- Pads - 14 inch - 255-1400 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 01 |
255-1440 |
14 inch aqua plus burnishing pad (pkg of 5) |
$26.50 |
|
|
| 02 |
255-1435 |
14 inch Armadillo concrete scrubbing pad (pkg of 5) |
$28.40 |
|
|
| 03 |
255-1464 |
14 inch Blue ace pad (pkg of 5) |
$26.50 |
|
|
| 04 |
255-1442 |
14 inch Blue Jay burnishing pad (pkg of 5) |
$21.22 |
|
|
| 05 |
255-1412 |
14 inch Cure white pad (pkg of 5) |
$26.50 |
|
|
| 06 |
255-1477 |
14 inch Diamondback extreme stripping pad (pkg of 5) |
$37.58 |
|
|
| 07 |
255-1438 |
14 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2 |
$142.70 |
|
|
| 08 |
255-1421 |
14 inch gorilla lite burnishing pad (pkg of 5) |
$26.50 |
|
|
| 09 |
255-1450 |
14 inch gorilla spray buff/polish/burnish pad (pkg of 5) |
$26.50 |
|
|
| 10 |
255-1465 |
14 inch Heat concrete bonding pad (pkg of 5) |
$77.50 |
|
|
| 11 |
255-1430 |
14 inch jaguar burnishing pad (pkg of 5) |
$21.22 |
|
|
| 12 |
255-1487 |
14 inch Melamine Mela-Kleen pad (pkg of 2) |
$144.33 |
|
|
| 13 |
255-1490 |
14 inch premium black stripping pad (pkg of 5) |
$24.75 |
|
|
| 14 |
255-1470 |
14 inch premium blue cleaning pad (pkg of 5) |
$26.50 |
|
|
| 15 |
255-1492 |
14 inch premium brown stripping pad (pkg of 5) |
$26.50 |
|
|
| 16 |
255-1480 |
14 inch premium green scrubbing pad (pkg of 5) |
$24.75 |
|
|
| 17 |
255-1460 |
14 inch premium red scrubbing pad (pkg of 5) |
$26.50 |
|
|
| 18 |
255-1452 |
14 inch premium tan polishing pad (pkg of 5) |
$23.58 |
|
|
| 19 |
255-1420 |
14 inch premium white polishing pad (pkg of 5) |
$24.75 |
|
|
| 20 |
255-1411 |
14 inch superspeed rubberized pad (pkg of 5) |
$26.50 |
|
|
| 21 |
255-1495 |
14 inch razorback stripping pad (pkg of 5) |
$34.15 |
|
|
| 22 |
255-1447 |
14 inch Redwood maroon floor prep pad (pkg of 10) |
$54.63 |
|
|
| 23 |
255-1455 |
14 inch Ruff non-abrasive brush pad (pkg of 2) |
$95.50 |
|
|
| 24 |
255-1423 |
14 inch sand screen driver pad (pkg of 2) |
$24.80 |
|
|
| 25 |
255-0120 |
14 inch Professional sand screen 100 grit (pkg of 10) |
$58.96 |
|
|
| 26 |
255-0121 |
14 inch Professional sand screen 120 grit (pkg of 10) |
$51.20 |
|
|
| 27 |
255-0122 |
14 inch Professional sand screen 180 grit (pkg of 10) |
$48.53 |
|
|
| 28 |
255-0119 |
14 inch Professional sand screen 60 grit (pkg of 10) |
$86.63 |
|
|
| 29 |
255-0205 |
14 inch Superscreen sand screen 100 grit (pkg of 10) |
$49.13 |
|
|
| 30 |
255-0206 |
14 inch Superscreen sand screen 120 grit (pkg of 10) |
$42.67 |
|
|
| 31 |
255-0207 |
14 inch Superscreen sand screen 180 grit (pkg of 10) |
$40.44 |
|
|
| 32 |
255-0204 |
14 inch Superscreen sand screen 60 grit (pkg of 10) |
$72.20 |
|
|
| 33 |
255-1424 |
14 x 20 inch Tiger carpet bonnet (pkg of 2) |
$103.35 |
|
|
| 34 |
255-9549 |
14 inch Diamond by Gorilla 11000 Grit (pkg of 2) |
$137.58 |
|
|
| 35 |
255-9546 |
14 inch Diamond by Gorilla 1500 Grit (pkg of 2) |
$128.55 |
|
|
| 36 |
255-9543 |
14 inch Diamond by Gorilla 200 Grit (pkg of 2) |
$118.09 |
|
|
| 37 |
255-9547 |
14 inch Diamond by Gorilla 3000 Grit (pkg of 2) |
$137.58 |
|
|
| 38 |
255-9544 |
14 inch Diamond by Gorilla 400 Grit (pkg of 2) |
$118.09 |
|
|
| 39 |
255-9545 |
14 inch Diamond by Gorilla 800 Grit (pkg of 2) |
$128.55 |
|
|
| 40 |
255-9548 |
14 inch Diamond by Gorilla 8000 Grit (pkg of 2) |
$110.13 |
|
|
| 41 |
255-9639 |
14 inch Diamond starter pack (1 of each grit) |
$259.10 |
|
|
| 42 |
255-1482 |
14 inch Turbostrip segmented rotary pad (pkg of 4) |
$45.95 |
|
|
| 43 |
255-1415 |
14 inch Duala clean and shine pad - low speed (pkg of 5) |
$104.60 |
|
|
| 44 |
255-1416 |
14 inch 2001 Duala clean and shine pad-high speed (pkg of 5) |
$120.80 |
|
|
|
|
- Pads - 14 x 28 inch - 255-1428 |
|
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 01 |
255-9032 |
14 x 28 inch Melamine Mela-Kleen pad (pkg of 2) |
$325.45 |
|
|
| 02 |
255-9005 |
14 x 28 inch Premium Black Stripping Pad (pkg of 5) |
$73.85 |
|
|
| 03 |
255-9017 |
14 x 28 inch Premium Blue Cleaning Pad (pkg of 5) |
$73.85 |
|
|
| 04 |
255-9011 |
14 x 28 inch Premium Green Scrubbing Pad (pkg of 5) |
$73.85 |
|
|
| 05 |
255-9023 |
14 x 28 inch Premium Red Pad (pkg of 5) |
$73.85 |
|
|
| 06 |
255-9029 |
14 x 28 inch Premium White Polishing Pad (pkg of 5) |
$73.85 |
|
|
| 07 |
255-9037 |
14 x 28 inch Redwood maroon floor prep pad (pkg of 10) |
$182.45 |
|
|
| 08 |
255-9042 |
14 x 28 inch Ruff non-abrasive brush pad (pkg of 2) |
$237.23 |
|
|
| 09 |
255-0187 |
14 x 28 inch Professional sand screen 100 grit (pkg of 10) |
$220.28 |
|
|
| 10 |
255-0188 |
14 x 28 inch Professional sand screen 120 grit (pkg of 10) |
$211.45 |
|
|
| 11 |
255-0189 |
14 x 28 inch Professional sand screen 150 grit (pkg of 10) |
$162.33 |
|
|
| 12 |
255-0190 |
14 x 28 inch Professional sand screen 180 grit (pkg of 10) |
$162.33 |
|
|
| 13 |
255-0185 |
14 x 28 inch Professional sand screen 60 grit (pkg of 10) |
$208.03 |
|
|
| 14 |
255-0186 |
14 x 28 inch Professional sand screen 80 grit (pkg of 10) |
$238.48 |
|
|
| 15 |
255-0286 |
14 x 28 inch Superscreen sand screen 100 grit (pkg of 10) |
$147.00 |
|
|
| 16 |
255-0287 |
14 x 28 inch Superscreen sand screen 120 grit (pkg of 10) |
$141.12 |
|
|
| 17 |
255-0288 |
14 x 28 inch Superscreen sand screen 150 grit (pkg of 10) |
$211.18 |
|
|
| 18 |
255-0289 |
14 x 28 inch Superscreen sand screen 180 grit (pkg of 10) |
$135.28 |
|
|
| 19 |
255-0284 |
14 x 28 inch Superscreen sand screen 60 grit (pkg of 10) |
$270.58 |
|
|
| 20 |
255-0285 |
14 x 28 inch Superscreen sand screen 80 grit (pkg of 10) |
$159.14 |
|
|
| 21 |
255-9661 |
14 x 28 inch Diamond by Gorilla 100 Grit (pkg of 2) |
$309.51 |
|
|
| 22 |
255-9669 |
14 x 28 inch Diamond by Gorilla 11000 Grit (pkg of 2) |
$561.99 |
|
|
| 23 |
255-9665 |
14 x 28 inch Diamond by Gorilla 1500 Grit (pkg of 2) |
$271.49 |
|
|
| 24 |
255-9662 |
14 x 28 inch Diamond by Gorilla 200 Grit (pkg of 2) |
$309.51 |
|
|
| 25 |
255-9666 |
14 x 28 inch Diamond by Gorilla 3000 Grit (pkg of 2) |
$339.03 |
|
|
| 26 |
255-9663 |
14 x 28 inch Diamond by Gorilla 400 Grit (pkg of 2) |
$309.51 |
|
|
| 27 |
255-9664 |
14 x 28 inch Diamond by Gorilla 800 Grit (pkg of 2) |
$271.49 |
|
|
| 28 |
255-9667 |
14 x 28 inch Diamond by Gorilla 8000 Grit (pkg of 2) |
$271.49 |
|
|
| 29 |
255-9668 |
14 x 28 inch Diamond starter pack (1 of each grit) |
$271.49 |
|
|
| 30 |
255-0292 |
14 x 28 inch Duala clean and shine pad -low speed (pkg of 5) |
$194.35 |
|
|
| 31 |
255-0296 |
14 x 28 2001 Duala clean and shine pad -high speed (pkg 5) |
$280.68 |
|
|
|
|
- Pads - 17 inch - 255-1700 |
|
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 01 |
255-1740 |
17 inch aqua plus burnishing pad (pkg of 5) |
$27.86 |
|
|
| 02 |
255-1735 |
17 inch Armadillo concrete scrubbing pad (pkg of 5) |
$39.75 |
|
|
| 03 |
255-1764 |
17 inch Blue ace pad (pkg of 5) |
$34.80 |
|
|
| 04 |
255-1742 |
17 inch Blue Jay burnishing pad (pkg of 5) |
$34.80 |
|
|
| 05 |
255-1712 |
17 inch Cure white pad (pkg of 5) |
$34.80 |
|
|
| 06 |
255-1777 |
17 inch Diamondback extreme stripping pad (pkg of 5) |
$49.85 |
|
|
| 07 |
255-1738 |
17 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2 |
$163.73 |
|
|
| 08 |
255-1721 |
17 inch gorilla lite burnishing pad (pkg of 5) |
$34.80 |
|
|
| 09 |
255-1750 |
17 inch gorilla spray buff/polish/burnish pad (pkg of 5) |
$34.80 |
|
|
| 10 |
255-1765 |
17 inch Heat concrete bonding pad (pkg of 5) |
$101.72 |
|
|
| 11 |
255-1730 |
17 inch jaguar burnishing pad (pkg of 5) |
$27.86 |
|
|
| 12 |
255-1767 |
17 inch Laminated 2001 Gorilla polish pad (pkg of 5) |
$101.72 |
|
|
| 13 |
255-1768 |
17 inch Microclean daily cleaning pad (pkg of 2) |
$124.93 |
|
|
| 14 |
255-1769 |
17 inch Micropolish polishing and burnishing pad (pkg of 2) |
$155.95 |
|
|
| 15 |
255-1790 |
17 inch premium black stripping pad (pkg of 5) |
$34.80 |
|
|
| 16 |
255-1770 |
17 inch premium blue cleaning pad (pkg of 5) |
$34.80 |
|
|
| 17 |
255-1792 |
17 inch premium brown stripping pad (pkg of 5) |
$34.80 |
|
|
| 18 |
255-1780 |
17 inch premium green scrubbing pad (pkg of 5) |
$34.80 |
|
|
| 19 |
255-1760 |
17 inch premium red scrubbing pad (pkg of 5) |
$34.80 |
|
|
| 20 |
255-1752 |
17 inch premium tan polishing pad (pkg of 5) |
$34.80 |
|
|
| 21 |
255-1720 |
17 inch premium white polishing pad (pkg of 5) |
$34.80 |
|
|
| 22 |
255-1711 |
17 inch superspeed rubberized pad (pkg of 5) |
$27.86 |
|
|
| 23 |
255-1795 |
17 inch razorback stripping pad (pkg of 5) |
$45.33 |
|
|
| 24 |
255-1747 |
17 inch Redwood maroon floor prep pad (pkg of 10) |
$71.65 |
|
|
| 25 |
255-1755 |
17 inch Ruff non-abrasive brush pad (pkg of 2) |
$124.65 |
|
|
| 26 |
255-1723 |
17 inch sand screen driver pad (pkg of 2) |
$40.68 |
|
|
| 27 |
255-0139 |
17 inch Professional sand screen 100 grit (pkg of 10) |
$124.53 |
|
|
| 28 |
255-0019 |
17 inch Professional sand screen 120 grit (pkg of 10) |
$117.03 |
|
|
| 29 |
255-0140 |
17 inch Professional sand screen 150 grit (pkg of 10) |
$101.80 |
|
|
| 30 |
255-0141 |
17 inch Professional sand screen 180 grit (pkg of 10) |
$101.80 |
|
|
| 31 |
255-0142 |
17 inch Professional sand screen 220 grit (pkg of 10) |
$101.80 |
|
|
| 32 |
255-0143 |
17 inch Professional sand screen 400 grit (pkg of 10) |
$81.54 |
|
|
| 33 |
255-0138 |
17 inch Professional sand screen 60 grit (pkg of 10) |
$182.08 |
|
|
| 34 |
255-0018 |
17 inch Professional sand screen 80 grit (pkg of 10) |
$150.75 |
|
|
| 35 |
255-0225 |
17 inch Superscreen sand screen 100 grit (pkg of 10) |
$83.10 |
|
|
| 36 |
255-0226 |
17 inch Superscreen sand screen 120 grit (pkg of 10) |
$78.08 |
|
|
| 37 |
255-0227 |
17 inch Superscreen sand screen 150 grit (pkg of 10) |
$86.91 |
|
|
| 38 |
255-0228 |
17 inch Superscreen sand screen 180 grit (pkg of 10) |
$67.95 |
|
|
| 39 |
255-0229 |
17 inch Superscreen sand screen 220 grit (pkg of 10) |
$97.13 |
|
|
| 40 |
255-0230 |
17 inch Superscreen sand screen 400 grit (pkg of 10) |
$67.95 |
|
|
| 41 |
255-0223 |
17 inch Superscreen sand screen 60 grit (pkg of 10) |
$155.47 |
|
|
| 42 |
255-0224 |
17 inch Superscreen sand screen 80 grit (pkg of 10) |
$100.59 |
|
|
| 43 |
255-1724 |
17 inch Tiger carpet bonnet (pkg of 2) |
$76.00 |
|
|
| 44 |
255-9570 |
17 inch Diamond by Gorilla 11000 Grit (pkg of 2) |
$153.80 |
|
|
| 45 |
255-9567 |
17 inch Diamond by Gorilla 1500 Grit (pkg of 2) |
$153.80 |
|
|
| 46 |
255-9564 |
17 inch Diamond by Gorilla 200 Grit (pkg of 2) |
$163.73 |
|
|
| 47 |
255-9568 |
17 inch Diamond by Gorilla 3000 Grit (pkg of 2) |
$153.80 |
|
|
| 48 |
255-9565 |
17 inch Diamond by Gorilla 400 Grit (pkg of 2) |
$131.11 |
|
|
| 49 |
255-9566 |
17 inch Diamond by Gorilla 800 Grit (pkg of 2) |
$153.80 |
|
|
| 50 |
255-9569 |
17 inch Diamond by Gorilla 8000 Grit (pkg of 2) |
$153.80 |
|
|
| 51 |
255-9642 |
17 inch Diamond starter pack (1 of each grit) |
$287.02 |
|
|
| 52 |
255-1782 |
