Batteries - 172-9899 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 01 |
162-0019 |
6V 390Ah wet battery (SNSR) |
6 |
|
| 02 |
172-3449 |
Battery connector kit |
1 |
|
| 03 |
172-1770 |
Connector assembly |
1 |
|
|
|
- Pads - 16 inch - 255-1600 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 01 |
255-1640 |
16 inch aqua plus burnishing pad (pkg of 5) |
|
|
| 02 |
255-1635 |
16 inch Armadillo concrete scrubbing pad (pkg of 5) |
|
|
| 03 |
255-1664 |
16 inch Blue ace pad (pkg of 5) |
|
|
| 04 |
255-1642 |
16 inch Blue Jay burnishing pad (pkg of 5) |
|
|
| 05 |
255-1612 |
16 inch Cure white pad (pkg of 5) |
|
|
| 06 |
255-1677 |
16 inch Diamondback extreme stripping pad (pkg of 5) |
|
|
| 07 |
255-1638 |
16 inch EHD Extra Heavy Duty Concrete Leveling Pad (pkg of 2 |
|
|
| 08 |
255-1621 |
16 inch gorilla lite burnishing pad (pkg of 5) |
|
|
| 09 |
255-1650 |
16 inch gorilla spray buff/polish/burnish pad (pkg of 5) |
|
|
| 10 |
255-1665 |
16 inch Heat concrete bonding pad (pkg of 5) |
|
|
| 11 |
255-1630 |
16 inch jaguar burnishing pad (pkg of 5) |
|
|
| 12 |
255-1687 |
16 inch Melamine Mela-Kleen pad (pkg of 2) |
|
|
| 13 |
255-1690 |
16 inch premium black stripping pad (pkg of 5) |
|
|
| 14 |
255-1670 |
16 inch premium blue cleaning pad (pkg of 5) |
|
|
| 15 |
255-1692 |
16 inch premium brown stripping pad (pkg of 5) |
|
|
| 16 |
255-1680 |
16 inch premium green scrubbing pad (pkg of 5) |
|
|
| 17 |
255-1660 |
16 inch premium red scrubbing pad (pkg of 5) |
|
|
| 18 |
255-1652 |
16 inch premium tan polishing pad (pkg of 5) |
|
|
| 19 |
255-1620 |
16 inch premium white polishing pad (pkg of 5) |
|
|
| 20 |
255-1611 |
16 inch superspeed rubberized pad (pkg of 5) |
|
|
| 21 |
255-1695 |
16 inch razorback stripping pad (pkg of 5) |
|
|
| 22 |
255-1647 |
16 inch Redwood maroon floor prep pad (pkg of 10) |
|
|
| 23 |
255-1655 |
16 inch Ruff non-abrasive brush pad (pkg of 2) |
|
|
| 24 |
255-1623 |
16 inch sand screen driver pad (pkg of 2) |
|
|
| 25 |
255-0132 |
16 inch Professional sand screen 100 grit (pkg of 10) |
|
|
| 26 |
255-0133 |
16 inch Professional sand screen 120 grit (pkg of 10) |
|
|
| 27 |
255-0134 |
16 inch Professional sand screen 150 grit (pkg of 10) |
|
|
| 28 |
255-0135 |
16 inch Professional sand screen 180 grit (pkg of 10) |
|
|
| 29 |
255-0136 |
16 inch Professional sand screen 220 grit (pkg of 10) |
|
|
| 30 |
255-0137 |
16 inch Professional sand screen 400 grit (pkg of 10) |
|
|
| 31 |
255-0130 |
16 inch Professional sand screen 60 grit (pkg of 10) |
|
|
| 32 |
255-0131 |
16 inch Professional sand screen 80 grit (pkg of 10) |
|
|
| 33 |
255-0217 |
16 inch Superscreen sand screen 100 grit (pkg of 10) |
|
|
| 34 |
255-0218 |
16 inch Superscreen sand screen 120 grit (pkg of 10) |
|
|
| 35 |
255-0219 |
16 inch Superscreen sand screen 150 grit (pkg of 10) |
|
|
| 36 |
255-0220 |
16 inch Superscreen sand screen 180 grit (pkg of 10) |
|
|
| 37 |
255-0221 |
16 inch Superscreen sand screen 220 grit (pkg of 10) |
|
|
| 38 |
255-0222 |
16 inch Superscreen sand screen 400 grit (pkg of 10) |
|
|
| 39 |
255-0215 |
16 inch Superscreen sand screen 60 grit (pkg of 10) |
|
|
| 40 |
255-0216 |
