Final Squeegee Lift Assembly

#PartDescription ReqNotesAvailability
1 154-2657 Squeegee lift assembly (OBSOLETE) 1
2 999-1537 Bolt 1/2-13 x 8 hex head grade 5 1
3 999-0559 Washer 1/2 x 1/4 flat stainless steel 1
4 999-0050 Nut 1/2-13 hex jam plain finish 1
5 154-1241 Extension spring 1
6 154-2659 Frame assembly (OBSOLETE) 1