17 inch Turbostrip segmented rotary pad (pkg of 4) |
$53.85 |
|
|
| 53 |
255-1715 |
17 inch Duala clean and shine pad - low speed (pkg of 5) |
$133.70 |
|
|
| 54 |
255-1716 |
17 inch 2001 Duala clean and shine pad - high speed (pkg 5) |
$154.67 |
|
|
|
|
Brush and Pad Assembly - 275-0575 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-1629 |
13 inch nylon scrubbing brush |
$214.40 |
2 |
(includes 2) |
| 1b |
375-1630 |
13 inch polypropelene scrubbing brush |
$289.30 |
2 |
(includes 2) |
| 1c |
375-1631 |
13 inch super abrasive stripping brush |
$335.90 |
2 |
(includes 2) |
| 1d |
275-1349 |
14 inch polypropelene scrubbing brush |
$240.50 |
2 |
(includes 2) |
| 1e |
275-1348 |
14 inch nylon scrubbing brush |
$288.20 |
2 |
(includes 2) |
| 1f |
275-1350 |
14 inch super abrasive stripping brush |
$511.70 |
2 |
(includes 2) |
| 1g |
275-1352 |
16 inch polypropelene scrubbing brush |
$275.80 |
2 |
(includes 2) |
| 1h |
275-1351 |
16 inch nylon scrubbing brush |
$371.30 |
2 |
(includes 2) |
| 1i |
275-1353 |
16 inch super abrasive stripping brush |
$511.70 |
2 |
(includes 2) |
| 2 |
375-1282 |
Clutch plate kit |
$60.20 |
1 |
|
| 3a |
996-1479 |
13 inch pad driver assembly |
$324.70 |
2 |
(includes 4-8) |
| 3b |
275-1357 |
14 inch pad driver assembly |
$327.30 |
2 |
(includes 4-8) |
| 3c |
275-4783 |
16 inch pad driver assembly |
$364.00 |
2 |
(includes 4-8) |
| 4 |
375-1282 |
Clutch plate kit |
$60.20 |
1 |
|
| 5 |
275-6264 |
Pad centering device |
$42.00 |
1 |
|
| 6 |
999-0266 |
Washer #8 SAE flat stainless steel |
$0.90 |
3 |
|
| 7 |
275-4705 |
Screw M4-.7 x25mm pan head phillips |
$4.44 |
3 |
|
| 8 |
175-5851 |
Nut M4 45/64 |
$3.48 |
3 |
|
| 9a |
175-8616 |
13 inch stripping pad (brown) |
$16.30 |
2 |
|
| 9b |
175-8617 |
13 inch scrubbing pad (blue) |
$74.50 |
2 |
|
| 9c |
175-8618 |
Buffing pad |
$74.10 |
2 |
|
| 9d |
255-1320 |
13 inch premium white polishing pad (pkg of 5) |
$23.48 |
2 |
|
| 9e |
255-1347 |
13 inch Redwood maroon floor prep pad (pkg of 10) |
$48.33 |
2 |
|
| 9f |
375-9365 |
Polish pad (yellow) |
$126.60 |
2 |
|
| 9g |
255-1492 |
14 inch premium brown stripping pad (pkg of 5) |
$26.50 |
2 |
|
| 9h |
175-4906 |
14 inch scrubbing pad (blue) |
$17.80 |
2 |
|
| 9i |
175-4905 |
14 inch buffing pad (red) |
$17.80 |
2 |
|
| 9j |
175-4904 |
Polish pad 14 inch white |
$17.80 |
2 |
|
| 9k |
255-1490 |
14 inch premium black stripping pad (pkg of 5) |
$24.75 |
2 |
|
| 9l |
375-1634 |
14 inch stripping pad (maroon) |
$19.70 |
2 |
|
| 9m |
375-9366 |
14 inch polish pad (yellow) |
$133.00 |
2 |
|
| 9n |
255-1692 |
16 inch premium brown stripping pad (pkg of 5) |
$29.53 |
2 |
|
| 9o |
175-0518 |
16 inch scrubbing pad (blue)(each) |
$20.30 |
2 |
|
| 9p |
175-0519 |
16 inch buffing pad (red)(each) |
$20.30 |
2 |
|
| 9q |
255-1620 |
16 inch premium white polishing pad (pkg of 5) |
$29.53 |
2 |
|
| 9r |
175-4909 |
Black strip head pad |
$33.40 |
2 |
|
| 9s |
255-1647 |
16 inch Redwood maroon floor prep pad (pkg of 10) |
$65.10 |
2 |
|
| 9t |
375-9367 |
16 inch polish pad (yellow) |
$171.50 |
2 |
|
| 10a |
996-1039 |
Polypropelene grout scrubbing brush - CYLINDRICAL |
$203.50 |
2 |
|
| 10b |
996-1041 |
Nylon scrubbing brush - CYLINDRICAL |
$297.70 |
2 |
|
| 10c |
996-1042 |
Abrasive scrubbing brush - CYLINDRICAL |
$436.60 |
2 |
|
| 11a |
375-1635 |
28 x 14 inch scrubbing pad (blue) |
$60.60 |
1 |
|
| 11b |
255-9048 |
14x28 inch gorilla spray buff/polish/burnish pad (pkg of 5) |
$59.14 |
1 |
|
| 11c |
255-9029 |
14 x 28 inch Premium White Polishing Pad (pkg of 5) |
$73.85 |
1 |
|
| 11d |
255-9037 |
14 x 28 inch Redwood maroon floor prep pad (pkg of 10) |
$182.45 |
1 |
|
| 11e |
255-9011 |
14 x 28 inch Premium Green Scrubbing Pad (pkg of 5) |
$73.85 |
1 |
|
| 11f |
475-2795 |
28 x 14 inch stripping pad (black) (sold by the carton) |
$965.60 |
1 |
|
| 11g |
475-4012 |
28 x 14 inch melamine pad (pkg of 5) |
$533.60 |
1 |
|
| 11h |
375-9369 |
Polish pad 28 x 14 (yellow) |
$689.70 |
1 |
|
| 12 |
375-1640 |
28 x 14 inch backer pad with velcro fasteners |
$217.00 |
1 |
|
|
|
Scrub Head Assembly - Disk - 275-7783 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
275-1457 |
24V brush motor assembly with gearbox |
$1,375.04 |
2 |
(includes 2-3) (OEM) |
| 1b |
991-1706 |
24V brush motor assembly with gearbox |
$712.62 |
2 |
(NON-OEM) |
| 2 |
275-1458 |
Carbon brush (pkg of 2) |
$200.40 |
1 |
(1 per motor) |
| 3 |
275-1459 |
Brush motor connector harness |
$256.90 |
1 |
(1 per motor) |
| 4 |
275-1469 |
Shaft spacer |
$7.50 |
2 |
|
| 5 |
275-1465 |
Screw M6-1 x 35 mm set nylock stainless steel |
$3.60 |
8 |
|
| 6 |
375-3139 |
Plastic round knob |
$14.30 |
2 |
|
| 7 |
175-7018 |
Compression spring |
$5.00 |
2 |
|
| 8 |
375-3140 |
Screw M6-1 x 12mm truss head phillips stainless steel |
$1.68 |
4 |
|
| 9 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
4 |
|
| 10 |
999-0769 |
Screw M8-1.25 x 40mm button head socket stainless steel |
$1.44 |
2 |
|
| 11 |
375-3141 |
Roller bracket |
$21.10 |
2 |
|
| 12 |
175-2182 |
Sleeve |
$3.48 |
2 |
|
| 13 |
175-2245 |
Wheel |
$8.80 |
2 |
|
| 14 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
2 |
|
| 15a |
375-9370 |
26 inch disc housing |
$632.46 |
1 |
|
| 15b |
375-4503 |
28 inch disc housing with decal |
$690.14 |
1 |
|
| 15c |
375-9824 |
32 inch disc housing bumper |
$556.70 |
1 |
|
| 16 |
375-9372 |
Flange bushing 10mm x 12mm x 17mm |
$31.60 |
1 |
|
| 17 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
1 |
|
| 18 |
375-0108 |
Electrical harness |
$5.90 |
1 |
|
| 19 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
|
| 20 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
| 21 |
375-0204 |
5 foot solution hose |
$96.20 |
1 |
|
| 22 |
375-3144 |
Plastic tee fitting |
$12.20 |
1 |
|
| 23 |
999-1408 |
Screw M10-1.5 x 90mm hex head stainless steel |
$3.90 |
2 |
|
| 24 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
8 |
|
| 25 |
999-0497 |
Nut M6-1 nylon insert lock stainless steel |
$0.90 |
8 |
|
| 26 |
275-1468 |
Square keyway |
$4.44 |
2 |
|
| 27 |
275-1477 |
Brush drive hub (disk) |
$119.30 |
2 |
|
| 28 |
175-7920 |
Washer M8 flat stainless steel |
$3.72 |
2 |
|
| 29 |
999-0499 |
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.68 |
2 |
|
| 31a |
475-3755 |
26 inch bumper head skirt |
$131.70 |
1 |
|
| 31b |
375-3146 |
28 inch (700mm) bumper |
$115.80 |
1 |
|
| 31c |
375-3148 |
32 inch (800mm) bumper |
$133.10 |
1 |
|
|
|
Scrub Head Assembly - Cylindrical - Lower - 275-7784 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
11 |
|
| 2 |
375-3150 |
Skirt cover |
$9.50 |
2 |
|
| 3 |
375-3158 |
Cylindrical side skirt |
$23.30 |
2 |
|
| 4 |
175-2863 |
Screw M10-1.5 x 20mm flat head stainless steel nylok |
$4.44 |
2 |
|
| 5 |
375-3159 |
Brush door |
$48.30 |
1 |
|
| 6 |
999-0534 |
Screw M4-.7 x 10mm pan head slotted zinc |
$0.90 |
6 |
|
| 7 |
175-2477 |
Roll pin |
$2.76 |
2 |
|
| 8 |
175-2476 |
Idler plug shaft |
$67.90 |
2 |
|
| 9 |
175-2478 |
Brush idler plug |
$26.30 |
2 |
|
| 10 |
175-2472 |
Retaining ring |
$2.76 |
2 |
|
| 11 |
375-0071 |
Cotter hair pin |
$1.68 |
2 |
|
| 12 |
275-3031 |
PIN, CLEVIS, 0.37D X 4.00L (Tennant Industrial) |
$12.84 |
2 |
|
| 13 |
991-2013 |
Wheel |
$8.70 |
6 |
|
| 14 |
275-5187 |
Latch with keeper |
$14.50 |
2 |
|
| 15 |
999-0534 |
Screw M4-.7 x 10mm pan head slotted zinc |
$0.90 |
6 |
|
| 16 |
375-3160 |
Cable tie (Tennant Industrial) |
$9.17 |
1 |
|
| 17 |
275-5197 |
Fir tree clip |
$1.92 |
3 |
|
| 18 |
375-3161 |
Debris tray spring bracket |
$20.00 |
1 |
|
| 19 |
375-3162 |
28 inch (700mm) cylindrical housing |
$718.10 |
1 |
|
| 20 |
275-1497 |
Water deflector |
$44.60 |
1 |
|
| 21 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
7 |
|
| 22 |
375-0204 |
5 foot solution hose |
$96.20 |
1 |
|
| 23 |
375-0135 |
90 degree elbow |
$30.40 |
1 |
|
| 24 |
275-9424 |
28 inch spray bar tube assembly |
$71.40 |
1 |
|
| 25 |
275-1505 |
Cap fitting |
$7.70 |
2 |
|
| 26 |
375-3167 |
Debris tray bracket |
$16.20 |
1 |
|
| 27 |
375-3164 |
Debris tray |
$41.60 |
1 |
|
| 28 |
375-3165 |
Slide tray bracket |
$57.70 |
1 |
|
| 29 |
375-3166 |
Brush panel wrap |
$209.40 |
1 |
|
|
|
Recovery Tank Assembly - 275-7787 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3213 |
Recovery tank cover kit |
$291.60 |
1 |
(includes 2) |
| 2 |
375-3206 |
Recovery tank cover seal |
$65.00 |
1 |
|
| 3 |
375-3207 |
Recovery tank lid support |
$49.60 |
1 |
|
| 4 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
12 |
|
| 5 |
275-5957 |
Round knob M6 x 20mm plastic |
$4.56 |
2 |
|
| 6 |
375-3208 |
Recovery tank spray shield |
$18.50 |
1 |
|
| 7 |
999-0507 |
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.90 |
3 |
|
| 8 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
3 |
|
| 9 |
375-0114 |
Vacuum motor mount |
$16.50 |
1 |
|
| 10 |
275-9897 |
Isolator |
$4.44 |
3 |
|
| 11a |
375-0113 |
24V 2 stage vacuum motor |
$415.70 |
1 |
(includes 11b) |
| 11b |
275-7693 |
Carbon brush (pkg of 2) |
$25.40 |
1 |
|
| 12 |
175-7794 |
Vacuum exhaust hose |
$27.50 |
1 |
|
| 13 |
175-6085 |
Gasket |
$9.20 |
1 |
|
| 14 |
375-3209 |
Hinge |
$14.00 |
2 |
|
| 15 |
375-3210 |
Recovery tank seal |
$32.90 |
1 |
|
| 16 |
375-3211 |
Recovery tank |
$786.00 |
1 |
|
| 17 |
375-3212 |
Leaf hinge |
$17.10 |
2 |
|
| 18 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
|
| 20 |
375-7848 |
Top hanger bracket |
$61.80 |
1 |
(after SN 11010146) |
|
|
Recovery Tank Drain Hose Assembly - 275-7788 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
999-0507 |
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.90 |
3 |
|
| 2 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
3 |
|
| 3 |
175-7782 |
Float mount |
$28.50 |
1 |
|
| 4 |
175-1804 |
Shut-off float |
$70.20 |
1 |
|
| 5 |
175-7783 |
Float mount gasket |
$4.80 |
1 |
|
| 6 |
375-0211 |
Debris tray |
$30.20 |
1 |
|
| 7 |
375-3214 |
Hose tube adapter |
$9.30 |
1 |
|
| 8 |
275-5935 |
Hose adapter gasket |
$3.84 |
1 |
|
| 9 |
375-3216 |
Drain hose assembly (black) |
$60.60 |
1 |
(includes 10a-10b) |
| 10a |
375-0214 |
Drain cap assembly (black) |
$7.60 |
1 |
(includes 10b) |
| 10b |
175-5804 |
O-ring |
$10.70 |
1 |
|
| 11 |
997-2000 |
Hose clamp |
$2.15 |
2 |
|
| 12a |
375-0220 |
22 inch hose assembly w/cuffs 1 1/2 x 22 in |
$32.09 |
1 |
(standard) |
| 12b |
375-3217 |
33 inch hose assembly with cuffs |
$75.90 |
1 |
(replaced by 12a) (before SN 10984821) |
| 12c |
991-3182 |
Vacuum hose with cuffs 1 1/2 |
$24.60 |
1 |
(NON-OEM) |
| 13 |
997-2003 |
Hose clamp |
$2.42 |
1 |
|
|
|
Solution Tank Assembly - 275-7789 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
475-4132 |
TANK KIT, SOLTN, CI [T500] |
$1,291.70 |
1 |
|
| 2 |
375-3219 |
Right hand accessory tray |
$19.60 |
1 |
|
| 3 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
11 |
(qty 15 before SN 11058039) |
