| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
151-0122
|
1/4 inch duct gasket lid |
|
|
|
002 |
151-0123
|
Lock washer |
|
|
|
003 |
151-0124
|
Bushing |
|
|
|
004a |
151-0125
|
Lifting link 20 1/2 wide jack |
|
|
|
004b |
151-0126
|
Lifting link 27 inch wide jack |
|
|
|
005 |
151-0127
|
Flat washer #10 stainless steel |
|
|
|
006 |
151-0124
|
Bushing |
|
|
|
007 |
151-0128
|
Traverse |
|
|
|
008 |
151-0129
|
Pin |
|
|
|
009 |
151-0130
|
5 inch flag center wire (black) |
|
|
|
010a |
151-0131
|
Eye bolt fine thread with bushings |
|
|
|
010b |
151-0132
|
Eye bolt coarse thread with bushings |
|
|
|
011 |
151-0133
|
Bushing |
|
|
|
012a |
151-0134
|
Nut fine thread |
|
|
|
012b |
151-0135
|
Nut coarse thread |
|
|
|
013a |
151-0136
|
Push rod 36 inch forks fine thread |
|
|
|
013b |
151-0137
|
Push rod 42 inch forks fine thread |
|
|
|
013c |
151-5028
|
Push rod (OBSOLETE) |
|
|
|
014 |
151-0138
|
Exit roller |
|
|
|
015 |
151-0139
|
Pivot axle |
|
|
|
016 |
151-5014
|
Roll pin |
|
|
|
017 |
151-0140
|
Load roller brackets |
|
|
|
018 |
151-5032
|
Roller Axle includes bolt, sleeve, nut |
|
|
|
019 |
151-0141
|
Washer |
|
|
|
020 |
151-5035
|
Space Washer |
|
|
|
021a |
N/A
|
Not available |
|
|
|
021b |
N/A
|
Not available |
|
|
|
022 |
151-0142
|
Bearing |
|
|
|
023a |
151-5006
|
Super load roller assembly |
|
|
|
023b |
151-0143
|
Load roller assembly ultra poly 3 inch dia |
|
|
|
023c |
151-0144
|
Super load roller assembly poly 3 inch diameter |
|
|
|
023d |
151-0145
|
Load roller poly 3 inch diameter |
|
|
|
023e |
151-0146
|
Load roller assembly nylon 3 inch diameter |
|
|
|
023f |
151-0147
|
Load roller nylon 3 inch diameter |
|
|
|
023g |
151-0148
|
Load roller assembly steel 3 inch diameter |
|
|
|
023h |
151-0149
|
Load roller steel 3 inch diameter |
|
|
|
024 |
151-0150
|
Nut |
|
|
|
025 |
151-5022
|
Lifting link pin |
|
|
|
026 |
151-0151
|
Nut old style |
|
|
|
027a |
151-0152
|
Entry roller 1 7/16 inch diameter |
|
|
|
027b |
151-0153
|
Entry roller 1 15/16 inch |
|
|
|
028a |
151-0154
|
Bolt old style |
|
|
|
028b |
151-0155
|
Nut bolt and sleeve assembly new style |
|
|
|
029 |
151-0156
|
Lifting link 27 inch wide jack |
|
|
|
030 |
151-0157
|
Traverse |
|
|
|
031a |
151-0158
|
Push rod 36 inch forks fine thread |
|
|
|
031b |
151-0159
|
Push rod 42 inch forks fine thread |
|
|
|
031c |
151-0160
|
Push rod 48 inch |
|
|
|
032 |
151-0161
|
Exit roller |
|
|
|
033 |
151-0162
|
Pivot axle |
|
|
|
034 |
151-5011
|
Roll pin |
|
|
|
035 |
151-0163
|
Load roller brackets |
|
|
|
036 |
151-0164
|
Load roller axle assembly |
|
|
|
037a |
151-0165
|
Bearing (for Poly roller) |
|
|
|
037b |
151-0166
|
Bearing (for steel roller) |
|
|
|
038a |
151-0167
|
Load roller assembly polyproylene 2 inch diameter |
|
|
|
038b |
151-0168
|
Load roller polypropylene 2 inch diameter |
|
|
|
038c |
151-0169
|
Load roller assembly steel 2 inch diameter |
|
|
|
038d |
151-0170
|
Load roller steel 2 inch diameter |
|
|
|
039 |
151-0171
|
Lifiting link 33 inch wide jack |
|
|
|
040 |
151-0172
|
Traverse 33 inch wide jack |
|
|
|
041 |
151-0173
|
Push rod 48 inch forks fine thread |
|
|
|
042 |
151-0174
|
Load roller brackets |
|
|
|
043 |
151-0175
|
Bearing |
|
|
|
044a |
151-0176
|
Super load roller assembly steel 1 3/4 inch diameter |
|
|
|
044b |
151-0177
|
Load roller assembly steel 1 3/4 diameter |
|
|
|
044c |
151-0178
|
Load roller steel 1 3/4 diameter |
|
|
|