16 inch Superscreen sand screen 80 grit (pkg of 10) |
|
|
| 41 |
255-1624 |
16 inch Tiger carpet bonnet (pkg of 2) |
|
|
| 42 |
255-9563 |
16 inch Diamond by Gorilla 11000 Grit (pkg of 2) |
|
|
| 43 |
255-9560 |
16 inch Diamond by Gorilla 1500 Grit (pkg of 2) |
|
|
| 44 |
255-9557 |
16 inch Diamond by Gorilla 200 Grit (pkg of 2) |
|
|
| 45 |
255-9561 |
16 inch Diamond by Gorilla 3000 Grit (pkg of 2) |
|
|
| 46 |
255-9558 |
16 inch Diamond by Gorilla 400 Grit (pkg of 2) |
|
|
| 47 |
255-9559 |
16 inch Diamond by Gorilla 800 Grit (pkg of 2) |
|
|
| 48 |
255-9562 |
16 inch Diamond by Gorilla 8000 Grit (pkg of 2) |
|
|
| 49 |
255-9641 |
16 inch Diamond starter pack (1 of each grit) |
|
|
| 50 |
255-1682 |
16 inch Turbostrip segmented rotary pad (pkg of 4) |
|
|
| 51 |
255-1615 |
16 inch Duala clean and shine pad - low speed (pkg of 5) |
|
|
| 52 |
255-1616 |
16 inch 2001 Duala clean and shine pad - high speed (pkg 5) |
|
|
|
|
Chassis Assembly - 272-6071 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 2 |
999-0114 |
Washer 1/2 SAE flat |
2 |
|
| 3 |
272-5393 |
Screw 5/16-18 x 4 hex head full thread |
1 |
|
| 4 |
172-2001 |
Hair cotter pin |
1 |
|
| 5 |
999-1128 |
Bolt M12-1.75 x 35mm hex hd stainless steel part thread |
2 |
|
| 6 |
272-1605 |
Bolt M10-1.5 x 20mm hex head nylon lock |
2 |
|
| 7 |
999-0430 |
Nut 5/16-18 hex jam plain finish |
1 |
|
| 8 |
172-2067 |
Washer 11/32 x 1/8 flat |
2 |
|
| 12 |
999-1129 |
Screw 1/4-20 x 1/2 pan head phillips thread rolling zinc |
1 |
|
| 13 |
272-1843 |
Flanged bearing |
2 |
|
| 14a |
172-3283 |
Wheel and bearing assembly |
2 |
(each assembly includes two bearings) |
| 14b |
272-3931 |
Ball bearing |
4 |
|
| 15 |
172-3286 |
Actuator pin |
1 |
|
| 16 |
272-0404 |
Arm weldment linkage |
1 |
|
| 17 |
272-6040 |
Chassis weldment |
1 |
|
| 18 |
999-0406 |
Washer 5/16 internal star lock zinc plated |
1 |
|
| N/S |
997-2101 |
6 inch cable tie |
5 |
|
|
|
Detergent Injection Assembly - AXP/EDS - 272-6072 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 0a |
272-9954 |
Detergent injection assembly |
1 |
(includes 1-21)(only used on AXP models) |
| 0b |
272-6041 |
Detergent injection assembly |
1 |
(includes 1-22) (only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 1 |
172-0369 |
Washer 17/64 x 3/4 x 23/64 flat |
3 |
|
| 2 |
997-2103 |
8 inch cable tie |
2 |
|
| 3 |
999-0211 |
Nut 5/16-18 hex nylon insert lock zinc plated |
8 |
|
| 4 |
999-0152 |
Nut 1/4-20 nylon insert lock zinc plated |
2 |
|
| 5 |
999-0508 |
Screw 1/4-20 x 1/2 pan head phillips zinc plated |
3 |
|
| 6 |
172-4451 |
Screw 1/4-20 x 3/8 pan phillips stainless steel |
5 |
|
| 7 |
272-2174 |
Snub bushing |
1 |
|
| 8 |
172-0032 |
Gasket 1/16 x 1/2 x 120 (OBSOLETE) |
1 |
|
| 9a |
272-9955 |
Control assembly |
1 |
(only used on AXP models) |
| 9b |
272-6042 |
Control assembly |
1 |
(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 10a |
272-5397 |
Control decal |
1 |
(only used on AXP models) |
| 10b |
272-6043 |
Graphic overlay |
1 |
(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 11 |
272-5398 |
Detergent tray |
1 |
|
| 12a |
272-5399 |
Detergent box weldment |
1 |
(only used on AXP models) |
| 12b |
