USAfixTM - Repair Guide (RG) - Master Email RG
- Brush Motor Switch Broken
 Level of Difficulty - Low  Estimated Completion Time - minutes

Tools Required

Parts Required

Step Procedure & Parts & Tools
1 The switch that engages the scrub brush motor is located near the machine down pressure lever lock on the support bracket.

2 The switch is activated when the lever is released and the scrub head is lowered to the floor. It is deactivated when the lever is moved onto the locked/transport position.

3 This lever is most often actuated by the operators foot. The most common reason for replacing the switch is because of damage due to operator error or machine handling.

4 This switch should also be checked if the brush motor is constantly on and will not shut off.

5 Please note that machines should not be tilted backwards for any reason which could cause damage to this switch as well as other components on rear of machine.