| 4 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
1 |
(before SN 11058039) |
| 5 |
175-7825 |
Solution fill port cap |
$4.44 |
1 |
(before SN 11058039) |
| 6 |
375-3220 |
Standard fill cover |
$26.80 |
1 |
(before SN 11058039) |
| 7 |
375-3221 |
Water seal |
$4.92 |
1 |
(before SN 11058039) |
| 8 |
375-3222 |
Solution drain hose kit |
$42.40 |
1 |
|
| 9 |
375-3223 |
Left hand accessory tray |
$24.60 |
1 |
|
| 10 |
175-2254 |
Hose clamp |
$5.00 |
1 |
|
| 11 |
275-5197 |
Fir tree clip |
$1.92 |
4 |
|
| 12 |
175-2667 |
P clamp |
$4.44 |
1 |
|
| 13 |
375-3230 |
Dual seal (Tennant Industrial) |
$24.67 |
1 |
|
| 14 |
375-3224 |
Actuator weldment bracket |
$102.20 |
1 |
|
| 15 |
175-0152 |
Spacer |
$4.32 |
1 |
|
| 16 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 17 |
999-0507 |
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.90 |
1 |
|
| 18 |
375-3225 |
Cable |
$15.30 |
1 |
|
| 19 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
3 |
|
| 20 |
999-1026 |
Washer #10 internal lock stainless steel |
$0.90 |
3 |
|
| 21 |
175-5129 |
Ball chain #10 stainless steel |
$4.44 |
1 |
|
| 22 |
375-3226 |
Filter screen |
$4.92 |
1 |
|
| 23 |
375-3227 |
Solution tank seal |
$29.80 |
1 |
|
| 24a |
375-3228 |
Front fill cover |
$24.90 |
1 |
(standard) |
| 24b |
375-3229 |
Front fill cover |
$72.60 |
1 |
(ec- H2O) |
| 25 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
2 |
|
| 27 |
375-1366 |
Large rail hanger bracket (OBSOLETE) |
$11.30 |
1 |
(before 06/2022) |
| 28 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
1 |
|
| 29 |
175-3179 |
P clamp |
$4.44 |
1 |
(models without ABW option) |
| 30 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
1 |
(models without ABW option) |
|
|
Electrical Assembly - 275-7790 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3231 |
Bracket |
$44.20 |
1 |
|
| 2 |
375-0170 |
Circuit breaker |
$7.70 |
1 |
|
| 3 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
2 |
|
| 4 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
5 |
|
| 5 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
9 |
|
| 6 |
375-3232 |
60amp circuit breaker |
$23.80 |
1 |
|
| 7 |
275-7026 |
Plug (Tennant Industrial) |
$2.80 |
1 |
(models without spray wand option) |
| 8 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
1 |
|
| 9 |
999-0740 |
Nut M5-.8 hex stainless steel |
$0.90 |
1 |
|
| 10 |
375-3233 |
24V relay |
$18.40 |
1 |
|
| 11 |
275-5197 |
Fir tree clip |
$1.92 |
4 |
|
| 12 |
275-0288 |
Washer 1/4 internal-external lock |
$3.60 |
3 |
|
| 13 |
375-3180 |
Bracket |
$53.50 |
1 |
|
| 14 |
375-3234 |
Drive module kit |
$360.50 |
1 |
(requires Tennant True service or an authorized Tennant service provider) |
| 15 |
999-1083 |
Washer #8 internal star lock stainless steel |
$0.90 |
2 |
|
| 16 |
999-1672 |
Screw M4-.7 x 30mm pan head phillips stainless steel |
$0.90 |
2 |
|
| 17a |
375-3235 |
Control board kit |
$801.70 |
1 |
(includes 17b-17c) |
| 17b |
275-1425 |
Static ground strap (Tennant Industrial) |
$11.50 |
1 |
|
| 17c |
375-1351 |
USB to USB mini cable |
$13.90 |
1 |
|
| 18 |
375-3236 |
Control board pad |
$18.40 |
1 |
|
| 19 |
275-5465 |
Standoff |
$1.68 |
1 |
|
| 20 |
275-5476 |
Nut M8 x 1.25 hex brass (Tennant Industrial) |
$5.17 |
6 |
|
| 21 |
275-5475 |
Washer M8-.4 x 1.6mm brass |
$2.76 |
3 |
|
| 22 |
999-1053 |
Washer 5/16 internal star lock stainless steel |
$0.90 |
5 |
|
| 23 |
175-4271 |
Screw M8 x 35mm set |
$4.44 |
3 |
|
| 24 |
375-0176 |
Insulated stand-off |
$12.00 |
2 |
|
| 25 |
375-0181 |
Fuse |
$16.40 |
2 |
|
| 26 |
275-5479 |
Nut M6 x 1 (Tennant Industrial) |
$2.80 |
1 |
|
| 27 |
999-0016 |
Washer 1/4 flat plain finish |
$0.90 |
1 |
|
| 28 |
175-4544 |
Washer M6 locking |
$3.72 |
1 |
|
| 29 |
375-3237 |
Circuit board cover gasket |
$48.60 |
1 |
|
| 30 |
375-4562 |
Circuitboard heatsink |
$91.30 |
1 |
|
| 31 |
275-1269 |
3 foot trim molding |
$61.60 |
1 |
|
| 32 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 33 |
999-0406 |
Washer 5/16 internal star lock zinc plated |
$0.90 |
2 |
|
| 34 |
999-1415 |
Screw M8-1.25 x 12mm hex head stainless steel |
$1.38 |
2 |
|
| 35 |
275-9986 |
10amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
|
|
Frame and Drive Assembly - 275-7791 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3239 |
Front frame weldment |
$174.00 |
1 |
|
| 2 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
13 |
|
| 3 |
275-5197 |
Fir tree clip |
$1.92 |
6 |
|
| 4 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
13 |
(qty 9 before SN 11064202) |
| 5 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
9 |
|
| 6 |
275-9261 |
Static strip with grommet |
$23.90 |
1 |
|
| 7a |
375-2542 |
Rear frame weldment |
$186.00 |
1 |
(after SN 11064201) |
| 7b |
375-3240 |
Rear frame weldment |
$274.10 |
1 |
(before SN 11064202) |
| 8 |
275-8203 |
Molding |
$41.10 |
1 |
|
| 9 |
375-0225 |
Swivel caster wheel |
$69.20 |
2 |
|
| 10 |
999-0519 |
Nut M12-1.75 nylon insert lock stainless steel |
$3.50 |
2 |
|
| 11 |
175-1825 |
Washer |
$4.32 |
2 |
|
| 12a |
375-3173 |
Wheel with taper |
$138.80 |
2 |
|
| 12b |
275-1449 |
Wheel with taper |
$153.20 |
2 |
(before SN 11046266) |
| 12c |
275-5301 |
Solid wheel kit |
$328.40 |
1 |
(includes 12b) (before SN 11046266) |
| 13 |
175-4349 |
Transaxle bracket |
$34.10 |
2 |
|
| 14a |
375-3241 |
24V electronic transaxle |
$1,603.00 |
1 |
(includes 14b-17) |
| 14b |
175-3655 |
Transaxle coupling |
$9.10 |
1 |
|
| 14c |
175-3660 |
Transaxle sleeve |
$9.40 |
1 |
|
| 15 |
275-1447 |
24V transaxle motor |
$579.80 |
1 |
(includes 16) |
| 16 |
175-7898 |
Carbon brush (pkg of 4) |
$60.70 |
1 |
|
| 17 |
275-1448 |
Square keyway |
$3.72 |
2 |
|
| 18 |
375-4024 |
Washer (Tennant Industrial) |
$6.17 |
1 |
|
| 19 |
999-9082 |
Screw M8-1.25 x 25mm hex head stainless steel |
$1.68 |
2 |
(after SN 11064201) |
| 20 |
375-2543 |
Spanning vertical bracket |
$33.90 |
1 |
(after SN 11064201) |
| 21 |
275-5085 |
Nut M6-1 x 16 hex head stainless steel |
$2.76 |
4 |
(after SN 11064201) |
| 22 |
375-2544 |
Spanning angle bracket |
$31.50 |
1 |
(after SN 11064201) |
| 23 |
375-2545 |
Spanning bracket plate |
$24.20 |
1 |
(after SN 11064201) |
| 24 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
5 |
(after SN 11064201) |
| 25 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
2 |
(after SN 11064201) |
| 26 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
3 |
(after SN 11064201) |
| 27 |
375-2546 |
Spanning bracket |
$37.80 |
1 |
(after SN 11064201) |
| 28 |
999-0501 |
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
$2.40 |
1 |
(after SN 11064201) |
| 29 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
2 |
(after SN 11064201) |
|
|
Scrub Head Lift Assembly - Disk - 275-7792 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
275-8726 |
SCREW, HEX, M8 X 1.25 X 130, SS (Tennant Industrial) |
$11.34 |
2 |
|
| 2 |
175-2298 |
Washer .38 x .06 stainless steel |
$4.44 |
2 |
|
| 3 |
175-2199 |
Compression spring |
$5.00 |
2 |
|
| 4 |
375-3244 |
Pm sleeve |
$2.76 |
2 |
|
| 5 |
375-3245 |
Sleeve |
$31.20 |
2 |
|
| 6 |
999-0114 |
Washer 1/2 SAE flat |
$0.90 |
2 |
|
| 7 |
375-3246 |
24V actuator |
$470.20 |
1 |
|
| 8 |
175-2202 |
Nylon wire tie |
$3.72 |
5 |
|
| 9 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
4 |
|
| 10 |
175-4331 |
Cotter hair pin |
$4.44 |
1 |
|
| 11 |
175-2111 |
Clevis pin |
$4.32 |
1 |
|
| 12 |
375-3248 |
Guide bracket |
$20.70 |
1 |
|
| 13 |
375-3249 |
Plastic tube |
$5.70 |
1 |
|
| 14 |
375-3250 |
Scrubhead pivot weldment |
$79.20 |
1 |
|
| 15 |
275-5197 |
Fir tree clip |
$1.92 |
2 |
|
| 16 |
375-3251 |
Leveler screw |
$29.60 |
1 |
|
| 17 |
175-2234 |
Extension spring |
$12.40 |
2 |
|
| 18 |
175-4343 |
1 inch tube |
$5.90 |
2 |
|
| 19 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 20 |
999-0787 |
Bolt M8-1.25 x 40mm hex head full thread stainless steel |
$2.25 |
2 |
|
| 21 |
175-2102 |
Scrub head lifting arm |
$45.40 |
2 |
|
| 22 |
175-2106 |
Cotter hair pin |
$3.11 |
2 |
|
| 23 |
175-2105 |
Clevis pin |
$6.20 |
2 |
|
| 24 |
175-2298 |
Washer .38 x .06 stainless steel |
$4.44 |
2 |
|
| 25 |
175-2443 |
2 1/2 inch compression spring |
$5.00 |
2 |
|
| 26 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
4 |
|
| 27 |
175-4331 |
Cotter hair pin |
$4.44 |
3 |
|
| 28 |
175-4960 |
Clevis pin |
$9.30 |
2 |
|
| 29 |
375-3252 |
Pin holder bracket |
$17.00 |
2 |
|
| 30 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
4 |
|
| 31 |
999-1308 |
Nut M6-1 hex stainless steel |
$0.90 |
4 |
|
| 32 |
175-7839 |
Switch plate |
$30.60 |
1 |
|
| 33 |
375-3253 |
Suspension head spring bracket |
$40.80 |
1 |
|
| 34 |
375-0226 |
Mircroswitch |
$9.40 |
1 |
|
| 35 |
999-1221 |
Screw M3-.5 x 25mm pan head stainless steel |
$0.90 |
2 |
|
| 36 |
175-9603 |
Clevis pin |
$4.44 |
1 |
|
| 37 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
1 |
|
| 38 |
999-1424 |
Nut M8-1.25 hex stainless steel |
$1.50 |
1 |
|
| 39 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 40 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
2 |
|
| 41 |
375-3254 |
Frame weldment stop |
$54.50 |
1 |
(before SN 10972148) |
| 42 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
(before SN 10972148) |
| 43 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
2 |
(before SN 10972148) |
|
|
Scrub Head Lift Assembly - Cylindrical - 275-7793 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
275-8726 |
SCREW, HEX, M8 X 1.25 X 130, SS (Tennant Industrial) |
$11.34 |
2 |
|
| 2 |
175-2298 |
Washer .38 x .06 stainless steel |
$4.44 |
2 |
|
| 3 |
175-2199 |
Compression spring |
$5.00 |
2 |
|
| 4 |
375-3244 |
Pm sleeve |
$2.76 |
2 |
|
| 5 |
375-3245 |
Sleeve |
$31.20 |
2 |
|
| 6 |
999-0114 |
Washer 1/2 SAE flat |
$0.90 |
2 |
|
| 7 |
375-3246 |
24V actuator |
$470.20 |
1 |
|
| 8 |
175-2202 |
Nylon wire tie |
$3.72 |
5 |
|
| 9 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
4 |
|
| 10 |
175-4331 |
Cotter hair pin |
$4.44 |
1 |
|
| 11 |
175-2111 |
Clevis pin |
$4.32 |
1 |
|
| 12 |
375-3248 |
Guide bracket |
$20.70 |
1 |
|
| 13 |
175-7911 |
Roller |
$9.00 |
1 |
|
| 14 |
375-3250 |
Scrubhead pivot weldment |
$79.20 |
1 |
|
| 15 |
275-5197 |
Fir tree clip |
$1.92 |
2 |
|
| 16 |
375-3251 |
Leveler screw |
$29.60 |
1 |
|
| 17 |
175-2234 |
Extension spring |
$12.40 |
2 |
|
| 18 |
175-4343 |
1 inch tube |
$5.90 |
2 |
|
| 19 |
999-9097 |
Washer M8 flat stainless steel |
$0.90 |
2 |
|
| 20 |
999-0787 |
Bolt M8-1.25 x 40mm hex head full thread stainless steel |
$2.25 |
2 |
|
| 21 |
175-2102 |
Scrub head lifting arm |
$45.40 |
2 |
|
| 22 |
175-2106 |
Cotter hair pin |
$3.11 |
2 |
|
| 23 |
175-2105 |
Clevis pin |
$6.20 |
2 |
|
| 24 |
175-2298 |
Washer .38 x .06 stainless steel |
$4.44 |
2 |
|
| 25 |
175-2443 |
2 1/2 inch compression spring |
$5.00 |
2 |
|
| 26 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
4 |
|
| 27 |
