| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
151-0179
|
Steer wheel assembly |
|
|
|
001b |
151-0180
|
Steer wheel assembly (poly) |
|
|
|
001c |
151-0181
|
Steer wheel assembly (nylon) |
|
|
|
001d |
151-0182
|
Steer wheel assembly (steel) |
|
|
|
002 |
151-0183
|
Snap ring |
|
|
|
003 |
151-5026
|
Ball bearing |
|
|
|
004 |
151-0184
|
Washer |
|
|
|
005 |
151-0185
|
Steer wheel axle 25mm |
|
|
|
006 |
151-0186
|
Hub cap |
|
|
|
007 |
151-0300
|
Pump piston assembly |
|
|
|
008 |
151-0188
|
Spring |
|
|
|
009 |
151-5020
|
Scraper |
|
|
|
010 |
151-5039
|
U-cup |
|
|
|
011 |
151-0189
|
Sleeve |
|
|
|
012 |
151-0190
|
Split pin |
|
|
|
013 |
151-0191
|
Ball |
|
|
|
014 |
151-0192
|
Valve |
|
|
|
015 |
151-5008
|
Roll pin |
|
|
|
016 |
151-0193
|
Screw plug |
|
|
|
017 |
151-0194
|
O-ring |
|
|
|
018 |
151-0195
|
Spring |
|
|
|
019 |
151-0196
|
Handle cap |
|
|
|
020 |
151-0194
|
O-ring |
|
|
|
021 |
151-0197
|
Control lever |
|
|
|
022 |
151-5009
|
Roll pin |
|
|
|
023 |
151-0198
|
Control rod |
|
|
|
024 |
151-0199
|
Hex head nut stainless steel |
|
|
|
025 |
151-0210
|
Chain |
|
|
|
026 |
151-0211
|
Lower control rod |
|
|
|
027 |
151-0211
|
Lower control rod |
|
|
|
028 |
151-0212
|
Adjusting nut |
|
|
|
029 |
151-5010
|
Roll pin |
|
|
|
030 |
151-0213
|
Roller |
|
|
|
031a |
151-0127
|
Flat washer #10 stainless steel |
|
|
|
031b |
151-0128
|
Traverse |
|
|
|
032a |
151-0124
|
Bushing |
|
|
|
032b |
151-0215
|
Bushing (used with 151-0214) |
|
|
|
034 |
151-0216
|
Pin |
|
|
|
035 |
151-0217
|
Spring |
|
|
|
036 |
151-0218
|
Spacer |
|
|
|
037 |
151-5011
|
Roll pin |
|
|
|
038 |
151-0219
|
Release lever |
|
|
|
039 |
151-5012
|
Roll pin |
|
|
|
040a |
151-0220
|
Heavy duty thrust bearing |
|
|
|
040b |
151-0221
|
Thrust bearing |
|
|
|
041 |
151-0222
|
Snap ring |
|
|
|
042 |
151-0184
|
Washer |
|
|
|
043a |
151-0223
|
Steer wheel assembly ultra poly |
|
|
|
043b |
151-0224
|
Steer wheel assembly polypropylene |
|
|
|
043c |
151-0225
|
Steer wheel assembly nylon |
|
|
|
044 |
151-0185
|
Steer wheel axle 25mm |
|
|
|
045a |
151-0191
|
Ball |
|
|
|
045b |
151-0226
|
Ball |
|
|
|
046b |
151-0227
|
Three port lever nut |
|
|
|
047a |
151-0228
|
Flanged bearing |
|
|
|
047b |
151-0229
|
Roller bearing |
|
|
|
048 |
151-5021
|
O-Ring |
|
|
|
049 |
151-5030
|
Release pin |
|
|
|
051 |
151-0231
|
Screw |
|
|
|
052 |
151-0232
|
Washer |
|
|
|
053 |
151-0233
|
Spring |
|
|
|
054 |
151-0234
|
Ball |
|
|
|
055 |
151-5029
|
Spring |
|
|
|
056 |
151-0235
|
Washer |
|
|
|
057 |
151-0236
|
Five port lever nut |
|
|
|
058 |
151-0237
|
U-cup |
|
|
|
059 |
151-5038
|
U-cup |
|
|
|
060 |
151-5019
|
Scraper |
|
|
|
061 |
151-0238
|
Ram |
|
|
|
062 |
151-0239
|
Ball |
|
|
|
063 |
N/A
|
Not available |
|
|
|
064 |
151-0240
|
Bolt |
|
|
|
065 |
151-0241
|
Washer |
|
|
|
066 |
151-0242
|
Drain hose clip cover |
|
|
|
067 |
151-0243
|
Washer |
|
|
|
KIT |
151-0244
|
Super seal kit |
|
|
|
KIT |
151-0246
|
Ball and valve kit |
|
|
|
KIT |
151-0245
|
Complete seal kit |
|
|
|