272-6044 |
Chemical box weldment |
1 |
(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 13 |
272-5400 |
Detergent cover |
1 |
|
| 15 |
272-6046 |
Detergent pad |
1 |
|
| 16 |
272-5403 |
Detergent pump |
1 |
|
| 17 |
272-5404 |
Chemical resistant hose |
1 |
|
| 18a |
272-2179 |
Chemical bottle assembly |
1 |
(only used on AXP models) |
| 18b |
272-2346 |
Indicator assembly |
1 |
(only used on AXP models) |
| 18c |
272-9375 |
Chemical bottle assembly |
|
(includes 18-20)(only used on AXP models) |
| 18d |
272-9832 |
Chemical bottle assembly |
1 |
(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 18e |
272-9833 |
Chemical bottle assembly |
1 |
(includes 18-20)(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
| 19 |
272-2180 |
Solution fill cap |
1 |
|
| 20 |
272-2184 |
Dry break insert |
1 |
|
| 21 |
272-2182 |
Dry break cap |
1 |
|
| 22 |
272-6047 |
Chemical ratio decal |
1 |
(only used on EcoFlex models. AXP models are no longer in production and have been replaced by EcoFlex models) |
|
|
Drive and Brake Pedal Assembly - 272-6073 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
172-3308 |
Pedal weldment |
1 |
(includes 2-9) |
| 2 |
999-0123 |
Washer 1/4 SAE flat zinc plated |
4 |
|
| 3 |
999-0507 |
Bolt M6-1 x 16mm hex head full thread plain finish |
1 |
|
| 4 |
999-0469 |
Nut M6-1 nylon insert lock zinc plated |
5 |
|
| 5 |
999-1162 |
Bolt M6-1 x 75mm hex head part thread zinc |
3 |
|
| 8 |
272-6049 |
Brake bracket |
1 |
|
| 9 |
272-6050 |
Pedal weldment |
1 |
|
| 10 |
999-0522 |
Screw 1/4-20 x 1/2 pan head phillips stainless steel |
2 |
|
| 11 |
272-8880 |
Foot pedal assembly |
1 |
|
| 12 |
272-6051 |
Pedal mounting plate |
1 |
|
| 13 |
999-0152 |
Nut 1/4-20 nylon insert lock zinc plated |
2 |
|
| 14 |
999-1895 |
Screw 1/4-20 x 7/8 flat head phillips stainless steel |
2 |
|
| 15 |
999-0510 |
Screw 1/4-20 x 1 pan head phillips zinc plated |
1 |
|
| 16 |
999-0567 |
Screw 1/4-20 x 5/8 pan head phillips stainless steel |
4 |
|
|
|
Electrical Panel Assembly - 272-6074 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
272-5406 |
Electrical panel |
1 |
|
| 2 |
999-0509 |
Screw 1/4-20 x 3/8 pan head phillips zinc plated |
9 |
|
| 3 |
999-1131 |
Screw 8-32 x 3/8 pan head phillips thread rolling SS |
1 |
|
| 4 |
172-8839 |
Backup alarm |
1 |
|
| 5 |
172-0103 |
Electrical mount |
3 |
|
| 6 |
172-0345 |
Terminal stud |
3 |
|
| 7a |
172-8836 |
150amp fuse |
1 |
|
| 7b |
991-3061 |
150amp fuse |
1 |
(NON-OEM) |
| 8 |
999-0029 |
Bolt 5/16-18 x 1/2 hex head plain finish |
4 |
|
| 9 |
999-0406 |
Washer 5/16 internal star lock zinc plated |
4 |
|
| 10 |
999-0152 |
Nut 1/4-20 nylon insert lock zinc plated |
3 |
|
| 12 |
272-8184 |
36V 100amp contactor |
1 |
(Vacuum motor) |
| 14 |
272-5407 |
Electrical cover |
1 |
|
| 15 |
999-0123 |
Washer 1/4 SAE flat zinc plated |
6 |
|
| 16 |
999-0567 |
Screw 1/4-20 x 5/8 pan head phillips stainless steel |
2 |
|
| 17 |
172-0232 |
Clear boot cap |
1 |
|
| 18 |
172-0231 |
Reset button boot |
1 |
|
| 19 |
272-8183 |
36V 200amp contactor |
1 |
(Brush drive) |
| 20 |
272-8183 |
36V 200amp contactor |
1 |
(Drive wheel) |
| 21 |
999-0430 |
Nut 5/16-18 hex jam plain finish |