175-4331 |
Cotter hair pin |
$4.44 |
3 |
|
| 28 |
175-4960 |
Clevis pin |
$9.30 |
2 |
|
| 29 |
375-3252 |
Pin holder bracket |
$17.00 |
2 |
|
| 30 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
4 |
|
| 31 |
999-1308 |
Nut M6-1 hex stainless steel |
$0.90 |
4 |
|
| 32 |
175-7839 |
Switch plate |
$30.60 |
1 |
|
| 33 |
375-3253 |
Suspension head spring bracket |
$40.80 |
1 |
|
| 34 |
375-0226 |
Mircroswitch |
$9.40 |
1 |
|
| 35 |
999-1221 |
Screw M3-.5 x 25mm pan head stainless steel |
$0.90 |
2 |
|
| 36 |
175-9603 |
Clevis pin |
$4.44 |
1 |
|
| 37 |
999-9097 |
Washer M8 flat stainless steel |
$0.90 |
1 |
|
| 38 |
999-1424 |
Nut M8-1.25 hex stainless steel |
$1.50 |
1 |
|
| 39 |
175-4371 |
Compression spring |
$4.44 |
2 |
|
| 40 |
999-0559 |
Washer 1/2 x 1/4 flat stainless steel |
$0.90 |
4 |
|
| 41 |
999-9097 |
Washer M8 flat stainless steel |
$0.90 |
2 |
|
| 42 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
2 |
|
|
|
Scrub Head Lift Assembly - Orbital - 275-7794 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3246 |
24V actuator |
$470.20 |
1 |
|
| 2 |
175-2111 |
Clevis pin |
$4.32 |
1 |
|
| 3 |
175-4331 |
Cotter hair pin |
$4.44 |
1 |
|
| 4 |
375-3255 |
Clevis pin |
$27.10 |
1 |
|
| 5 |
375-3256 |
Spacer |
$11.90 |
1 |
|
| 6 |
375-3257 |
Scrubhead guide spring pin |
$5.60 |
2 |
|
| 7 |
999-9214 |
Washer M8 flat nylon |
$0.90 |
1 |
|
| 8 |
375-3258 |
Wave spring |
$18.10 |
1 |
|
| 9 |
999-0114 |
Washer 1/2 SAE flat |
$0.90 |
1 |
|
| 10 |
375-3259 |
Thrust washer |
$3.84 |
2 |
|
| 11 |
375-3260 |
Spring |
$6.10 |
2 |
|
| 12 |
275-7716 |
Flanged sleeve (Tennant Industrial) |
$5.17 |
3 |
|
| 13 |
999-0566 |
Washer 1/2 flat nylon |
$0.90 |
6 |
|
| 14 |
175-4720 |
Bearing |
$9.00 |
3 |
|
| 15 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
3 |
|
| 16 |
999-0787 |
Bolt M8-1.25 x 40mm hex head full thread stainless steel |
$2.25 |
2 |
|
| 17 |
999-0770 |
Screw M8-1.25 x 30mm flat head socket stainless steel |
$2.38 |
1 |
|
| 18 |
375-0102 |
Neoprene isolator |
$13.80 |
2 |
|
| 19 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
2 |
|
| 20 |
375-3261 |
Lift weldment bracket |
$32.30 |
1 |
|
| 21 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 22 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
2 |
|
| 23 |
999-1221 |
Screw M3-.5 x 25mm pan head stainless steel |
$0.90 |
6 |
|
| 24 |
375-0226 |
Mircroswitch |
$9.40 |
3 |
|
| 25 |
175-7839 |
Switch plate |
$30.60 |
3 |
|
| 26 |
375-4587 |
Lift arm weldment |
$277.20 |
1 |
|
| 27 |
175-2202 |
Nylon wire tie |
$3.72 |
5 |
|
|
|
Shroud Assembly - 275-7795 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-3262 |
Disk and orbital head cover |
$58.60 |
1 |
|
| 1b |
375-3263 |
Cylindrical head cover |
$89.50 |
1 |
|
| 2 |
999-0507 |
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.90 |
5 |
|
| 3 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
5 |
|
| 4 |
175-0777 |
P/M sleeve |
$5.00 |
3 |
|
|
|
Charger Assembly - 275-7796 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-0182 |
Control column cover |
$134.40 |
1 |
|
| 2 |
175-7872 |
Key switch with 2 keys |
$48.30 |
1 |
(includes 3) |
| 3 |
991-1634 |
Key (pkg of 2) |
$14.21 |
1 |
|
| 4 |
175-2698 |
Switch plug |
$5.50 |
2 |
|
| 5 |
275-1416 |
Safety shut-off switch |
$37.10 |
1 |
|
| 6 |
275-9900 |
Hour meter |
$48.90 |
1 |
|
| 7 |
275-5449 |
Cord hook |
$2.76 |
2 |
(on-board charger) |
| 8 |
175-7660 |
Screw #10-14 x .675 shoulder self-tapping |
$2.76 |
9 |
|
| 9 |
175-7795 |
Cable tie |
$4.32 |
3 |
|
| 10 |
275-5448 |
Charger cover |
$11.20 |
1 |
(on-board charger) (standard) |
| 11 |
175-7507 |
Compression spring |
$3.72 |
1 |
(on-board charger) (qty 2 before SN 10982559) |
| 12 |
175-9855 |
Bolt M6-.8 x 30mm shield |
$7.00 |
1 |
(on-board charger) (qty 2 before SN 10982559) |
| 13a |
375-3264 |
24V 25amp SPE onboard battery charger |
$536.30 |
1 |
(includes 14) (on-board charger) (standard) |
| 13b |
375-1633 |
Off-board battery charger assembly |
$678.00 |
1 |
(includes 14) (off-board charger) (wet and AGM) |
| 13c |
375-2531 |
24V 650W Lithium-ion charger |
$544.30 |
1 |
(includes 14) (off-board charger) (lithium-ion) |
| 13d |
375-9393 |
24V on-board charger |
$639.20 |
1 |
(includes 14) (on-board charger) (TPPL) |
| 13e |
N/A |
Not available |
$0.00 |
1 |
(lithium-ion charger) (on-board charger) (650W lithium-ion) |
| 13f |
N/A |
Not available |
$0.00 |
1 |
(lithium-ion charger) (on-board charger) (1000W lithium-ion) |
| 14 |
991-2103 |
50amp charger plug SB50 with pins (red) |
$7.19 |
1 |
|
| 15a |
275-1585 |
16/3 charger power cord 15 foot (black) |
$73.48 |
1 |
(OEM) |
| 15b |
993-2795 |
16/3 onboard charger power cord 15 foot (black) |
$29.60 |
1 |
(NON-OEM) |
| 16 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
4 |
|
| 17 |
375-3182 |
Column frame |
$102.60 |
1 |
|
| 18 |
275-5443 |
P clamp |
$5.00 |
1 |
(on-board charger) (standard, TPPL and 650W lithium-ino) |
| 19 |
375-9373 |
Screw M6 x 1 x 30, 10.9 |
$1.20 |
1 |
(on-board charger) (after SN 10982558) |
| 20a |
475-1496 |
HARNESS, CHRGR, 12GA [M8 RING/M8 RING] |
$43.60 |
1 |
(includes 21) (standard and TPPL) |
| 20b |
N/A |
Not available |
$0.00 |
1 |
(lithium-ion charger harness) |
| 21 |
991-2103 |
50amp charger plug SB50 with pins (red) |
$7.19 |
1 |
|
| 22 |
175-2894 |
Nut M5-.8 hex nylon locking |
$2.76 |
4 |
(on-board charger) (TPPL and 650W lithium-ion) |
| 23 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
4 |
(on-board charger) (TPPL and 650W lithium-ion) |
| 24 |
375-9380 |
Relay adapter electrical harness |
$90.10 |
1 |
(on-board charger) (TPPL and 650W lithium-ion) |
| 25 |
175-8635 |
40amp relay |
$26.60 |
1 |
(on-board charger) (TPPL and 650W lithium-ion) |
| 26 |
999-0777 |
Screw M4-.7 x 10mm hex head plain finish |
$0.90 |
1 |
(on-board charger) (TPPL and 650W lithium-ion) |
| 27 |
375-9394 |
Charger adapter plate weldment |
$60.60 |
1 |
(off-board, TPPL and 650W lithium-ion) |
| 28 |
375-4592 |
Charger bracket |
$7.80 |
1 |
(on-board charger) (1000W lithium-ion) |
| 29 |
275-5428 |
Wiring harness |
$19.70 |
1 |
(on-board charger) (1000W lithium-ion) |
| 30 |
175-7839 |
Switch plate |
$30.60 |
1 |
(off-board charger) |
| 31 |
375-0226 |
Mircroswitch |
$9.40 |
1 |
(off-board charger) |
| 32 |
375-0046 |
Charger plug bracket |
$27.50 |
1 |
(off-board charger) |
| 33 |
999-1040 |
Screw M3-.5 x 20mm pan head |
$0.90 |
4 |
(off-board charger) |
| 34 |
175-7660 |
Screw #10-14 x .675 shoulder self-tapping |
$2.76 |
2 |
(off-board charger) |
|
|
Console Handle Assembly - 275-7798 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-2547 |
Membrane bezel kit |
$442.20 |
1 |
(includes 2a, 3-5) (pro-membrane panel without telemetry) (requires Tennant True service or an authorized Tennant service provider) (after SN 11062241) |
| 1b |
375-3266 |
Membrane bezel kit |
$568.40 |
1 |
(inclues 2b, 3-5) (pro-membrane panel) (requires Tennant True service or an authorized Tennant service provider) (before SN 11062242) |
| 1c |
375-0241 |
LCD bezel kit |
$1,574.20 |
1 |
(includes 3-5) (pro-panel LCD) (requires Tennant True service or an authorized Tennant service provider) |
| 2a |
375-2548 |
Membrane scren kit |
$89.90 |
1 |
(includes 3-4) (pro-membrane panel without telemetry) (after SN 11062241) |
| 2b |
375-3267 |
Screen kit (OBSOLETE) |
$159.50 |
1 |
(includes 3-4) (pro-membrane panel) (before SN 11062242) |
| 3 |
375-9374 |
Console gasket |
$33.80 |
1 |
(after 02/2020) |
| 4 |
275-5430 |
USB cap |
$6.20 |
1 |
|
| 5 |
375-1351 |
USB to USB mini cable |
$13.90 |
1 |
|
| 6 |
275-5433 |
Switch |
$8.70 |
1 |
|
| 7 |
375-4600 |
Speed range dial |
$7.40 |
1 |
|
| 8 |
275-5452 |
Potentiometer |
$74.30 |
1 |
|
| 9 |
275-5453 |
Toggle cap |
$6.20 |
1 |
|
| 10 |
275-5454 |
Toggle switch assembly |
$69.50 |
1 |
|
| 11 |
275-5434 |
Top handle housing |
$77.50 |
2 |
|
| 12 |
375-3186 |
Screw |
$8.30 |
2 |
|
| 13 |
999-0024 |
Washer 5/16 flat stainless steel |
$1.22 |
3 |
|
| 14 |
275-5436 |
Handle shaft assembly |
$17.20 |
1 |
|
| 15 |
275-5893 |
Seal |
$23.40 |
1 |
|
| 16 |
275-5435 |
Spring |
$26.60 |
1 |
|
| 17 |
275-5437 |
Bottom handle housing |
$78.00 |
1 |
|
| 18 |
275-5438 |
Bail |
$42.10 |
1 |
|
| 19 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
2 |
|
| 20 |
275-5439 |
Handle cover |
$16.40 |
1 |
|
| 21 |
175-7660 |
Screw #10-14 x .675 shoulder self-tapping |
$2.76 |
15 |
|
| 22 |
475-2983 |
SEAL, AFMKT, RBR, CLSD, ADH, 01FT |
$2.88 |
1 |
(after 02/2020) |
|
|
Squeegee Lift Assembly - 275-7800 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
2 |
|
| 2 |
375-3268 |
Squeegee lift weldment bracket |
$54.70 |
1 |
|
| 3 |
375-0071 |
Cotter hair pin |
$1.68 |
3 |
|
| 4 |
175-3341 |
Clevis pin |
$4.44 |
1 |
|
| 5 |
375-3269 |
Spring guide |
$32.30 |
1 |
|
| 6 |
375-3259 |
Thrust washer |
$3.84 |
1 |
(before SN 10871722) |
| 7 |
375-3270 |
Compression spring |
$25.40 |
1 |
|
| 8 |
999-6696 |
Bolt M12-1.75 x 30mm stainless steel hex cap screw |
$4.72 |
2 |
|
| 9 |
999-0559 |
Washer 1/2 x 1/4 flat stainless steel |
$0.90 |
5 |
|
| 10 |
375-3271 |
Squeegee pivot bracket |
$81.40 |
1 |
|
| 11 |
175-7890 |
Sleeved bushing |
$4.44 |
2 |
|
| 12 |
275-8362 |
PIN, CLEVIS, 0.37D X 3.25L (Tennant Industrial) |
$8.60 |
2 |
|
| 13 |
375-0266 |
Lift pedal cover |
$10.20 |
1 |
|
| 14 |
375-3272 |
Squeegee mounting weldment bracket |
$109.30 |
1 |
|
| 15 |
999-0519 |
Nut M12-1.75 nylon insert lock stainless steel |
$3.50 |
2 |
|
| 16 |
175-0939 |
Thrust washer |
$5.00 |
1 |
|
| 17 |
175-3217 |
Washer .91b x 1.38d x .06 steel plated |
$4.44 |
2 |
(between SN 10871722 and SN 10941193) |
| 18 |
175-7839 |
Switch plate |
$30.60 |
1 |
|
| 19 |
375-0226 |
Mircroswitch |
$9.40 |
1 |
|
| 20 |
999-1221 |
Screw M3-.5 x 25mm pan head stainless steel |
$0.90 |
2 |
|
| 21 |
375-4606 |
Spring guide |
$10.40 |
1 |
(after SN 10941193) |
|
|
Squeegee Assembly - 275-7801 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0a |
375-0196 |
20 inch (500mm) squeegee assembly |
$611.40 |
1 |
(includes 1a, 2-3, 4a, 5a, 6, 7, 8a, 9-13, 14a, 15-21, 22a, 23a, 24a, 25a) |
| 0b |
375-7849 |
26 inch squeegee kit |
$335.90 |
1 |
(includes 1b, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22b, 23d, 24d, 25d, 27-30) (after SN 11005985) |
| 0c |
375-3277 |
26 inch (650mm) squeegee assembly |
$394.20 |
1 |
(includes 1b, 1c, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22b, 23d, 24d, 25d, 27-33) (before SN 11005986) (replaced by 0b) |
| 0d |
675-9474 |
700mm squeegee kit |
$353.70 |
1 |
(includes 1d, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22c, 23g, 24g, 25g, 27-30) (after SN 11005985) |
| 0e |
375-3293 |
28 inch (700mm) squeegee assembly |
$402.00 |
1 |
(includes 1d, 1e, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22c, 23g, 24g, 25g, 27-33) (before SN 11005986) (replaced by 0d) |
