| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
154-0316
|
Bail |
1 |
|
|
2 |
154-0541
|
Throttle control cable |
1 |
|
|
3 |
999-0576
|
Screw 8-18 x 1/2 pan head phillips self-drilling ss |
5 |
|
|
4 |
154-9028
|
Guide |
1 |
|
|
5 |
154-0640
|
Bushing |
1 |
|
|
6 |
999-0006
|
Washer 3/16 flat zinc plated |
2 |
|
|
7 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
1 |
|
|
8 |
999-1547
|
Screw 10-24 x 7/8 button head socket stainless steel |
1 |
|
|
9 |
154-2363
|
Bulkhead hood assembly |
1 |
|
|
10 |
154-0401
|
Foam seal |
1 |
|
|
11 |
154-2368
|
Air filter |
1 |
|
|
12 |
991-6001
|
Fuel regulator (T60) |
1 |
|
|
13 |
154-0168
|
Fuel adjustment |
1 |
|
|
14 |
154-0228
|
Hosebarb 1/8 x 1/4 inch |
1 |
|
|
15 |
154-2051
|
Extension fitting |
1 |
|
|
16 |
991-6002
|
12V fuel lock off (Model 152) |
1 |
|
|
17 |
154-0066
|
Fitting 49 x 6 (regulator to fuel lock) |
1 |
|
|
18 |
154-0348
|
90 degree elbow fitting |
1 |
|
|
19 |
154-2348
|
Brass fitting |
1 |
|
|
N/S |
154-2371
|
Micro switch |
1 |
|
|