4 |
|
| 22 |
999-0267 |
Screw 10-24 x 1/2 pan head phillips zinc |
3 |
|
| 23 |
272-6052 |
Speed controller |
1 |
|
| 24 |
172-2160 |
10amp circuit breaker |
1 |
(Circuit control) |
| 25 |
172-2523 |
70amp circuit breaker |
1 |
(Drive wheel) |
| 26 |
272-5409 |
Harness guide weldment |
1 |
(Detergent injection models only) |
| 27 |
999-0567 |
Screw 1/4-20 x 5/8 pan head phillips stainless steel |
4 |
|
|
|
Front Wheel Assembly - 272-6075 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
999-0005 |
Screw 5/16-18 x 7/8 socket head |
1 |
|
| 2 |
999-0211 |
Nut 5/16-18 hex nylon insert lock zinc plated |
1 |
|
| 3 |
272-1652 |
Bolt 3/8-16 x 5/6 lock |
4 |
|
| 4 |
999-1379 |
Screw M8-1.25 x 70mm socket head stainless steel |
4 |
|
| 5 |
999-1828 |
Screw M8-1.25 x 55mm socket head stainless steel |
4 |
|
| 6 |
172-2067 |
Washer 11/32 x 1/8 flat |
1 |
|
| 8 |
172-3316 |
Bearing cone |
1 |
|
| 10 |
172-0435 |
Top bearing |
1 |
|
| 12 |
172-0951 |
Nut 1-14 hex thin nylock UNF |
1 |
|
| 13 |
991-5122 |
1/4 nylon tree push-in rivet |
3 |
|
| 14 |
172-3319 |
Bearing block |
1 |
|
| 15 |
172-3320 |
Steering plate |
1 |
|
| 17a |
272-7361 |
Drive motor |
1 |
|
| 17b |
272-5411 |
Drive wheel |
1 |
(Wheel only) |
| 18 |
172-3327 |
Splash guard plate |
1 |
|
| 19 |
172-3328 |
Splash guard |
1 |
|
| 20 |
172-3329 |
Spindle weldment |
1 |
|
| 22 |
999-1556 |
Screw M4-.7 x 8mm pan head phillips zinc plated |
1 |
|
| 23 |
999-1861 |
Screw 10-24 x 7/8 pan head phillips stainless steel |
1 |
|
| 24 |
999-0960 |
Nut 10-24 hex stainless steel |
1 |
|
| 25 |
999-0377 |
Washer 6 SAE flat plain finish |
1 |
|
| N/S |
272-6053 |
Front wheel service kit |
1 |
(kit includes 1 connectio box, 2 curved brushes, 1 brush holder and hardware) |
| N/S |
272-6054 |
Drive motor kit |
1 |
|
| N/S |
272-6055 |
Drive wheel harness kit |
1 |
|
|
|
Recovery Assembly - 272-6076 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
999-0477 |
Screw 10-24 x 5/16 truss head phillips zinc |
8 |
|
| 2 |
999-0123 |
Washer 1/4 SAE flat zinc plated |
7 |
|
| 3 |
999-1030 |
Screw 1/4-20 x 2 pan head phillips stainless steel |
6 |
|
| 4 |
999-0456 |
Screw 1/4-20 x 3/4 pan head phillips stainless steel |
4 |
|
| 5 |
999-0419 |
Screw 1/4-20 x 5/8 flat head slotted zinc plated |
12 |
|
| 6 |
999-0399 |
Screw 5/16-18 x 3/4 pan head phillips zinc plated |
1 |
|
| 7 |
999-0332 |
Screw 10-24 x 5/8 pan head phillips stainless steel |
5 |
|
| 8 |
182-0034 |
Screw 10-14 x 1/2 pan head plastite |
2 |
|
| 9 |
172-0517 |
Float cage half (2 required for full float cage) |
2 |
|
| 10 |
272-1253 |
Vacuum hose 2 x 6 |
1 |
|
| 14 |
272-1159 |
Plastic clamp |
1 |
|
| 16 |
172-3169 |
Plastic clamp |
1 |
|
| 17 |
172-3335 |
Foam cylinder |
2 |
|
| 19 |
172-3337 |
Top panel muffler |
1 |
|
| 20 |
172-3338 |
Bottom panel muffler |
1 |
|
| 21 |
272-6565 |
Gasket strip |
1 |
|
| 22 |
172-3333 |
Cover pivot pin |
1 |
|
| 23 |
272-8999 |
Exhaust cover |
1 |
|
| 24 |
172-0126 |
Acoustical foam |
1 |
|
| 25 |
272-9000 |
Vacuum motor cover |
1 |
|
| 26 |
272-9139 |
Recovery tank lid |
1 |
|
| 27 |
172-3344 |
Tank mount bracket |
2 |
|
| 28 |
999-1862 |
Washer #10 flat SAE stainless steel |
9 |