| 0f |
375-7850 |
32 inch squeegee kit |
$387.40 |
1 |
(includes 1f, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22d, 23j, 24j, 25j, 27-30) (after SN 11005985) |
| 0g |
375-3304 |
32 inch (800mm) squeegee assembly |
$454.80 |
1 |
(includes 1f, 1g, 2, 4b, 5b, 7, 8b, 12, 14b, 15-21, 22d, 23j, 24j, 25j, 27-33) (before SN 11005986) (replaced by 0f) |
| 1a |
375-0197 |
20 inch squeegee weldment |
$194.90 |
1 |
|
| 1b |
375-9375 |
26 inch mach squeegee frame |
$193.40 |
1 |
(after SN 10979888) |
| 1c |
375-9375 |
26 inch mach squeegee frame |
$193.40 |
1 |
(before SN 10979889) (replaced by 1b) |
| 1d |
375-9376 |
28 inch mach squeegee frame |
$210.80 |
1 |
(after SN 10983980) |
| 1e |
375-9376 |
28 inch mach squeegee frame |
$210.80 |
1 |
(before SN 10983981) (replaced by 1d) |
| 1f |
375-9377 |
32 inch mach squeegee frame |
$254.00 |
1 |
(after SN 10996995) |
| 1g |
375-3305 |
32 inch (800mm) squeegee weldment (OBSOLETE) |
$245.00 |
1 |
(before SN 10996996) (replaced by 1f) |
| 2 |
999-1424 |
Nut M8-1.25 hex stainless steel |
$1.50 |
2 |
|
| 3 |
999-0024 |
Washer 5/16 flat stainless steel |
$1.22 |
4 |
(20 inch) |
| 4a |
175-2249 |
Sleeve |
$3.48 |
2 |
(20 inch) |
| 4b |
175-2182 |
Sleeve |
$3.48 |
2 |
(26, 28 and 32 inch) |
| 5a |
175-7919 |
Guide wheel |
$5.00 |
2 |
(20 inch) |
| 5b |
175-2181 |
Wheel |
$9.90 |
2 |
(26, 28 and 32 inch) |
| 6 |
999-0770 |
Screw M8-1.25 x 30mm flat head socket stainless steel |
$2.38 |
2 |
(20 inch) |
| 7 |
375-0262 |
Screw M8-1.25 x 80mm button socket stainless steel |
$15.60 |
2 |
|
| 8a |
375-0261 |
Star knob M8-1.25 |
$8.70 |
4 |
(20 inch) |
| 8b |
275-1552 |
Star knob |
$30.50 |
4 |
(26, 28 and 32 inch) |
| 9 |
175-2592 |
Clevis Pin 0.37 D X 1.75 L |
$4.44 |
2 |
(20 inch) |
| 10 |
375-0071 |
Cotter hair pin |
$1.68 |
2 |
(20 inch) |
| 11 |
175-7931 |
Compression spring |
$4.44 |
2 |
(20 inch) |
| 12 |
275-0143 |
Compression spring |
$4.44 |
2 |
|
| 13 |
999-0787 |
Bolt M8-1.25 x 40mm hex head full thread stainless steel |
$2.25 |
2 |
(20 inch) |
| 14a |
991-2013 |
Wheel |
$8.70 |
2 |
(20 inch) |
| 14b |
175-7953 |
Swivel caster wheel |
$19.80 |
2 |
(26, 28 and 32 inch) |
| 15 |
375-3281 |
Squeegee knob |
$5.00 |
1 |
|
| 16 |
375-0263 |
Squeegee water trap cover |
$7.40 |
1 |
|
| 17 |
375-0265 |
Squeegee water trap gasket |
$3.72 |
1 |
|
| 18 |
175-0152 |
Spacer |
$4.32 |
1 |
|
| 19 |
175-3058 |
Washer 3/4 wave |
$4.32 |
1 |
|
| 20 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
1 |
|
| 21 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
1 |
|
| 22a |
375-0198 |
20 inch (500mm) squeegee retainer |
$72.20 |
1 |
|
| 22b |
375-3285 |
26 inch (600mm) squeegee blade retainer |
$77.90 |
1 |
|
| 22c |
375-3298 |
28 inch (700mm) squeegee blade retainer |
$96.80 |
1 |
|
| 22d |
375-3309 |
32 inch (800mm) squeegee blade retainer |
$88.20 |
1 |
|
| 23a |
375-3274 |
Squeegee blade kit 20 inch (500mm) linatex |
$53.50 |
1 |
(includes 24a, 25a) |
| 23b |
375-3275 |
Squeegee blade kit 20 inch (500mm) urethane |
$91.80 |
1 |
(includes 24b, 25b) (option) |
| 23c |
375-3276 |
Squeegee blade kit 20 inch (500mm) gum rubber |
$30.00 |
1 |
(includes 24c, 25c) (option) |
| 23d |
375-3282 |
Squeegee blade kit 26 inch linatex |
$72.90 |
1 |
(includes 24d, 25d) |
| 23e |
375-3287 |
Squeegee blade kit 26 inch urethane |
$146.10 |
1 |
(includes 24e, 25e) (option) |
| 23f |
375-3290 |
Squeegee blade kit 26 inch gum rubber |
$45.90 |
1 |
(includes 24f, 25f) (option) |
| 23g |
375-3295 |
Squeegee blade kit 28 inch linatex |
$72.90 |
1 |
(includes 24g, 25g) |
| 23h |
375-3316 |
Squeegee blade kit 28 inch urethane |
$87.90 |
1 |
(includes 24h, 25h) (option) |
| 23i |
375-3301 |
Squeegee blade kit 28 inch gum rubber |
$50.90 |
1 |
(includes 24i, 25i) (option) |
| 23j |
375-3306 |
Squeegee blade kit 32 inch linatex |
$81.10 |
1 |
(includes 24j, 25j) |
| 23k |
375-3310 |
Squeegee blade kit 32 inch urethane |
$93.90 |
1 |
(includes 24k, 25k) (option) |
| 23l |
375-3313 |
Squeegee blade kit 32 inch gum rubber |
$50.70 |
1 |
(includes 24l, 25l) (option) |
| 23m |
991-9229 |
BLADE KIT, 800MM, RED |
$32.79 |
1 |
(NON-OEM) |
| 24a |
375-0260 |
Squeegee blade 20 inch (500mm) linatex rear |
$21.20 |
1 |
|
| 24b |
375-1344 |
Squeegee blade 20 inch (500mm) urethane rear |
$64.30 |
1 |
|
| 24c |
375-3276 |
Squeegee blade kit 20 inch (500mm) gum rubber |
$30.00 |
1 |
|
| 24d |
375-3283 |
Squeegee blade 26 inch linatex rear |
$55.30 |
1 |
|
| 24e |
375-3288 |
Squeegee blade 26 inch urethane rear |
$65.40 |
1 |
|
| 24f |
375-3291 |
Squeegee blade 26 inch gum rubber rear |
$15.00 |
1 |
|
| 24g |
375-3296 |
Squeegee blade 28 inch linatex rear |
$55.70 |
1 |
|
| 24h |
375-3299 |
Squeegee blade 28 inch urethane rear |
$66.10 |
1 |
|
| 24i |
375-3302 |
Squeegee blade 28 inch gum rubber rear |
$15.00 |
1 |
|
| 24j |
375-3307 |
Squeegee blade 32 inch linatex rear |
$56.90 |
1 |
|
| 24k |
375-3311 |
Squeegee blade 32 inch urethane rear |
$66.90 |
1 |
|
| 241 |
991-9224 |
BLADE,SQGE,REAR RED(500MM) |
$29.10 |
1 |
(NON-OEM) |
| 24m |
375-3314 |
Squeegee blade 32 inch gum rubber rear |
$15.00 |
1 |
|
| 24n |
991-9264 |
BLADE, SQGE, REAR, 1204L,RED |
$40.27 |
1 |
(NON-OEM) |
| 25a |
375-0199 |
Squeegee blade 20 inch (500mm) linatex front |
$18.70 |
1 |
|
| 25b |
375-1342 |
Squeegee blade 20 inch (500mm) urethane front |
$44.20 |
1 |
|
| 25c |
375-1343 |
Squeegee blade 20 inch (500mm) gum rubber front |
$15.00 |
1 |
|
| 25d |
375-3284 |
Squeegee blade 26 inch linatex front |
$38.60 |
1 |
|
| 25e |
375-3289 |
Squeegee blade 26 inch urethane front |
$42.60 |
1 |
|
| 25f |
375-3292 |
Squeegee blade 26 inch gum rubber front |
$15.00 |
1 |
|
| 25g |
375-3297 |
Squeegee blade 28 inch linatex front |
$39.10 |
1 |
|
| 25h |
375-3300 |
Squeegee blade 28 inch urethane front |
$43.20 |
1 |
|
| 25i |
375-3303 |
Squeegee blade 28 inch gum rubber front |
$15.00 |
1 |
|
| 25j |
375-3308 |
Squeegee blade 32 inch linatex front |
$39.80 |
1 |
|
| 25k |
375-3312 |
Squeegee blade 32 inch urethane front |
$43.80 |
1 |
|
| 25l |
375-3315 |
Squeegee blade 32 inch gum rubber front |
$15.00 |
1 |
|
| 26 |
375-0264 |
Screw M5 captive |
$7.70 |
1 |
(20 inch) |
| 27 |
999-0786 |
Screw M8-1.25 x 35mm hex head stainless steel |
$1.02 |
2 |
(26, 28 and 32 inch) |
| 28a |
999-1625 |
Nut M10-1.5 hex jam stainless steel |
$1.40 |
4 |
(26, 28 and 32 inch) (after SN 11005985) |
| 28b |
991-3164 |
NUT, HEX, JAM, M10 X 1.5, SS |
$2.33 |
4 |
(NON-OEM) |
| 29 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
4 |
(26, 28 and 32 inch) (after SN 10964902) |
| 30 |
375-2507 |
Caster plate |
$11.60 |
2 |
(26, 28 and 32 inch) (after SN 11005985) |
| 31 |
375-4615 |
Right hand squeegee caster bracket weldment |
$37.90 |
1 |
(26, 28 and 32 inch) (before SN 11005986) |
| 32 |
375-4616 |
Left hand squeegee caster bracket weldment |
$37.90 |
1 |
(26, 28 and 32 inch) (before SN 11005986) |
| 33 |
375-3286 |
Squeegee bumper bracket |
$9.40 |
2 |
(26, 28 and 32 inch) (before SN 11005986) |
|
|
Standard Solution Assembly - 275-7803 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-0133 |
24V solution solenoid valve |
$180.50 |
1 |
|
| 1b |
991-9175 |
VALVE, WATER, SOLENOID, 24VDC QF08/QF08 |
$164.30 |
1 |
(NON-OEM) |
| 2 |
375-0156 |
90 degree elbow |
$19.50 |
3 |
(qty 4 before SN 10865727) |
| 3 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
2 |
|
| 4 |
375-0136 |
Straight plastic fitting |
$14.70 |
1 |
|
| 5 |
375-0204 |
5 foot solution hose |
$96.20 |
1 |
|
| 6 |
375-3318 |
Plastic fitting |
$5.60 |
1 |
|
| 7 |
375-0137 |
Plastic fitting |
$17.20 |
1 |
|
| 8a |
375-0138 |
In-line filter |
$14.70 |
1 |
(includes 8b-8d) |
| 8b |
375-0139 |
Gasket |
$3.00 |
1 |
|
| 8c |
375-0140 |
Mesh filter screen |
$8.70 |
1 |
|
| 8d |
175-5868 |
Short clear filter bowl |
$16.80 |
1 |
|
| 8e |
991-3109 |
Strainer assembly |
$14.74 |
1 |
(NON-OEM) |
| 9 |
375-0135 |
90 degree elbow |
$30.40 |
1 |
|
| 10 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
| 11 |
375-4232 |
Plastic fitting |
$10.40 |
1 |
(after SN 10865726) |
| 12 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
(after SN 10865726) |
| 13 |
175-7795 |
Cable tie |
$4.32 |
1 |
|
|
|
Battery Cables Assembly - 275-7804 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3319 |
Cable assembly |
$80.50 |
1 |
|
| 2 |
175-1103 |
Battery cable boot (black) |
$5.00 |
8 |
(qty 4 for TPPL battery) |
| 3 |
375-3320 |
4 gauge battery jumper cable 15 inch (red) |
$29.10 |
1 |
|
| 4 |
175-9591 |
Wire (black) |
$33.00 |
3 |
|
| 5 |
375-9395 |
Cable assembly |
$56.30 |
1 |
(TPPL battery) |
| 6 |
375-9396 |
Cable |
$26.00 |
1 |
(TPPL battery) |
| 7 |
375-3320 |
4 gauge battery jumper cable 15 inch (red) |
$29.10 |
1 |
(TPPL battery) |
| 8 |
375-2549 |
Cable assembly |
$90.70 |
1 |
(Litihum-ion) |
| 9 |
175-6885 |
Boot (black) |
$6.00 |
4 |
(Litihum-ion) |
| 10 |
675-9521 |
Cable (red) |
$20.10 |
1 |
(Litihum-ion) |
| 11 |
175-9591 |
Wire (black) |
$33.00 |
1 |
(Litihum-ion) |
|
|
Decal Assembly - 275-7805 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3321 |
T500 decal |
$93.50 |
2 |
|
| 2 |
375-0248 |
ec-H2O Nano Tennant decal (OBSOLETE) |
$30.20 |
2 |
|
| 3 |
375-3191 |
Tennant decal |
$34.20 |
1 |
|
| 4 |
375-3322 |
Hazard decal kit |
$91.40 |
1 |
|
| 5 |
375-3323 |
Operational decal kit |
$210.80 |
1 |
|
| 6 |
375-3324 |
Orbital decal |
$8.20 |
1 |
|
| 7 |
375-3325 |
Off-board charger decal |
$50.50 |
1 |
|
| 8 |
375-3193 |
Warning decal |
$13.60 |
1 |
|
| 9 |
375-9378 |
Filter info decal |
$0.00 |
1 |
(after SN 10865726) |
| 10 |
375-2550 |
Hazard decal |
$10.60 |
1 |
(Lithium-ion batteries) |
|
|
Wiring Diagram - Standard 1 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Wiring Diagram - Standard 2 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Main Electrical Harness Diagram - 1 - 275-7810 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3326 |
Main electrical harness |
$779.90 |
1 |
|
|
|
Main Electrical Harness Diagram - 2 - 275-7811 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3326 |
Main electrical harness |
$779.90 |
1 |
|
| 2 |
375-3327 |
Operator electrical harness |
$166.10 |
1 |
|
|
|
Main Electrical Harness Diagram - 3 - 275-7812 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3326 |
Main electrical harness |
$779.90 |
1 |
|
|
|
Main Electrical Harness Diagram - 4 - 275-7813 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-7851 |
Electrical harness |
$470.20 |
1 |
|
|
|
Electrical Operator Harness Diagram - 275-7814 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-3327 |
Operator electrical harness |
$166.10 |
1 |
(before SN 11062242) |
| 1b |
375-2558 |
Electrical harness |
$113.20 |
1 |
(after SN 11062241) |
|
|
Telemetry Electrical Assembly - 275-7817 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3231 |
Bracket |
$44.20 |
1 |
|
| 2 |
