |
154-2446
|
Wand (OBSOLETE) |
1 |
|
|
616 |
154-2447
|
Wand squeegee (OBSOLETE) |
1 |
|
|
617 |
154-2448
|
Wand kit (OBSOLETE) |
1 |
(includes 614-616) |
|
618 |
154-2449
|
24 inch squeegee assembly (OBSOLETE) |
1 |
|
|