|
| 29 |
172-3346 |
Recovery tank lid gasket |
1 |
|
| 30 |
172-3347 |
Filter screen |
1 |
|
| 32 |
172-3349 |
Separator plate |
1 |
|
| 33 |
172-3357 |
9 inch wire rope |
1 |
|
| 34 |
272-5303 |
Recovery tank lid and gasket |
1 |
|
| 35 |
172-3351 |
Vibration mount |
3 |
|
| 36 |
172-3353 |
Vacuum muffler |
1 |
|
| 39a |
272-6298 |
Vacuum hose assembly |
1 |
(OEM) |
| 39b |
991-5152 |
Vacuum hose assembly |
1 |
(NON-OEM) |
| 40 |
272-5412 |
Recovery tank |
1 |
|
| 41a |
272-5577 |
Drain hose |
1 |
|
| 41b |
375-3216 |
Drain hose assembly (black) |
1 |
|
| 42 |
272-6033 |
Rear bumper |
2 |
|
| 43 |
272-6034 |
Rear middle bumper |
1 |
|
| 44 |
272-0430 |
Vacuum duct gasket |
2 |
|
| 46a |
272-9272 |
36V 3 stage vacuum motor |
1 |
(OEM) |
| 46b |
991-1237 |
36V 3 stage vacuum motor bypass dual ball tangential |
1 |
(NON-OEM) |
| 46c |
991-1221 |
Carbon brush without plastic cover (pkg of 2) |
1 |
|
| 48 |
272-6778 |
Strainer basket |
1 |
|
| 49 |
272-6035 |
Recovery tank tube |
1 |
|
| N/S |
272-8537 |
Drain hose cap assembly |
1 |
|
| N/S |
272-9273 |
Drain hose extension |
1 |
|
| N/S |
172-3359 |
Vacuum harness |
1 |
|
|
|
Scrub Deck Assembly - Disc - |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
|
|
Squeegee Assembly - 272-6082 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 0a |
272-6036 |
28 inch squeegee assembly |
1 |
(These squeegee assemblies include red gum rubber blades. The squeegee tool casting is not available for sale separately. If you need to replace the casting please order a complete squeegee assembly.) |
| 0b |
272-6037 |
34 inch squeegee assembly |
1 |
(These squeegee assemblies include red gum rubber blades. The squeegee tool casting is not available for sale separately. If you need to replace the casting please order a complete squeegee assembly.) |
| 0c |
272-5565 |
Squeegee assembly |
1 |
(These squeegee assemblies include red gum rubber blades. The squeegee tool casting is not available for sale separately. If you need to replace the casting please order a complete squeegee assembly.) |
| 1 |
999-0423 |
Nut 5/16-18 nylon insert lock stainless steel |
2 |
|
| 2 |
999-0688 |
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
2 |
|
| 3 |
999-0227 |
Nut 6-32 hex nylon insert lock jam zinc plated |
2 |
(before May 2012) |
| 4 |
999-0336 |
Screw 6-32 x 3/8 pan head phillips stainless steel |
2 |
(before May 2012) |
| 5 |
999-9004 |
Washer 5/16 SAE flat stainless steel |
2 |
|
| 6 |
999-0688 |
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
1 |
|
| 7 |
272-3671 |
Screw 5/16-18 x 1 1/4 thumb stainless steel |
1 |
|
| 8 |
999-1019 |
Nut 5/16-18 hex jam stainless steel |
1 |
|
| 10 |
172-4099 |
Nut 5/16-18 thumb |
2 |
|
| 11 |
172-0094 |
Latch |
1 |
(before May 2012) |
| 13a |
272-3677 |
Front strap |
1 |
(28" models) |
| 13b |
272-3683 |
Front strap |
1 |
(32" and 35" models) |
| 13c |
272-7393 |
Front strap |
1 |
(38" models) |
| 14a |
272-3679 |
Band clamp |
1 |
(28" models after May 2012) |
| 14b |
272-3686 |
Band clamp |
1 |
(32" and 35" models after April 2012) |
| 14c |
272-6038 |
Band clamp assembly |
1 |
(38" models after June 2012) |
| 16a |
272-3675 |