375-0170 |
Circuit breaker |
$7.70 |
1 |
|
| 3 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 4 |
275-9986 |
10amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
| 5 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 6 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
5 |
|
| 7 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
9 |
|
| 8 |
375-3232 |
60amp circuit breaker |
$23.80 |
1 |
|
| 9 |
999-1026 |
Washer #10 internal lock stainless steel |
$0.90 |
1 |
|
| 10 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
1 |
|
| 11 |
999-0740 |
Nut M5-.8 hex stainless steel |
$0.90 |
1 |
|
| 12 |
375-3233 |
24V relay |
$18.40 |
1 |
|
| 13 |
275-5197 |
Fir tree clip |
$1.92 |
4 |
|
| 14 |
375-3236 |
Control board pad |
$18.40 |
1 |
|
| 15 |
275-0288 |
Washer 1/4 internal-external lock |
$3.60 |
2 |
|
| 16 |
375-3180 |
Bracket |
$53.50 |
1 |
|
| 17 |
375-3234 |
Drive module kit |
$360.50 |
1 |
(requires Tennant True service or an authorized Tennant service provider) |
| 18 |
999-1083 |
Washer #8 internal star lock stainless steel |
$0.90 |
2 |
|
| 19 |
999-1672 |
Screw M4-.7 x 30mm pan head phillips stainless steel |
$0.90 |
2 |
|
| 20a |
475-4183 |
KIT, CONTROL BOARD, TELEM, CI [T500] |
$1,968.30 |
1 |
(includes 20b-21a) (requires Tennant True service or an authorized Tennant service provider) |
| 20b |
275-1425 |
Static ground strap (Tennant Industrial) |
$11.50 |
1 |
|
| 20c |
375-1351 |
USB to USB mini cable |
$13.90 |
1 |
|
| 22d |
175-7795 |
Cable tie |
$4.32 |
1 |
|
| 21a |
375-9391 |
Telem antenna |
$54.80 |
2 |
(after SN 10997157) |
| 21b |
375-0171 |
18 inch antenna (Tennant Industrial) |
$91.35 |
1 |
(before SN 10994158) |
| 22 |
275-5465 |
Standoff |
$1.68 |
1 |
|
| 23 |
375-3337 |
Telemetry sim kit (USA) |
$145.90 |
1 |
|
| 24 |
275-5476 |
Nut M8 x 1.25 hex brass (Tennant Industrial) |
$5.17 |
6 |
|
| 25 |
275-5475 |
Washer M8-.4 x 1.6mm brass |
$2.76 |
3 |
|
| 26 |
999-1053 |
Washer 5/16 internal star lock stainless steel |
$0.90 |
5 |
|
| 27 |
175-4271 |
Screw M8 x 35mm set |
$4.44 |
3 |
|
| 28 |
375-0176 |
Insulated stand-off |
$12.00 |
2 |
|
| 29 |
375-0181 |
Fuse |
$16.40 |
2 |
|
| 30 |
275-5479 |
Nut M6 x 1 (Tennant Industrial) |
$2.80 |
1 |
|
| 31 |
999-0016 |
Washer 1/4 flat plain finish |
$0.90 |
1 |
|
| 32 |
175-4544 |
Washer M6 locking |
$3.72 |
1 |
|
| 33 |
375-3237 |
Circuit board cover gasket |
$48.60 |
1 |
|
| 34 |
375-4562 |
Circuitboard heatsink |
$91.30 |
1 |
|
| 35 |
275-1269 |
3 foot trim molding |
$61.60 |
1 |
|
| 36 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 37 |
999-0406 |
Washer 5/16 internal star lock zinc plated |
$0.90 |
2 |
|
| 38 |
999-1415 |
Screw M8-1.25 x 12mm hex head stainless steel |
$1.38 |
2 |
|
| 39 |
375-4266 |
Bracket |
$46.70 |
1 |
|
| 40 |
375-4267 |
Aluminum spacer |
$8.20 |
2 |
|
| 41 |
375-4013 |
Electrical harness adapter |
$33.90 |
1 |
|
| 42 |
175-2216 |
Diode plug |
$12.00 |
1 |
|
|
|
ec-H20 Solution Assembly - 275-7818 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-0142 |
ec-H2O module kit |
$1,239.50 |
1 |
(includes 2) |
| 2 |
375-0144 |
Nanoclean cartridge |
$275.40 |
1 |
|
| 3 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
3 |
|
| 4 |
375-0075 |
90 degree elbow |
$16.20 |
1 |
|
| 5 |
375-0143 |
Hose |
$105.40 |
1 |
|
| 6 |
375-0079 |
90 degree elbow |
$10.20 |
1 |
|
| 7 |
375-0145 |
PVC hose |
$95.70 |
1 |
|
| 8 |
375-4635 |
ec-H2O bracket weldment |
$50.80 |
1 |
|
| 9 |
375-0146 |
Dispenser pump assembly |
$310.30 |
1 |
|
| 10 |
175-7795 |
Cable tie |
$4.32 |
3 |
|
| 11 |
375-0076 |
Plastic tee fitting |
$17.00 |
1 |
|
| 12 |
375-0150 |
6 foot hose |
$94.30 |
1 |
|
| 13 |
375-0148 |
Plastic tee fitting |
$21.90 |
2 |
|
| 14 |
375-3339 |
90 degree elbow |
$16.50 |
1 |
|
| 15 |
375-0075 |
90 degree elbow |
$16.20 |
1 |
|
| 16 |
375-0152 |
Straight plastic fitting |
$5.00 |
1 |
|
| 17 |
175-8088 |
Brass coupling fitting |
$4.44 |
1 |
|
| 18 |
275-4760 |
Press switch |
$78.30 |
1 |
|
| 19 |
375-0153 |
Check valve |
$41.00 |
1 |
|
| 20 |
375-0156 |
90 degree elbow |
$19.50 |
1 |
|
| 21 |
375-0204 |
5 foot solution hose |
$96.20 |
1 |
|
| 22 |
375-0157 |
Plastic tee fitting |
$23.40 |
1 |
|
| 23 |
175-9693 |
Hose 1/4 x 8 foot (Tennant Industrial) |
$96.35 |
1 |
|
| 24 |
375-0155 |
Solution pump |
$322.10 |
1 |
|
| 25 |
997-2009 |
Hose clamp |
$3.00 |
1 |
|
| 26 |
375-0154 |
90 degree elbow |
$15.90 |
2 |
|
| 27 |
375-0157 |
Plastic tee fitting |
$23.40 |
1 |
|
| 28 |
175-5304 |
Hose clamp |
$3.72 |
3 |
|
| 29 |
275-4947 |
Plastic fitting |
$2.76 |
1 |
|
| 30 |
175-3671 |
Hose clamp |
$4.44 |
1 |
|
| 31 |
275-4773 |
Rocker switch |
$7.00 |
1 |
|
| 32 |
275-9986 |
10amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
| 33 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 34 |
375-1138 |
Plastic fitting |
$4.32 |
2 |
|
| 35 |
175-7795 |
Cable tie |
$4.32 |
1 |
|
| 36 |
275-0288 |
Washer 1/4 internal-external lock |
$3.60 |
1 |
|
| 37 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
(after SN 10865726) |
|
|
Severe Environment Solution Assembly - 275-7819 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
275-3145 |
Screw M5-.8 x 40mm pan head phillips stainless steel |
$6.17 |
2 |
|
| 2a |
375-0159 |
24V pump assembly |
$607.10 |
1 |
(includes 2b-3) |
| 2b |
375-0160 |
24V pump |
$356.90 |
1 |
|
| 2c |
375-0161 |
Hose kit |
$45.10 |
1 |
|
| 3 |
375-0162 |
Potentiometer |
$62.40 |
1 |
|
| 4 |
175-8773 |
Vinyl cap |
$5.50 |
1 |
|
| 5 |
175-4281 |
Potentiometer knob |
$12.80 |
1 |
|
| 6 |
175-2277 |
Nut hex head |
$3.72 |
1 |
|
| 7 |
175-4494 |
Washer M10 |
$3.72 |
1 |
|
| 8 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
2 |
|
| 9 |
375-3340 |
Pump bracket weldment |
$34.20 |
1 |
|
| 10 |
375-3341 |
Clear PVC Hose |
$16.80 |
1 |
|
| 11 |
175-5304 |
Hose clamp |
$3.72 |
4 |
|
| 12 |
175-5305 |
Hose 1/4 x 3 foot |
$47.80 |
1 |
|
| 13 |
375-0148 |
Plastic tee fitting |
$21.90 |
1 |
|
| 14 |
275-8203 |
Molding |
$41.10 |
1 |
|
| 15 |
275-5569 |
Snap cap (Tennant Industrial) |
$6.10 |
1 |
|
| 16 |
375-9390 |
2.3L trimmed tank |
$65.80 |
1 |
|
| 17 |
375-0163 |
Liquid level sensor |
$75.20 |
1 |
|
| 18 |
375-0154 |
90 degree elbow |
$15.90 |
1 |
|
| 19 |
175-3529 |
Brass fitting |
$5.00 |
1 |
|
| 20 |
275-4818 |
Barb fitting |
$4.44 |
1 |
|
| 21 |
375-3344 |
Detergent metering tank decal |
$28.10 |
1 |
|
| 22 |
375-0245 |
Detergent metering decal |
$22.10 |
1 |
|
| 23 |
375-1138 |
Plastic fitting |
$4.32 |
3 |
|
| 24 |
375-9009 |
Sheild plate |
$41.20 |
1 |
|
|
|
Recovery Tank Rinse Assembly - 275-7820 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-3345 |
Recovery tank rinse kit |
$915.70 |
1 |
(includes 1-19) |
| 1 |
275-7874 |
Spray gun nozzle |
$81.60 |
1 |
|
| 2 |
375-3347 |
Garden hose brass fitting |
$17.30 |
1 |
|
| 3 |
175-8087 |
12 Foot black recoil hose |
$124.40 |
1 |
|
| 4 |
375-3348 |
Brass fitting |
$6.10 |
1 |
|
| 5 |
375-3346 |
Plastic fitting |
$7.20 |
1 |
|
| 6 |
175-2152 |
P clamp |
$3.72 |
1 |
|
| 7 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
1 |
|
| 8 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
2 |
|
| 9 |
375-3350 |
Hose hanger bracket |
$27.50 |
1 |
|
| 10 |
375-3351 |
Screw M5-.8 x 30mm stainless steel |
$1.32 |
4 |
|
| 11 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
4 |
|
| 12 |
375-3352 |
24V 60 psi solution pump |
$735.70 |
1 |
|
| 13 |
375-3353 |
90 degree elbow |
$16.90 |
1 |
|
| 14 |
375-0204 |
5 foot solution hose |
$96.20 |
1 |
|
| 15 |
375-0134 |
Plastic tee fitting |
$26.70 |
1 |
|
| 16 |
999-0740 |
Nut M5-.8 hex stainless steel |
$0.90 |
4 |
|
| 17 |
175-5969 |
15amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
| 18 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 19 |
275-4773 |
Rocker switch |
$7.00 |
1 |
|
|
|
Parking Brake Assembly - 275-7821 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3356 |
Parking brake clamp |
$60.00 |
1 |
|
| 2 |
999-1308 |
Nut M6-1 hex stainless steel |
$0.90 |
1 |
|
| 3 |
275-1444 |
Screw M6 x 25mm stainless steel |
$5.00 |
1 |
|
| 4 |
175-5326 |
Screw 4 x 45/64 x 20 pan head stainless steel |
$3.60 |
4 |
|
| 5 |
375-3357 |
Brake plate weldment |
$28.50 |
1 |
|
| 6 |
999-9108 |
Screw M6-1 x 30mm hex head stainless steel |
$0.90 |
2 |
(after SN 11064201) |
| 7 |
175-0550 |
Sleeve |
$4.20 |
2 |
|
| 8a |
375-2553 |
Parking shoe brake |
$37.10 |
1 |
(after SN 11064201) |
| 8b |
375-3358 |
Parking brake shoe |
$23.60 |
1 |
(before SN 11064202) |
| 9 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
9 |
(qty 2 before SN 11064202) |
| 10 |
999-0497 |
Nut M6-1 nylon insert lock stainless steel |
$0.90 |
2 |
|
| 11 |
175-7129 |
Tension spring |
$7.00 |
1 |
|
| 12 |
375-3359 |
Parking brake decal |
$30.60 |
1 |
|
| 13 |
375-2543 |
Spanning vertical bracket |
$33.90 |
1 |
(after SN 11064201) |
| 14 |
375-2544 |
Spanning angle bracket |
$31.50 |
1 |
(after SN 11064201) |
| 15 |
375-2545 |
Spanning bracket plate |
$24.20 |
1 |
(after SN 11064201) |
| 16 |
999-9082 |
Screw M8-1.25 x 25mm hex head stainless steel |
$1.68 |
2 |
(after SN 11064201) |
| 17 |
275-5085 |
Nut M6-1 x 16 hex head stainless steel |
$2.76 |
2 |
(after SN 11064201) |
| 18 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
4 |
(after SN 11064201) |
| 19 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
3 |
(after SN 11064201) |
| 20 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
4 |
(qty 2 before SN 11064202) |
| 21 |
375-2546 |
Spanning bracket |
$37.80 |
1 |
(after SN 11064201) |
| 22 |
999-0501 |
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
$2.40 |
1 |
(after SN 11064201) |
|
|
Solution Tank Auto-Fill Assembly - 275-7822 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-3430 |
Auto fill kit |
$141.30 |
1 |
(includes 1-6) |
| 1 |
375-3431 |
Plastic female fitting |
$40.40 |
1 |
|
| 2 |
375-3432 |
Plastic male fitting |
$9.90 |
1 |
|
| 3 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
4 |
|
| 4 |
375-3433 |
Auto fill cover |
$31.00 |
1 |
|
| 5 |
375-3221 |
Water seal |
$4.92 |
1 |
|
| 6 |
375-3434 |
Float valve |
$86.90 |
1 |
|
|
|
Drain Hose Assembly - 275-7823 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-3435 |
Drain Hose w/valve kit (OBSOLETE) |
$112.60 |
1 |
(includes 2-4) (before SN 10948943) (replaced by 1b) (control valve) |
| 1b |
375-3216 |
Drain hose assembly (black) |
$60.60 |
1 |
(includes 6a and 7a) (after SN 10984820) (pinch cuff screw cap) |
| 2 |
375-0212 |
2 way ball valve (OBSOLETE) |
$77.40 |
1 |
(before SN 10948943) (replaced by 1b) (control valve) |
| 3 |
375-3436 |
Hose assembly with 2 cuffs (gray) (OBSOLETE) |
$47.90 |
1 |
(before SN 10948943) |
| 4 |
997-2000 |
Hose clamp |
$2.15 |
1 |
(before SN 10948943) |
| 5 |
997-2003 |
Hose clamp |
$2.42 |
1 |
|
| 6a |
375-0214 |
Drain cap assembly (black) |
$7.60 |
1 |
(includes 7) (pinch cuff screw cap) |
