| # | Part | Description |
Req | Notes | Availability |
|---|
007 |
189-4394
|
Plaque |
|
|
|
008 |
189-4403
|
Brush hub kit |
|
|
|
009 |
189-4403
|
Brush hub kit |
|
|
|
011 |
189-4406
|
Support |
|
|
|
015 |
999-0972
|
Washer M14 flat |
|
|
|
021 |
189-4395
|
Left hand splash guard |
|
|
|
024a |
189-4399
|
Cylindrical brush soft |
|
|
|
024b |
189-4400
|
Cylindrical brush stiff |
|
|
|
024c |
189-4401
|
Cylindrical brush standard |
|
|
|
024d |
189-4402
|
Cylindrical brush tynex grit |
|
|
|
026 |
189-4396
|
Motor |
|
|
|
027 |
189-4397
|
Brush drive belt |
|
|
|
031 |
189-2577
|
Bearing |
|
|
|
033 |
189-4398
|
Right hand splash guard |
|
|
|
074 |
206-5170
|
Screw |
|
|
|
079 |
206-5168
|
Washer (OBSOLETE) |
|
|
|
098 |
189-4404
|
Washer lock |
|
|
|
099 |
189-4405
|
Screw |
|
|
|
