| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
154-1247
|
Valve mounting bracket (OBSOLETE) |
1 |
|
|
2 |
154-1248
|
2 way ball valve |
1 |
|
|
3 |
154-1249
|
Solution filter (OBSOLETE) |
1 |
|
|
4 |
154-1250
|
Elbow fitting |
1 |
|
|
5 |
154-1251
|
Adapter fitting |
1 |
|
|
6 |
154-1252
|
Bolt M5 x 18mm hex with spring washer |
1 |
|
|
7 |
154-2024
|
Hitch pin retainer |
1 |
|
|
8 |
154-1253
|
Flanged nut |
1 |
|
|
9 |
154-1222
|
Hose clamp |
3 |
|
|
10 |
154-1254
|
Hose (OBSOLETE) |
1 |
(valve to valve) |
|
11 |
154-1255
|
Hose (OBSOLETE) |
1 |
(solution tank to valve) |
|
12 |
154-1256
|
Hose clamp |
2 |
|
|
13 |
154-1257
|
Deltrol dispensing valve |
1 |
|
|
14 |
999-1099
|
Bolt 1/4-20 x 3/4 hex head stainless steel |
2 |
|
|
15 |
154-0600
|
Lock washer |
4 |
|
|
16 |
999-0609
|
Nut 1/4-20 hex stainless steel |
2 |
|
|
17 |
999-0019
|
Bolt 1/4-20 x 5/8 hex head grade 5 zinc plated |
2 |
|
|
18 |
999-0333
|
Screw 10-24 x 1/2 pan head phillips stainless steel |
2 |
|
|
