| # | Part | Description |
Req | Notes | Availability |
|---|
012 |
N/A
|
Not available |
1 |
Rubber skirt |
|
013 |
154-0587
|
Brush cover |
1 |
|
|
015a |
154-0573
|
17 inch Pad driver |
|
|
|
015b |
154-1026
|
Pad bracket |
|
|
|
015c |
999-0024
|
Washer 5/16 flat stainless steel |
4 |
|
|
015d |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
4 |
|
|
015e |
999-1835
|
Screw 5/16-18 x 1 1/4 flat head phillips zinc plated |
4 |
|
|
034 |
154-3493
|
Wheel |
2 |
|
|
040 |
154-3452
|
Side band |
2 |
|
|
042 |
154-1011
|
Front caster |
2 |
|
|
053 |
154-0590
|
Pin |
|
|
|
055 |
154-0574
|
Lock lever (OBSOLETE) |
|
|
|
065 |
N/A
|
Not available |
1 |
Battery tray |
|
N/S |
154-0558
|
17 inch Nylogrit brush kit (OBSOLETE) |
|
|
|