Squeegee blade kit 28 inch Linatex (red) |
1 |
(28" models after October 2011)(squeegee blade kits include both front and rear squeegee blades)(these squeegee blades are desinged to provide increased performance and reduced streaking. When installing thse blades on a machine built before November 2011 you must also order a new rear strap part number 272-7285) |
| 16b |
272-3675 |
Squeegee blade kit 28 inch Linatex (red) |
1 |
(28" models before November 2011)(squeegee blade kits include both front and rear squeegee blades) |
| 16c |
272-3682 |
Squeegee blade kit 34 inch gum rubber (red) |
1 |
(32" and 35" models)(squeegee blade kits include both front and rear squeegee blades) |
| 16d |
272-7171 |
Squeegee blade kit red gum rubber |
1 |
(38" models)(squeegee blade kits include both front and rear squeegee blades) |
| 16e |
272-3672 |
Squeegee blade kit 28 inch gum rubber |
1 |
(after October 2011)(squeegee blade kits include both front and rear squeegee blades)(these squeegee blades are desinged to provide increased performance and reduced streaking. When installing thse blades on a machine built before November 2011 you must also order a new rear strap part number 272-7285)(optional) |
| 16f |
272-8961 |
Squeegee blade kit 28 inch gum rubber |
1 |
(before November 2011)(squeegee blade kits include both front and rear squeegee blades)(optional) |
| 16g |
272-3675 |
Squeegee blade kit 28 inch Linatex (red) |
1 |
(standard after October 2011)(squeegee blade kits include both front and rear squeegee blades)(these squeegee blades are desinged to provide increased performance and reduced streaking. When installing thse blades on a machine built before November 2011 you must also order a new rear strap part number 272-7285) |
| 16h |
272-3675 |
Squeegee blade kit 28 inch Linatex (red) |
1 |
(standard after November 2011)(squeegee blade kits include both front and rear squeegee blades) |
| 16i |
272-3673 |
Squeegee blade kit 28 inch urethane |
1 |
(after October 2011)(squeegee blade kits include both front and rear squeegee blades)(these squeegee blades are desinged to provide increased performance and reduced streaking. When installing thse blades on a machine built before November 2011 you must also order a new rear strap part number 272-7285)(optional) |
| 16j |
272-3673 |
Squeegee blade kit 28 inch urethane |
1 |
(before November 2011)(squeegee blade kits include both front and rear squeegee blades)(32" and 35" model squeegee blade kits)(optional) |
| 16k |
172-4688 |
Squeegee blade kit 34 inch gum rubber |
1 |
(squeegee blade kits include both front and rear squeegee blades)(optional) |
| 16l |
272-3682 |
Squeegee blade kit 34 inch gum rubber (red) |
1 |
(standard)(squeegee blade kits include both front and rear squeegee blades) |
| 16m |
572-8127 |
Polyurethane squeegee blade kit (L) |
1 |
(squeegee blade kits include both front and rear squeegee blades)(38" model squeegee blade kits)(optional) |
| 16n |
272-6039 |
Squeegee blade kit 38 inch gum rubber |
1 |
(squeegee blade kits include both front and rear squeegee blades)(optional) |
| 16o |
272-7171 |
Squeegee blade kit red gum rubber |
1 |