| 6b |
375-0213 |
Drain cap assembly (gray) |
$7.60 |
1 |
(includes 7) (between SN 10948943 and SN 10984820) (pinch cuff screw cap) |
| 7 |
175-5804 |
O-ring |
$10.70 |
1 |
(pinch cuff screw cap) |
|
|
Smart-Fill Automatic Battery Watering Assembly - After SN 10995398 - 275-7824 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-9386 |
Auto battery fill kit |
$899.00 |
1 |
(includes 1-20) (requires Tennant True servce or an authorized Tennant service provider) |
| 1 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 2 |
275-9986 |
10amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
| 3 |
375-9387 |
Battery water delivery kit |
$313.70 |
1 |
|
| 4 |
375-9384 |
Battery water distribution kit (OBSOLETE) |
$211.90 |
1 |
|
| 5 |
375-4633 |
24V battery controller kit |
$304.40 |
1 |
(requires Tennant True servce or an authorized Tennant service provider) |
| 6 |
175-3179 |
P clamp |
$4.44 |
1 |
|
| 7 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 8 |
999-1087 |
Bolt M6-1 x 25mm hex head stainless steel |
$0.90 |
2 |
|
| 9 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
| 10 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
2 |
|
| 11 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
2 |
|
| 12 |
375-9388 |
Mounting bracket |
$32.40 |
1 |
|
| 13 |
375-9389 |
Battery fill tank kit |
$164.08 |
1 |
(includes 14-19) |
| 14 |
375-3342 |
Snap cap (blue) |
$8.80 |
1 |
|
| 15 |
375-3440 |
Automated battery watering decal |
$27.80 |
1 |
|
| 16 |
375-4250 |
Do not add detergent decal |
$18.70 |
1 |
|
| 17 |
175-4759 |
3/8 inch nylon plug |
$4.44 |
1 |
|
| 18 |
375-4252 |
Pump grommet |
$1.92 |
1 |
|
| 19 |
375-4253 |
13.5V pump |
$39.10 |
1 |
|
| 20 |
275-8203 |
Molding |
$41.10 |
1 |
|
|
|
Hydrolink Manual Battery Watering Assembly - 275-7825 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-0278 |
24V battery fill kit |
$392.10 |
1 |
(includes 1-5) (replaced by 375-9382) (Hydrolink is a rgeistered trademark of trojan battery company) |
| 1 |
275-6999 |
Battery fill pump kit |
$132.90 |
1 |
|
| 2 |
375-3448 |
24V battery water tube |
$160.10 |
1 |
|
| 3 |
375-0001 |
Battery fill cap |
$38.80 |
4 |
|
| 4 |
375-0002 |
Battery tag decal |
$6.90 |
1 |
|
| 5 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
|
|
ec-H2O Nanoclean Module Assembly - 275-7826 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-0142 |
ec-H2O module kit |
$1,239.50 |
1 |
(includes 1a-14) (includes ec-H2O NanoClean cartridge) |
| 1a |
375-0280 |
ec-H2O Kit (plumbing) |
$1,095.50 |
1 |
(includes 1b-13) |
| 1b |
375-0281 |
Upper ec-H2O module housing |
$21.10 |
1 |
|
| 2 |
275-8168 |
Screw M5 x 16mm pan head |
$3.60 |
4 |
|
| 3 |
275-4773 |
Rocker switch |
$7.00 |
1 |
|
| 4 |
999-1947 |
Screw M4-.7 x 50 hex stainless steel |
$1.34 |
4 |
|
| 5a |
375-9400 |
5 plate electrode |
$753.50 |
1 |
(after SN 10983852) |
| 5b |
375-0282 |
High flow 5 plate electrode |
$581.00 |
1 |
(before SN 10983853) |
| 6 |
999-0266 |
Washer #8 SAE flat stainless steel |
$0.90 |
4 |
|
| 7 |
999-0954 |
Nut M4-.7 nylon insert lock stainless steel |
$0.90 |
4 |
|
| 8 |
175-5305 |
Hose 1/4 x 3 foot |
$47.80 |
1 |
|
| 9 |
375-0283 |
Molded hose |
$21.80 |
1 |
|
| 10 |
275-5731 |
Direction decal |
$3.48 |
1 |
|
| 11 |
175-5304 |
Hose clamp |
$3.72 |
1 |
|
| 12 |
175-6081 |
Hose clamp |
$4.40 |
1 |
|
| 13 |
375-0284 |
B2 module harness |
$15.70 |
1 |
|
| 14 |
375-9401 |
Replacement controller kit |
$993.40 |
1 |
|
|
|
Orbital Head Eccentric Drive Assembly - 275-7827 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3204 |
Eccentric drive kit |
$416.00 |
1 |
(includes 2-12) |
| 2 |
375-3199 |
Square key |
$5.00 |
1 |
|
| 3 |
N/A |
Not available |
$0.00 |
1 |
(eccentric balance) (only available in kit) |
| 4 |
N/A |
Not available |
$0.00 |
1 |
(eccentric spacer) (only available in kit) |
| 5 |
999-1383 |
Screw M6-1 x 16mm hex head stainless steel |
$3.60 |
3 |
|
| 6 |
N/A |
Not available |
$0.00 |
1 |
(outer retainer plate) (only available in kit) |
| 7 |
375-3462 |
Ball bearing |
$134.10 |
1 |
|
| 8 |
N/A |
Not available |
$0.00 |
1 |
(outer bearing housing) (only available in kit) |
| 9 |
N/A |
Not available |
$0.00 |
1 |
(inner bearing housing) (only available in kit) |
| 10 |
999-1268 |
Screw M6-1 x 12mm socket head stainless steel |
$0.90 |
2 |
|
| 11 |
375-3463 |
Seal |
$12.70 |
1 |
|
| 12 |
375-0288 |
Screw M6-1 x 35mm flat socket |
$1.68 |
6 |
|
|
|
Battery Assembly - 275-7829 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
162-0003 |
6V 225Ah wet battery (SNSR) |
$245.00 |
4 |
(includes 2) |
| 1c |
162-0043 |
6V 224Ah AGM battery (Group GC2) |
$415.00 |
4 |
(includes 2) |
| 1d |
162-0047 |
12V 215Ah AGM battery (Group J185) |
$825.00 |
2 |
|
| 1e |
375-2540 |
24V Li-ion battery |
$3,182.60 |
1 |
|
| 2 |
999-0211 |
Nut 5/16-18 hex nylon insert lock zinc plated |
$0.90 |
2 |
(wet and AGM) |
| 3 |
275-5948 |
Battery terminal cover (black) |
$3.48 |
8 |
(wet batteries) (qty 2 for 260AH wet) |
| 4a |
175-1352 |
Battery insert |
$14.30 |
1 |
|
| 4b |
375-2513 |
Battery spacer |
$18.50 |
4 |
(Lithium-ion) |
| 5 |
375-3506 |
Trimmed battery tray |
$42.10 |
1 |
|
| 6 |
375-2551 |
Resistor plug |
$73.10 |
1 |
(Lithium-ion 2 battery system) |
| 7 |
675-9523 |
8 postion male to male cable assembly |
$46.20 |
1 |
(Lithium-ion 2 battery system) |
|
|
- Batteries - 275-8492 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
162-0003 |
6V 225Ah wet battery (SNSR) |
$245.00 |
4 |
|
| 2 |
162-0003 |
6V 225Ah wet battery (SNSR) |
$245.00 |
4 |
|
| 3 |
162-0043 |
6V 224Ah AGM battery (Group GC2) |
$415.00 |
4 |
(OEM) |
| 4 |
162-0043 |
6V 224Ah AGM battery (Group GC2) |
$415.00 |
4 |
(NON-OEM) |
|
|
- Chargers - 275-8493 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
375-1633 |
Off-board battery charger assembly |
$678.00 |
1 |
|
| 1b |
991-2103 |
50amp charger plug SB50 with pins (red) |
$7.19 |
1 |
|
| 2a |
375-3264 |
24V 25amp SPE onboard battery charger |
$536.30 |
1 |
|
| 2b |
275-1585 |
16/3 charger power cord 15 foot (black) |
$73.48 |
1 |
(OEM) |
| 2c |
991-8576 |
16/3 power cord 15 foot (black) |
$32.86 |
1 |
(NON-OEM) |
|
|
- Pad Holders - 275-9029 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
991-2214 |
Center-Lok II pad holder - left hand thread (red) |
$21.69 |
|
|
| 2a |
991-2201 |
Center-Lok II pad holder - right hand thread (black) |
$28.62 |
|
(Pad driver side female, Floor side male) |
| 2b |
991-8577 |
Pad retainer |
$23.04 |
|
(Pad driver side male, Floor side female) |
| 3a |
991-2202 |
Big mouth pad holder set (blue) |
$23.64 |
|
(includes 3 screws) |
| 3b |
991-2205 |
Deep lock ring and pad grip ring |
$38.23 |
|
|
| 4 |
991-2203 |
Big mouth pad holder male thread portion |
$37.74 |
|
|
| 5 |
991-2206 |
Center-Lok 3 pad holder |
$35.50 |
|
(includes 3 screws) |
| 6 |
996-0372 |
Big mouth pad holder (left hand thread) |
$23.64 |
|
|
| 7 |
N/A |
Not available |
$0.00 |
|
|
| 8 |
991-2209 |
Split retainer - pad holder ring (OBSOLETE) |
$29.10 |
|
|
| 9 |
N/A |
Not available |
$0.00 |
|
(replaced by #3 991-2202) |
| 10 |
991-2211 |
Center lock pad holding cup (male) (yellow) (OBSOLETE) |
$25.17 |
|
|
|
|
-Simplified Standard Solution System - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
-Simplified ECO-H2O Solution System - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Scrub Head Assembly - Cylindrical - Upper - 375-0140 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
999-1403 |
Screw M8 x 16mm torx head |
$2.64 |
12 |
|
| 2 |
375-3150 |
Skirt cover |
$9.50 |
2 |
|
| 3 |
375-3158 |
Cylindrical side skirt |
$23.30 |
2 |
|
| 4 |
375-3194 |
Belt cover |
$46.40 |
2 |
|
| 5 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
16 |
|
| 6a |
375-3195 |
Belt replacement kit |
$88.10 |
1 |
(includes 6b-7) |
| 6b |
275-4735 |
Drive belt |
$31.90 |
2 |
|
| 7 |
475-3728 |
TOOL, INSTALLATION, BELT |
$119.30 |
1 |
|
| 8 |
475-3930 |
BRACKET ASSY, MOTOR, CI |
$367.90 |
2 |
(includes 9-14) (includes bearings and tube - not available separately) |
| 9 |
275-4737 |
Sheave |
$103.70 |
1 |
|
| 10 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
2 |
|
| 11 |
275-1492 |
Drive shaft |
$131.90 |
1 |
|
| 12 |
275-1489 |
KEY, SQ, 0.19 X 0.19, 0.50L (Tennant Industrial) |
$6.17 |
1 |
|
| 13 |
175-8818 |
Square keyway |
$3.72 |
1 |
|
| 14 |
175-8819 |
Drive plug |
$50.80 |
1 |
|
| 15 |
275-4738 |
Sheave |
$79.40 |
2 |
|
| 16 |
175-4202 |
Square keyway |
$4.44 |
2 |
|
| 17a |
375-3197 |
24V 1500RPM brush motor |
$963.10 |
2 |
(includes 17b) |
| 17b |
275-1458 |
Carbon brush (pkg of 2) |
$200.40 |
1 |
|
| 18 |
275-5309 |
Wiring harness adapter |
$22.70 |
1 |
|
|
|
Scrub Head Assembly - Orbital - 375-0141 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3198 |
24V 2200RPM brush motor |
$1,198.10 |
1 |
(includes 2-3) |
| 2 |
275-9904 |
Carbon brush (pkg of 4) |
$79.40 |
1 |
|
| 3 |
275-1459 |
Brush motor connector harness |
$256.90 |
1 |
|
| 4 |
375-3199 |
Square key |
$5.00 |
1 |
|
| 5 |
275-4736 |
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.72 |
6 |
|
| 6 |
375-3200 |
Weldment bracket |
$82.90 |
1 |
|
| 7 |
375-0102 |
Neoprene isolator |
$13.80 |
13 |
|
| 8 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
1 |
|
| 9 |
375-0108 |
Electrical harness |
$5.90 |
1 |
|
| 10 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
|
| 11 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
6 |
|
| 12 |
175-0117 |
Guide wheel with bushing |
$9.00 |
2 |
|
| 13 |
375-4524 |
Brush housing weldment |
$334.80 |
1 |
|
| 14 |
999-6674 |
Washer 5/16 x 1 1/2 wave stainless steel |
$5.83 |
2 |
|
| 15 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 16 |
999-1297 |
Screw M8 x 50mm hex head stainless steel |
$2.60 |
2 |
|
| 17 |
375-0055 |
Straight plastic fitting |
$12.70 |
1 |
|
| 18 |
375-0291 |
Hose clamp |
$4.44 |
1 |
|
| 19 |
375-4525 |
Spray bar manifold |
$93.90 |
1 |
|
| 20 |
175-0988 |
P clamp |
$3.48 |
5 |
|
| 21 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
4 |
|
| 22 |
999-0740 |
Nut M5-.8 hex stainless steel |
$0.90 |
4 |
|
| 23 |
375-3203 |
Spacer |
$12.70 |
4 |
|
| 24 |
375-3204 |
Eccentric drive kit |
$416.00 |
1 |
|
| 25 |
999-0773 |
Screw M6-1 x 16mm flat socket head stainless steel |
$0.90 |
4 |
|
| 26 |
375-3205 |
Pad driver kit for Orbital heads |
$300.30 |
1 |
(includes 27) (includes driver plate, driver face, and red buffing pad) |
| 27 |
475-2050 |
FACE, PAD DRIVER |
$120.50 |
1 |
|
| 28 |
375-0288 |
Screw M6-1 x 35mm flat socket |
$1.68 |
6 |
|
| 29 |
999-1622 |
Screw M8-1.25 x 25mm flat head phillips stainless steel |
$1.54 |
4 |
|
|
|
Wiring Diagram - Lithium 1 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Wiring Diagram - Lithium 2 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Wiring Diagram - TPPL 1 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Wiring Diagram - TPPL 2 - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Electrical Harness - Bail Switch - 375-0147 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
