| # | Part | Description |
Req | Notes | Availability |
|---|
200 |
154-0637
|
Handle 110V (OBSOLETE) |
1 |
110V start |
|
201 |
999-1543
|
Screw 10-24 x 3/4 button head socket zinc plated |
1 |
|
|
202 |
999-0006
|
Washer 3/16 flat zinc plated |
2 |
|
|
203 |
154-0640
|
Bushing |
1 |
|
|
204 |
154-0541
|
Throttle control cable |
1 |
|
|
205 |
154-0641
|
Throttle bail (OBSOLETE) |
1 |
|
|
206 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
1 |
|
|
207 |
999-0233
|
Screw 8 x 1 1/4 hex washer head slotted zinc plated |
4 |
|
|
208a |
154-2329
|
Handle grip |
2 |
|
|
208b |
991-8571
|
Handle grip |
2 |
(NON-OEM) |
|
209 |
154-0643
|
Mount plate (OBSOLETE) |
1 |
|
|
210 |
154-0644
|
Clevis pin 1/4 x 2 1/2 (OBSOLETE) |
1 |
|
|
211 |
999-0016
|
Washer 1/4 flat plain finish |
2 |
|
|
212 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
3 |
|
|
213a |
154-0077
|
Handle grip |
2 |
Models w/o clutch |
|
213b |
154-0645
|
Foam handle grip (OBSOLETE) |
2 |
models with clutch |
|
213c |
991-8571
|
Handle grip |
2 |
(NON-OEM) (models w/o clutch) |
|
214 |
154-0646
|
Cotter pin |
1 |
|
|
215 |
999-0229
|
Screw 1/4-20 x 1 button head socket plain finish |
1 |
|
|
216 |
154-0149
|
Throttle knob |
1 |
|
|
217 |
999-0576
|
Screw 8-18 x 1/2 pan head phillips self-drilling ss |
2 |
|
|
218 |
154-0647
|
Handle 12V (OBSOLETE) |
1 |
12V start |
|
219 |
999-0024
|
Washer 5/16 flat stainless steel |
1 |
110V models |
|
220 |
154-0071
|
Adjustable handle lever |
1 |
|
|
221 |
999-0234
|
Nut 3/8-16 acorn nickel plated |
1 |
|
|
222 |
999-0032
|
Washer 3/8 USS flat plain finish |
1 |
|
|
223 |
154-0648
|
Handle complete 110V (OBSOLETE) |
1 |
110V models |
|
224 |
999-0242
|
Screw 3/8-16 x 4 carriage head grade 5 zinc |
2 |
|
|
225 |
160-0006
|
48 inch throttle control cable |
1 |
|
|
230 |
999-0238
|
Washer 1/4 internal star lock zinc plated |
2 |
|
|
231 |
999-0113
|
Screw 1/4-20 x 1/2 truss head slotted |
2 |
|
|
232 |
154-0649
|
Nut 10-24 spin lock |
4 |
|
|
233 |
154-1039
|
Tank strap |
1 |
|
|
234 |
154-0650
|
Handle assembly 110V (OBSOLETE) |
1 |
100V models |
|
237 |
992-0001
|
Velcro loop (sold by the inch) |
1 |
|
|
238 |
999-0188
|
Nut 3/8-16 nylon insert lock zinc plated |
5 |
|
|
239 |
999-0232
|
Screw 3/8-16 x 1 1/4 carriage head grade 5 zinc |
5 |
|
|
240 |
154-0328
|
Footman loop |
2 |
|
|
241 |
154-0651
|
Socket screw 10-24 x 3/4 |
4 |
|
|
244a |
161-0003
|
Aluminum propane tank |
1 |
|
|
244b |
154-1065
|
Steel propane tank |
1 |
|
|
245 |
999-0249
|
Screw 6-32 x 5/8 round head slotted zinc plated |
1 |
|
|
246 |
154-0039
|
Spring clip |
1 |
|
|
247 |
999-0144
|
Nut 6-32 k-lock zinc plated |
1 |
|
|
N/S |
991-6001
|
Fuel regulator (T60) |
1 |
(NON-OEM) |
|
N/S |
154-1075
|
Fuel regulator |
1 |
|
|