(standard)(squeegee blade kits include both front and rear squeegee blades)(optional) |
| 16p |
272-6617 |
Squeegee blade kit 28 inch urethane |
1 |
(squeegee blade kits include both front and rear squeegee blades)(optional) |
| 17a |
272-7285 |
28 inch weldment and rear band kit |
1 |
(28" models before June 2012) |
| 17b |
272-3684 |
Rear strap |
1 |
(32" and 35" models before May 2012) |
| 17c |
272-7392 |
Rear strap |
1 |
(38" models before July 2012) |
|
|
Solution Assembly - Standard - 272-6097 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
999-0024 |
Washer 5/16 flat stainless steel |
4 |
|
| 2 |
999-1862 |
Washer #10 flat SAE stainless steel |
3 |
|
| 3 |
999-0454 |
Screw 10-24 x 1/2 truss head phillips zinc plated |
4 |
|
| 4 |
999-0030 |
Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated |
4 |
|
| 5 |
999-0571 |
Screw 10-24 x 3/8 pan head phillips stainless steel |
3 |
|
| 6 |
999-0567 |
Screw 1/4-20 x 5/8 pan head phillips stainless steel |
3 |
|
| 7 |
999-0123 |
Washer 1/4 SAE flat zinc plated |
11 |
|
| 8 |
999-1030 |
Screw 1/4-20 x 2 pan head phillips stainless steel |
1 |
|
| 9 |
999-0456 |
Screw 1/4-20 x 3/4 pan head phillips stainless steel |
2 |
|
| 10 |
999-1376 |
Screw 6-32 x 1/2 hex head stainless steel |
1 |
|
| 11 |
999-0400 |
Screw 10-24 x 1 pan head phillips zinc plated |
5 |
|
| 12 |
272-6099 |
Front middle bumper |
1 |
|
| 13 |
999-0399 |
Screw 5/16-18 x 3/4 pan head phillips zinc plated |
2 |
|
| 14 |
999-0211 |
Nut 5/16-18 hex nylon insert lock zinc plated |
1 |
|
| 15 |
999-0227 |
Nut 6-32 hex nylon insert lock jam zinc plated |
1 |
|
| 16 |
999-0190 |
Nut 1/4-20 hex plain finish |
3 |
|
| 17 |
999-0333 |
Screw 10-24 x 1/2 pan head phillips stainless steel |
7 |
|
| 18 |
999-0599 |
Screw 1/4-20 x 1 3/4 pan head phillips stainless steel |
3 |
|
| 19 |
272-9417 |
Seat switch |
1 |
|
| 20 |
999-0517 |
Bolt M8-1.25 x 16mm hex head full thread zinc |
3 |
|
| 21 |
172-0392 |
Retaining ring |
2 |
|
| 22 |
999-0471 |
Nut M8-1.25 nylon insert lock zinc plated |
3 |
|
| 23 |
172-0553 |
Washer 17/64 x 1/16 flat |
2 |
|
| 24 |
172-2067 |
Washer 11/32 x 1/8 flat |
4 |
|
| 25 |
999-0998 |
Washer #10 flat stainless steel |
4 |
|
| 26 |
172-8494 |
#6 hose clamp SAE |
4 |
|
| 27 |
172-0254 |
Nylon pipe cap |
1 |
|
| 28 |
172-9023 |
Cable clamp |
1 |
|
| 29 |
172-0197 |
Rubber washer |
1 |
|
| 30 |
172-0223 |
Battery cable boot |
2 |
|
| 31 |
272-1448 |
90 degree elbow barb |
1 |
|
| 37 |
999-1454 |
Bolt 5/16-18 x 5/8 pan head stainless steel |
1 |
|
| 39 |
181-0176 |
Phenolic spacer |
1 |
|
| 40 |
172-2105 |
Manual solution valve |
1 |
|
| 41 |
172-2327 |
Wire reinforced clear hose (OBSOLETE) |
1 |
|
| 42a |
272-6335 |
Seat (OBSOLETE) |
1 |
|
| 43 |
272-6100 |
Solution tank |
1 |
|
| 44 |
172-3432 |
Solution tank cover (OBSOLETE) |
1 |
|
| 46a |
272-7243 |
Control board kit |
1 |
(includes 46b - 46d)(272-5329 is obsolete and replaced by 272-7243 and is used on all models) |
| 46b |
272-8156 |
Panel assembly |
1 |
|
| 46c |
272-1316 |
Key switch assembly |
1 |
|
| 46d |
172-8098 |
Replacement key |
1 |
|
| 48 |
272-1460 |
Water valve bracket |
1 |
|
| 49 |
172-3437 |
Cable clamp |
5 |
|
| 50 |
272-6101 |
Front bumper (OBSOLETE) |