275-5427 |
Wiring harness |
$8.30 |
1 |
|
|
|
Electrical Harness - TPPL Relay Adapter - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
Manual Battery Watering Assembly - 375-0149 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-9382 |
Manual battery fill kit |
$272.20 |
1 |
(includes 1-4) (this kit is intended for use with Trojan lead acid batteries only) |
| 1 |
375-9383 |
Battery hand pump |
$86.20 |
1 |
|
| 2 |
375-5144 |
Water manifold |
$262.70 |
1 |
|
| 3 |
375-9385 |
Battery tag decal |
$582.20 |
1 |
|
| 4 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
|
|
Severe Environment Lockout Assembly - 375-0151 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-4713 |
Severe environment lockout kit (TENNANT INDUSTRIAL) |
$169.84 |
1 |
(includes 2-3) |
| 2 |
999-0333 |
Screw 10-24 x 1/2 pan head phillips stainless steel |
$0.90 |
1 |
|
| 3 |
375-4714 |
Severe environment knob cover |
$34.30 |
1 |
|
|
|
Automatic Battery Watering Module Assembly - 375-0152 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-4633 |
24V battery controller kit |
$304.40 |
1 |
(includes 2-6) (requires Tennant True service or an authorized Tennant service provider) |
| 2 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
4 |
|
| 3 |
475-1116 |
PANEL, MTG, FILL, AUTO, BATTERY |
$20.70 |
1 |
|
| 4 |
475-0122 |
SEAL, COVER, BOARD, BATTERY WATERING |
$3.12 |
2 |
|
| 5 |
475-2353 |
CIRCUITBOARD ASSY [ABW MODULE] |
$275.60 |
1 |
|
| 6 |
475-1093 |
COVER, CIRCUITBOARD, BATTERY WATERING |
$19.60 |
1 |
|
|
|
Lithium-ion Battery Extension Assembly - 375-0192 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-2552 |
24V lithium-ion battery extension kit - SEE NOTE |
$3,267.90 |
1 |
(includes 1-6) |
| 1 |
375-2540 |
24V Li-ion battery |
$3,182.60 |
1 |
|
| 2 |
175-6885 |
Boot (black) |
$6.00 |
2 |
|
| 3 |
675-9521 |
Cable (red) |
$20.10 |
1 |
|
| 4 |
375-2551 |
Resistor plug |
$73.10 |
1 |
|
| 5 |
675-9523 |
8 postion male to male cable assembly |
$46.20 |
1 |
|
| 6 |
175-9591 |
Wire (black) |
$33.00 |
1 |
|
|
|
Smart-Fill Automatic Battery Watering Assembly - Before SN 10995399 - 375-0193 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1 |
375-3437 |
Plastic fitting |
$38.10 |
1 |
|
| 2 |
275-1748 |
HOSE, PVC, CLR, 0.38ID 0.56OD 027.0L |
$17.20 |
1 |
|
| 3 |
375-3438 |
Check valve |
$17.10 |
1 |
|
| 4 |
175-5305 |
Hose 1/4 x 3 foot |
$47.80 |
1 |
|
| 5 |
175-7303 |
1/4 inch union tee |
$9.40 |
1 |
|
| 6 |
175-7795 |
Cable tie |
$4.32 |
2 |
|
| 7 |
375-2584 |
Flow meter service kit |
$131.60 |
1 |
|
| 8 |
375-3440 |
Automated battery watering decal |
$27.80 |
1 |
|
| 9 |
375-0163 |
Liquid level sensor |
$75.20 |
1 |
|
| 10 |
375-3342 |
Snap cap (blue) |
$8.80 |
1 |
|
| 11a |
375-9390 |
2.3L trimmed tank |
$65.80 |
1 |
|
| 11b |
375-3343 |
Tank |
$69.00 |
1 |
(replaced by 11a) |
| 12a |
375-4250 |
Do not add detergent decal |
$18.70 |
1 |
|
| 12b |
375-3441 |
Warning decal |
$24.40 |
1 |
(replaced by 12a) |
| 13 |
175-5305 |
Hose 1/4 x 3 foot |
$47.80 |
1 |
|
| 14 |
375-0154 |
90 degree elbow |
$15.90 |
1 |
|
| 15 |
375-3442 |
Molded hose |
$20.30 |
1 |
|
| 16 |
999-0531 |
Screw M5-.8 x 16mm pan head slotted zinc |
$0.90 |
2 |
|
| 17 |
999-0998 |
Washer #10 flat stainless steel |
$0.90 |
2 |
|
| 18 |
375-3443 |
Plastic cap fitting |
$3.00 |
1 |
|
| 19 |
375-3444 |
Retaining cap strap |
$2.76 |
1 |
|
| 20 |
375-3445 |
Molded hose |
$29.90 |
1 |
|
| 21 |
375-3446 |
Battery fill pump |
$214.50 |
1 |
|
| 22 |
375-3449 |
In-line filter |
$25.10 |
1 |
|
| 23 |
999-1087 |
Bolt M6-1 x 25mm hex head stainless steel |
$0.90 |
2 |
|
| 24 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
2 |
|
| 25 |
375-4633 |
24V battery controller kit |
$304.40 |
1 |
(requires Tennant True service or an authorized Tennant service provider) |
| 26 |
275-8203 |
Molding |
$41.10 |
1 |
|
| 27 |
175-1661 |
90 degree elbow fitting |
$5.00 |
1 |
|
| 28 |
275-9196 |
Straight brass fitting |
$17.80 |
1 |
|
| 29 |
175-7941 |
Air vent valve |
$58.30 |
1 |
|
| 30 |
275-5197 |
Fir tree clip |
$1.92 |
2 |
|
| 31 |
375-0001 |
Battery fill cap |
$38.80 |
4 |
|
| 32 |
375-3448 |
24V battery water tube |
$160.10 |
1 |
|
| 33 |
275-9986 |
10amp circuit breaker (Tennant Industrial) |
$7.67 |
1 |
|
| 34 |
275-2596 |
Circuit breaker boot (Tennant Industrial) |
$19.34 |
1 |
|
| 35 |
375-1138 |
Plastic fitting |
$4.32 |
1 |
|
| 36 |
175-5304 |
Hose clamp |
$3.72 |
1 |
|
| 37 |
375-9009 |
Sheild plate |
$41.20 |
1 |
|
|
|
Solution Tank Support Bracket Assembly - Before SN 11064202 - 375-0194 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 0 |
375-2554 |
Solution tank support kit |
$148.40 |
1 |
(includes 1-16) |
| 1 |
999-9082 |
Screw M8-1.25 x 25mm hex head stainless steel |
$1.68 |
2 |
|
| 2 |
375-2555 |
Spanning bracket |
$39.30 |
1 |
|
| 3 |
375-2556 |
Spanning bracket |
$36.10 |
1 |
|
| 4 |
999-0335 |
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.90 |
9 |
|
| 5 |
999-1312 |
Screw M6-1 x 20mm hex head stainless steel |
$0.90 |
2 |
|
| 6 |
275-5085 |
Nut M6-1 x 16 hex head stainless steel |
$2.76 |
4 |
|
| 7 |
999-0355 |
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.90 |
4 |
|
| 8 |
999-0496 |
Nut M8-1.25 nylon insert lock stainless steel |
$1.22 |
3 |
|
| 9 |
375-2553 |
Parking shoe brake |
$37.10 |
1 |
|
| 10 |
375-3359 |
Parking brake decal |
$30.60 |
1 |
|
| 11 |
999-9108 |
Screw M6-1 x 30mm hex head stainless steel |
$0.90 |
2 |
|
| 12 |
175-0550 |
Sleeve |
$4.20 |
2 |
(existing part - not included in upgrade kit 375-2554) |
| 13 |
999-0497 |
Nut M6-1 nylon insert lock stainless steel |
$0.90 |
2 |
|
| 14 |
275-5197 |
Fir tree clip |
$1.92 |
1 |
|
| 15a |
375-2546 |
Spanning bracket |
$37.80 |
1 |
|
| 15b |
375-2557 |
Old frame spanning bracket |
$38.40 |
1 |
|
| 16 |
999-0501 |
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
$2.40 |
1 |
|
|
|
- Know Your Machine - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
- Know Your Machine - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
-Simplified Electrical System - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
-Simplified Recovery System - |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
|
- Frequently Replaced Parts - 575-9905 |
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
| 1a |
162-0003 |
6V 225Ah wet battery (SNSR) |
$245.00 |
4 |
|
| 1b |
162-0043 |
6V 224Ah AGM battery (Group GC2) |
$415.00 |
4 |
|
| 1c |
162-0047 |
12V 215Ah AGM battery (Group J185) |
$825.00 |
2 |
|
| 1d |
375-2540 |
24V Li-ion battery |
$3,182.60 |
1 |
|
| 2a |
375-1633 |
Off-board battery charger assembly |
$678.00 |
1 |
|
| 2b |
991-2103 |
50amp charger plug SB50 with pins (red) |
$7.19 |
1 |
|
| 2c |
375-3264 |
24V 25amp SPE onboard battery charger |
$536.30 |
1 |
|
| 2d |
375-1633 |
Off-board battery charger assembly |
$678.00 |
1 |
|
| 2e |
375-2531 |
24V 650W Lithium-ion charger |
$544.30 |
1 |
|
| 2f |
375-9393 |
24V on-board charger |
$639.20 |
1 |
|
| 3a |
275-1585 |
16/3 charger power cord 15 foot (black) |
$73.48 |
1 |
|
| 3b |
991-8576 |
16/3 power cord 15 foot (black) |
$32.86 |
1 |
(NON-OEM) |
| 4a |
175-7872 |
Key switch with 2 keys |
$48.30 |
1 |
|
| 4b |
991-1634 |
Key (pkg of 2) |
$14.21 |
1 |
|
| 5 |
275-5454 |
Toggle switch assembly |
$69.50 |
1 |
|
| 6 |
275-4773 |
Rocker switch |
$7.00 |
1 |
|
| 7 |
375-0133 |
24V solution solenoid valve |
$180.50 |
1 |
|
| 8a |
375-0138 |
In-line filter |
$14.70 |
1 |
|
| 8b |
375-0139 |
Gasket |
$3.00 |
1 |
|
| 8c |
175-5868 |
Short clear filter bowl |
$16.80 |
1 |
|
| 8d |
991-3109 |
Strainer assembly |
$14.74 |
1 |
(NON-OEM) |
| 9a |
375-3274 |
Squeegee blade kit 20 inch (500mm) linatex |
$53.50 |
1 |
(See Squeegee Assembly for individual parts) |
| 9b |
375-3275 |
Squeegee blade kit 20 inch (500mm) urethane |
$91.80 |
1 |
(See Squeegee Assembly for individual parts) |
| 9c |
375-3276 |
Squeegee blade kit 20 inch (500mm) gum rubber |
$30.00 |
1 |
(See Squeegee Assembly for individual parts) |
| 9d |
991-3100 |
BLADE KIT, 500MM, GUM |
$31.12 |
1 |
(NON-OEM) |
| 10a |
375-0220 |
22 inch hose assembly w/cuffs 1 1/2 x 22 in |
$32.09 |
1 |
|
| 10b |
375-3217 |
33 inch hose assembly with cuffs |
$75.90 |
1 |
|
| 10c |
991-3182 |
Vacuum hose with cuffs 1 1/2 |
$24.60 |
1 |
(NON-OEM) |
| 11 |
375-3216 |
Drain hose assembly (black) |
$60.60 |
1 |
|
| 12 |
375-0214 |
Drain cap assembly (black) |
$7.60 |
1 |
|
| 13 |
375-3222 |
Solution drain hose kit |
$42.40 |
1 |
|
| 14a |
375-3435 |
Drain Hose w/valve kit (OBSOLETE) |
$112.60 |
1 |
|
| 14b |
375-3216 |
Drain hose assembly (black) |
$60.60 |
1 |
|
| 15 |
375-0212 |
2 way ball valve (OBSOLETE) |
$77.40 |
1 |
|
| 16 |
375-3436 |
Hose assembly with 2 cuffs (gray) (OBSOLETE) |
$47.90 |
1 |
|
| 17a |
375-0113 |
24V 2 stage vacuum motor |
$415.70 |
1 |
|
| 17b |
275-7693 |
Carbon brush (pkg of 2) |
$25.40 |
1 |
|
| 17c |
991-2430 |
24V 2 stage vacuum motor |
$275.55 |
1 |
(NON-OEM) |
| 18a |
375-1629 |
13 inch nylon scrubbing brush |
$214.40 |
2 |
|
| 18b |
375-1630 |
13 inch polypropelene scrubbing brush |
$289.30 |
2 |
|
| 18c |
375-1631 |
13 inch super abrasive stripping brush |
$335.90 |
2 |
|
| 19a |
275-1348 |
14 inch nylon scrubbing brush |
$288.20 |
2 |
|
| 19b |
275-1350 |
14 inch super abrasive stripping brush |
$511.70 |
2 |
|
| 19c |
275-1350 |
14 inch super abrasive stripping brush |
$511.70 |
2 |
|
| 20a |
275-1352 |
16 inch polypropelene scrubbing brush |
$275.80 |
2 |
|
| 20b |
275-1351 |
16 inch nylon scrubbing brush |
$371.30 |
2 |
|
| 20c |
275-1353 |
16 inch super abrasive stripping brush |
$511.70 |
2 |
|
| 21a |
996-1479 |
13 inch pad driver assembly |
$324.70 |
2 |
|
| 21b |
275-1357 |
14 inch pad driver assembly |
$327.30 |
2 |
|
| 21c |
275-4783 |
16 inch pad driver assembly |
$364.00 |
2 |
|
| 22 |
375-1282 |
Clutch plate kit |
$60.20 |
1 |
|
| 23 |
275-6264 |
Pad centering device |
$42.00 |
1 |
|
| 24a |
996-1039 |
Polypropelene grout scrubbing brush - CYLINDRICAL |
$203.50 |
2 |
|
| 24b |
996-1041 |
Nylon scrubbing brush - CYLINDRICAL |
$297.70 |
2 |
|
| 24c |
996-1042 |
Abrasive scrubbing brush - CYLINDRICAL |
$436.60 |
2 |
|
| 25 |
675-9919 |
Pro-panel upgrade kit |
$1,238.77 |
1 |
|
|
|
- Square Brushes 14 x 28 - 996-1801 |
|
|
| RefNbr |
Part Number |
Description |
Price |
Req |
Notes |
|
996-1891 |
14 x 28 inch Sonic scrub mal-grit strip - 80 grit (black) |
$423.82 |
|
|
|
996-1889 |
14 x 28 inch Sonic scrub clean-grit - 180 grit (blue) |
$423.82 |
|
|
|
996-1888 |
14 x 28 inch Sonic scrub mal-grit lite - 500 grit (red) |
$423.82 |
|
|
|
996-1890 |
14 x 28 inch Sonic scrub mal-grit scrub - 120 grit (green) |
$423.82 |
|
|
|
|