2 |
|
| 51 |
172-3438 |
Actuator cover |
1 |
|
| 52 |
172-3439 |
Disconnect bar |
1 |
|
| 53 |
272-6102 |
Tank mount bracket |
1 |
|
| 54 |
272-6103 |
Seat mount weldment |
1 |
|
| 57 |
172-3443 |
Charger connector assembly |
1 |
|
| 58 |
172-3444 |
Hinge bracket |
1 |
|
| 60 |
272-1459 |
Valve bracket |
1 |
|
| 61 |
172-3447 |
Battery box panel |
1 |
|
| 65 |
272-2586 |
36V solenoid valve |
1 |
|
| 66 |
172-1770 |
Connector assembly |
1 |
|
| 67 |
272-1462 |
Clear hose 3/4 inches |
1 |
|
| 69 |
172-3449 |
Battery connector kit |
1 |
(includes items 70-73a)(Battery Connector Kit 172-3449 is included with machine) |
| 70 |
272-1144 |
Cable assembly |
4 |
|
| 72 |
172-0223 |
Battery cable boot |
10 |
|
| 73a |
172-3450 |
Battery cable assembly- ring type 4x15 1/2 |
1 |
|
| 73b |
172-3451 |
Battery spacer |
1 |
|
| 74 |
272-0462 |
Cable clamp |
4 |
|
| 75 |
372-0047 |
Screw 10-24 x 2 pan head phillips |
4 |
|
| 76 |
999-0419 |
Screw 1/4-20 x 5/8 flat head slotted zinc plated |
12 |
|
| 77 |
172-1062 |
7 inch spiral hose |
1 |
|
| 78 |
272-1469 |
Solution valve |
1 |
|
| 81 |
999-0424 |
Bolt 5/16-18 x 1 hex head stainless steel |
4 |
|
| N/S |
272-6637 |
Main wiring harness |
1 |
|
|
|
- Batteries, Brushes, and Chargers - 272-9909 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 01 |
162-0005 |
6V 305Ah wet battery (SNSR) |
|
|
| 02 |
162-0019 |
6V 390Ah wet battery (SNSR) |
|
|
| 03 |
162-0046 |
6V 335Ah AGM battery (Group J305) |
|
|
| 04a |
162-5063 |
36V 20amp battery charger with SB175 large gray plug |
|
|
| 04b |
162-5063 |
36V 20amp battery charger with SB175 large gray plug |
|
|
| 06 |
372-1153 |
36V 25amp onboard battery charger |
|
|
| 07 |
272-0479 |
36V onboard charger kit |
|
|
| 08 |
991-2112 |
175amp charger plug with pins (gray) SB175 |
|
|
| 09 |
998-0010 |
Battery jumper cable - ring type (red) |
|
|
| 11 |
991-2206 |
Center-Lok 3 pad holder |
|
|
| 12 |
996-3186 |
Magnagrit brush |
|
|
| 13 |
996-3187 |
Dynagrit brush |
|
|
| 14 |
996-3188 |
Aglite brush (OBSOLETE) |
|
|
| 15 |
996-3189 |
Prolene scrubbing brush |
|
|
| 16 |
996-3190 |
Prolite scrubbing brush |
|
|
| 17 |
996-3191 |
Union mix brush |
|
|
| 18 |
996-3192 |
Midgrit scrubbing brush |
|
|
| 19 |
996-3193 |
Midlite grit scrubbing brush |
|
|
|
|
- Pad Holders - 275-9029 |
|
| RefNbr |
Part Number |
Description |
Req |
Notes |
| 1 |
991-2214 |
Center-Lok II pad holder - left hand thread (red) |
|
|
| 2a |
991-2201 |
Center-Lok II pad holder - right hand thread (black) |
|
(Pad driver side female, Floor side male) |
| 2b |
991-8577 |
Pad retainer |
|
(Pad driver side male, Floor side female) |
| 3a |
991-2202 |
Big mouth pad holder set (blue) |
|
(includes 3 screws) |
| 3b |
991-2205 |
Deep lock ring and pad grip ring |
|
|
| 4 |
991-2203 |
Big mouth pad holder male thread portion |
|
|
| 5 |
991-2206 |
Center-Lok 3 pad holder |
|
(includes 3 screws) |
| 6 |
996-0372 |
Big mouth pad holder (left hand thread) |
|
|
| 8 |
991-2209 |
Split retainer - pad holder ring (OBSOLETE) |
|
|
| 9 |
N/A |
Not available |
|
(replaced by #3 991-2202) |
| 10 |
991-2211 |
Center lock pad holding cup (male) (yellow) (OBSOLETE) |
|
|
|
|
